170AAI14000

/ 4.9
1001 reviews | Need a Specific Revision?
Schneider Electric 170AAI14000 is a Modicon Momentum distributed analog input base with 16 single-ended channels.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 170AAI14000
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 170AAI14000

  • Manufacturer:
    Schneider Electric
  • Part Number:
    170AAI14000
  • Product Family:
    TSX Momentum
  • Product Type:
    Modicon Momentum Analog Input Base
  • Stock:
    1
  • Manufacturer:
    Schneider Electric
  • Product range:
    Modicon Momentum
  • Product role:
    Distributed analog input base
  • Input channels:
    16 single-ended
  • Update time:
    25 ms
  • Terminal blocks:
    2 removable
  • Protection:
    Reverse polarity; 2 A slow-blow
  • Weight:
    0.215 kg
  • Estimated shipping dimensions:
    5.5x18x26cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    France
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Selection Installation Service Checks Applications

Features:

  • Analog acquisition: Brings 16 single-ended field signals into a Modicon Momentum I/O node.
  • System pairing: Works as an I/O base beneath the compatible communication adapter and controller configuration.
  • Service boundary: Keeps signal range, terminal map, field power and PLC scaling tied to the installed base.
170AAI14000 is used where multiple analog field measurements must be collected through a distributed Modicon Momentum station.

The base, communication adapter and controller project form one I/O path; replacing only the base does not remove the need to verify addressing, data format and channel scaling.

Keeping the exact 170AAI14000 identity with the terminal map helps technicians preserve channel order and avoid moving a valid signal into the wrong PLC variable.

Apter Power supports exact-model document review, quotation, and procurement for the Schneider Electric 170AAI14000 Modicon Momentum Analog Input Base.
Schneider Electric 170AAI14000 Modicon Momentum Analog Input Base Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Signal range: verify every current or voltage input against the approved design.
  • Adapter: confirm the Momentum communication adapter and controller configuration.
  • Terminals: inspect both removable terminal blocks and field-conductor identification.
  • Safe state: place affected control and alarm loops in maintenance before disconnection.
  • Wiring: transfer conductors by channel and polarity with shielding and grounding retained.
  • Configuration: reconcile raw counts, scaling, diagnostics, and scan behavior in the PLC project.
  • Electrical checks: verify field supply, polarity, loop continuity, and absence of ground faults.
  • Signal tests: apply known values to each used channel and confirm PLC engineering units.
  • Record: retain adapter and base identities, terminal map, test values, diagnostics, and restored loop status.
  • Distributed analog acquisition: sixteen single-ended field inputs.
  • Legacy PLC support: verified Modicon Momentum installations.
  • Migration planning: controlled transition before the announced lifecycle milestones.
Description
In a Modicon Momentum station, 170AAI14000 collects 16 single-ended analog field signals and passes their data through the attached communication adapter to the controller. The I/O base therefore links field wiring, node hardware and PLC configuration in one measurement path.

If one channel changes after service, 170AAI14000 should be checked from the terminal and field supply through the raw PLC value and engineering-unit scaling. A correct adapter status does not prove that every channel range, polarity or terminal position is correct.

For replacement, 170AAI14000 should remain tied to the compatible Momentum adapter, two terminal blocks, channel map and controller project. Preserving those records reduces the chance of a wiring or scaling error during restart.
Technical notes
For 170AAI14000, place all affected analog loops in an approved safe state and isolate field power before moving terminals. Match the exact Momentum base, communication adapter, two removable terminal blocks, channel ranges, field wiring, shielding, grounding, and PLC scaling; stop if the base, adapter, or signal definition differs.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
A spare I/O base is available, but its model is not readable. Can terminal layout alone prove it is 170AAI14000?
No. Confirm the exact base identity from the label and controlled parts record, then match the adapter, channel definitions, terminal blocks and controller configuration.
The communication adapter reports healthy after 170AAI14000 is replaced, but one analog value is wrong. Where should diagnosis begin?
Check that channel’s polarity, signal range, terminal position, field supply, loop resistance, raw PLC value and engineering-unit scaling before replacing more hardware.
Can a Momentum communication adapter be moved onto 170AAI14000 without checking the controller project?
No. Verify that the adapter supports the base and that addressing, data format, I/O mapping and diagnostics in the controller project match the installed node.
Several channels on 170AAI14000 shift when a nearby motor starts. What should be inspected?
Inspect shielding, grounding, cable routing, field-supply stability and separation from noise sources, then compare the raw input with a controlled test signal.
What must happen before technicians remove either terminal block from 170AAI14000?
Place every affected control and alarm loop in the approved maintenance state, isolate field power and verify safe process conditions before moving wiring.
What evidence should be recorded after 170AAI14000 is commissioned?
Retain the base and adapter identities, terminal map, field-power checks, injected test values, PLC raw and scaled readings, diagnostics, alarms and restored loop status.
