170ADI35000

/ 4.9
1001 reviews | Need a Specific Revision?
The 170ADI35000 is a highly reliable, high-density discrete input base module within the Schneider Electric Modicon Momentum product family. Engineered to minimize control cabinet footprint while maximizing signal acquisition capacity.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 170ADI35000
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 170ADI35000

  • Manufacturer:
    Schneider Electric
  • Part Number:
    170ADI35000
  • Product Family:
    TSX Momentum
  • Product Type:
    Input Base Module
  • Stock:
    4
  • Product or component type:
    Discrete inputs base DC
  • Group of channels:
    2 groups of 16 inputs
  • Discrete input number:
    32 conforming to IEC 1131-2 Type 1
  • Discrete input voltage:
    24 V DC
  • Protective treatment:
    TC
  • Discrete input logic:
    Positive
  • Input voltage limits:
    24 V
  • Voltage range:
    - 3...30 V
  • Weight:
    0.22 kg
  • Estimated shipping dimensions:
    14.3x12.3x4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    France
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Operating Environment Monitoring & Control

Features:

  • Provides 32 discrete inputs in a compact Momentum form factor.
  • Accepts 15-30V DC sinking/sourcing inputs for flexible field device integration.
  • Individual channel status LEDs with removable terminal block for easy maintenance.
The 170ADI35000 delivers 32 discrete input channels in a compact Momentum form factor, providing high-density digital input capability for space-constrained control cabinets. The module is organized in four groups of eight channels, each with a common terminal, simplifying wiring and reducing installation time. The 170ADI35000 is ideal for applications requiring numerous digital inputs from sensors, limit switches, and pushbuttons in manufacturing, material handling, and building automation systems.

The 170ADI35000 accepts a wide input voltage range of 15-30V DC for ON-state signals, with OFF-state detection below 5V DC, ensuring reliable signal detection from a variety of field devices. The module supports both sinking and sourcing configurations, providing flexibility for integrating sensors from different manufacturers. The 170ADI35000 provides approximately 7mA input current at 24V DC, minimizing loading on field devices, and supports 0.5A maximum current per common group.

The 170ADI35000 features individual LED indicators for each of the 32 input channels, enabling real-time status monitoring and rapid troubleshooting of field wiring and device issues. The module includes a removable terminal block, allowing wiring to remain intact during module replacement and simplifying maintenance. The 170ADI35000 is designed for DIN rail mounting and provides reliable operation in demanding industrial environments.

The 170ADI35000 Schneider Input Base Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Schneider 170ADI35000 Input Base Module Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Schneider 170ADI35000 Input Base Module Specs

General

  • Manufacturer Schneider
  • Model 170ADI35000
  • Condition New Original ready stock
  • Product Family 170ADO35000,170AAI14000,170AAO92100
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Distributed Factory Automation: Installed in local control enclosures across manufacturing lines to gather state changes from proximity sensors, photoelectric switches, safety interlocking gates, and control buttons.
  • Municipal Infrastructure & Water Treatment: Extensively used in water pumping stations, wastewater treatment skids, and valve nests to track digital position feedbacks (e.g., valve fully open/closed, pump run/trip statuses, and low/high level float alarms).
  • Material Handling & Logistic Systems: Integrated along long conveyor loops, automated sorting terminals, and airport baggage handling decks to capture high-speed tracking data from sorting eyes and weight triggers.
  • Operational Range: Rated to function reliably between 0 °C and +60 °C (32 °F to 140 °F) under natural convection cooling.
  • Storage Range: Can withstand extreme storage spikes from -40 °C to +85 °C (-40 °F to 185 °F).
  • Humidity and Moisture: Supports relative humidity levels ranging from 5% to 95% non-condensing, allowing it to be safely deployed in humid environments such as food processing washdown vicinities (when installed inside appropriately rated NEMA/IP enclosures).
  • Channel-by-Channel LED Monitoring: The module housing embeds a 32-point green LED diagnostic array. This provides maintenance technicians with an instant, direct visual monitor of whether individual field circuits are actively closed and energized without deploying a test probe.
  • Signal Conditioning (Hardware Filtering): To prevent physical contact bounce or electrical EMI noise from falsely triggering logic loops, the module utilizes a hardware input filter. Signals must remain stable for a predefined time window (typically in the millisecond range) before the module updates its internal data registers.
  • Cyclic Data Mapping: When coupled with a Network Adapter (such as Modbus TCP/IP or PROFIBUS DP), the module continuously scans its 32 physical points and packs the statuses into two 16-bit registers. These registers are cyclically polled by the main controller (PLC/DCS) via deterministic network heartbeats.
Description
The 170ADI35000 is a discrete input module from the Modicon Momentum range, designed as a 32-input, 24 V DC base. This input module is part of the Modicon Momentum family, which provides controllers and IP20 monoblock I/Os for distributed control architectures. The 170ADI35000 offers two groups of 16 inputs, fully conforming to IEC 1131-2 type 1 with positive discrete input logic, and operates with a discrete input voltage of 24 V DC.

170ADI35000 provides isolation between channels and ground at 500 V AC, ensuring safe and reliable operation. It features 32 LEDs for channel status signaling, allowing clear and immediate monitoring of input states.

The primary applications of the 170ADI35000 include infrastructures and energy systems, material handling, and simple machine control. The module is CE, CSA, and UL certified, and it is suitable for wall mounting.
Alternative Names
17OADI35OOO I70ADI35000 170ADO35000 170AAO92100 170AAI14000 140XCA71706 140XBE10000 170PNT11020
