    Apter Power supplies original Siemens A5E37764770 VFD drive boards, delivering precise, factory-certified replacement parts to ensure optimal power cell sync and reliable performance in heavy-duty high-voltage systems.

A5E37764770/A5E03965230A

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens A5E37764770/A5E03965230A Control Board Delivers High-Resolution Analog Signal Processing With Reliable DIN Rail Installation And Industrial-Grade Protection.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for A5E37764770/A5E03965230A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for A5E37764770/A5E03965230A

  • Manufacturer:
    Siemens
  • Part Number:
    A5E37764770/A5E03965230A
  • Product Family:
    Siemens Robicon
  • Product Type:
    Cell Controller Board
  • Stock:
    1
  • Rated power supply voltage:
    24 V DC
  • Resolution:
    Typically 16 bits
  • Current:
    4 … 20 mA; 0 … 10 mA; 0 … 20 mA
  • Voltage:
    +/- 10 V
  • Protection class:
    IP20, UL open type, typically installed in a control cabinet.
  • Installation method:
    Standard DIN rail mounting, compact design
  • Operating temperature:
    0 … 60 °C
  • Storage/transport temperature:
    -40 … +70 °C.
  • Weight:
    0.65 kg
  • Estimated shipping dimensions:
    36.3x14.2x5.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Gemany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Configuration Safety & Compliance

Features:

  • High-Precision Analog Signal Processing For Industrial Automation Applications
  • Compact DIN Rail Mount Design With IP20 Protection And UL Open-Type Compatibility
  • Supports Multiple Current And Voltage Inputs With Typical 16-Bit Resolution
The Siemens A5E37764770/A5E03965230A control board is designed to deliver accurate analog signal management in complex industrial systems. It handles a variety of input types including 4…20 mA, 0…10 mA, 0…20 mA currents, and ±10 V voltages, ensuring reliable integration with sensors and actuators across manufacturing, chemical, and energy industries.

Compared with standard control boards, the Siemens A5E37764770/A5E03965230A stands out for its compact DIN rail installation, IP20-rated protection, and UL open-type compatibility. Its typical 16-bit resolution provides precise signal conversion, reducing errors in process monitoring and control.

Engineered for robust operation, the Siemens A5E37764770/A5E03965230A supports an operating temperature range of 0…60 °C (some models 0…40 °C) and storage/transport conditions from -40…+70 °C. These characteristics make it a reliable choice for engineers seeking long-term stability and versatility in automation projects, while simplifying installation and maintenance in control cabinets.

The A5E37764770/A5E03965230A Siemens Control Board may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Siemens A5E37764770/A5E03965230A Control Board Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
