    Apter Power delivers genuine Schneider Electric BMXP3420302 processors, providing a dependable source for premium quality, industrial-grade PLC hardware to ensure efficient, multi-axis motion and network control.

BMXP3420302

/ 4.9
1001 reviews | Need a Specific Revision?
The Schneider Electric BMXP3420302 is designed for the Modicon M340 automation platform and is capable of handling complex industrial control applications with precision and reliability.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for BMXP3420302
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for BMXP3420302

  • Manufacturer:
    Schneider Electric
  • Part Number:
    BMXP3420302
  • Product Family:
    Modicon M340 automation platform
  • Product Type:
    Processor Module
  • Stock:
    1
  • Range of product:
    Modicon M340 automation platform
  • Product or component type:
    Processor module
  • Concept:
    CANopen Transparent Ready
  • Number of racks:
    4
  • Number of slots:
    11
  • Number of application specific channel:
    36
  • Port Ethernet:
    10BASE-T/100BASE-TX
  • Weight:
    4 kg
  • Estimated shipping dimensions:
    5x11x11cm
  • Tariff Code:
    8537101190
  • Country of origin:
    France
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Diagnostics Monitoring & Control

Features:

  • Interface Between the Control Network and Modicon M340 Automation Platform
  • Combines Capability of High-Speed Processing with CANopen Communication Support
  • Operates in Conjunction with the M340 Series I/O Modules and Application-Specific Channels
The Schneider Electric BMXP3420302 operates as the Processor Module in a Modicon M340 rack, providing reliable control and data processing for all modules within the system. It continuously manages up to 1024 discrete I/O points and 256 analog I/O points in multi-rack configurations, distributing processing power through the rack backplane to support steady state operation of all I/O modules and application channels. Seamless communication transfer is standard with the BMXP3420302, however using an optional Redundant Configuration will allow seamless switchover to a backup processor in the event of a primary module failure. The BMXP3420302 has made improvements in several areas over previous processor designs in addition to incorporating CANopen transparent ready capability within the M340 rack.

The Schneider Electric BMXP3420302 provides essential control functions common to the entire rack, and is a critical component of the automation path, directly affecting the proper, normal operation of the overall control system. One BMXP3420302 processor module is required per rack depending on the desired I/O capacity. The BMXP3420302 occupies a dedicated slot in the rack and supports up to 4 racks with 11 slots per rack configuration.

For Extended I/O applications, the Schneider Electric BMXP3420302 processor module supports multi-rack expansion with distributed I/O management. In addition to standard single rack operation, the multi-rack configuration also performs automatic I/O addressing. The BMXP3420302 multi-rack configuration executes data exchange using the internal CANopen circuitry specified in the processor options. Using this method, the distributed I/O system continually monitors the health of all connected racks. If the system detects that a remote I/O rack is no longer communicating (outside configured response/tolerance levels), it will automatically flag the fault in the diagnostic register and place an event in the System Event List.

The BMXP3420302 Schneider Electric Processor Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Schneider Electric BMXP3420302 Processor Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Schneider Electric BMXP3420302 Processor Module Specs

General

  • Manufacturer Schneider Electric
  • Model BMXP3420302
  • Condition New Original ready stock
  • Product Family BMXXBP0400 ,BMXXBP0600 ,BMXXBP0800
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Process Industries: Utilized in water treatment, cement production, and renewable energy management.
  • Manufacturing: Ideal for secondary packaging, materials handling, textiles, printing, food processing, and woodworking machines.
  • Infrastructure: Deployed in infrastructure automation and large-scale machine control.
  • Motion Control: Supports complex motion tasks using independent axis control via CANopen for devices like Lexium 32 servo drives.
  • LED Status Indicators: A front-panel display block with 8-10 LEDs provides real-time alerts.
  • I/O Module Faults: Identifies errors in connected input/output modules.
  • Processor/System Faults: Red 'ERR' LED indicates critical internal failures.
  • Network Faults: Dedicated LEDs for Ethernet (ETH STS) and CANopen (CAN ERR) communication issues.
  • Memory Card Errors: Monitors the health and presence of the SD flash memory card.
  • Environmental Protection: It is IP20-rated and meets standards for industrial electromagnetic compatibility (EMC) (EN 61000-6-2/4) and safety (EN 61131-2).
  • Security: Features a safety screw on the front panel to lock the module into its slot.
  • Control Capacity: Manages up to 1024 discrete I/O and 256 analog I/O across a maximum of 4 racks.
  • Integrated Communication: Features multiple ports for comprehensive network monitoring.
  • Ethernet Modbus/TCP: Provides 10/100 Mbit/s connectivity for high-level monitoring and data exchange.
  • CANopen Master: Directly controls up to 63 slave devices for machine-level bus communication.
  • Modbus Serial Link: Supports RS-232/RS-485 for legacy device integration.
  • Web Services: When used with the included memory card, it can activate a standard Web server (Class B10) for remote diagnostics and data editing.
  • Processing Speed: Capable of executing 8.1 Kinst/ms (Boolean) with a typical master task overhead of 0.7 ms.
Description
The Schneider BMXP3420302 is a high-performance processor module designed for the Modicon M340 automation platform, engineered to handle complex industrial control applications with precision and reliability. This Schneider BMXP3420302 processor module supports a maximum configuration of 1024 discrete I/O points and 256 analog I/O points in multi-rack setups, making it ideal for large-scale manufacturing operations that require extensive input and output management. In single-rack configurations, the Schneider BMXP3420302 provides 704 discrete I/O and 66 analog I/O, offering flexibility for smaller applications while maintaining robust processing capabilities.

The Schneider BMXP3420302 is built on the CANopen communication concept with Transparent Ready functionality, ensuring seamless integration into modern industrial networks. This Schneider BMXP3420302 processor module supports up to 4 racks with 11 slots per rack, enabling scalable system architecture for growing automation needs. Additionally, the Schneider BMXP3420302 features 36 application-specific channels, allowing for specialized configurations tailored to unique operational requirements. This Schneider BMXP3420302 processor module is specifically designed for material handling systems, packaging lines, and process control applications where reliable real-time data processing and extensive I/O connectivity are critical for maintaining operational efficiency and system responsiveness.
Alternative Names
BMXP342O3O2 8MXP3420302 BMXXBP0800 BMXXBP1200 BMXP341000 BMXXBP0600 BMXXBP0400
Technical notes
Engineered for reliable distributed architectures, the Schneider Electric BMXP3420302 utilizes an internal rack power supply consuming 135 mA at 24 V DC while executing highly efficient task cycles including 1 cyclic master task, 1 fast periodic task, and up to 64 event-triggered tasks. The Schneider Electric BMXP3420302 provides an impressive processing velocity of 8.1 Kinst/ms for pure boolean operations, ensuring real-time response for safety-critical and high-speed industrial sequences.
