6SL3120-1TE13-0AA3

/ 4.9
1001 reviews | Need a Specific Revision?
Siemens 6SL3120-1TE13-0AA3 is a SINAMICS S120 booksize Single Motor Module with a 600 V DC input, 400 V three-phase output, and 3 A rating.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6SL3120-1TE13-0AA3
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6SL3120-1TE13-0AA3

  • Manufacturer:
    Siemens
  • Part Number:
    6SL3120-1TE13-0AA3
  • Product Family:
    Siemens SINAMICS
  • Product Type:
    SINAMICS S120 3 A Booksize Single Motor Module
  • Stock:
    1
  • Cooling Method:
    Internal air cooling
  • DC Link Input:
    600 V DC
  • Motor Output:
    400 V three-phase AC
  • Maximum Output Current:
    6 A
  • Rated Power:
    1.6 kW
  • DC Link Current:
    3.6 A
  • Control Connection:
    DRIVE-CLiQ
  • Safety Functions:
    Extended Safety Integrated support
  • Protection Rating:
    IP20
  • Weight:
    12.081 lbs (5.48 kg)
  • Estimated shipping dimensions:
    5x38x27cm
  • Tariff Code:
    8504409999
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DC Link Motor Output DRIVE-CLiQ Cooling

Features:

  • Converts the 600 V DC link into a controlled 400 V three-phase motor output.
  • The booksize power stage is rated for 3 A and uses internal air cooling.
  • DRIVE-CLiQ links the module with S120 control and extended safety functions.
Siemens 6SL3120-1TE13-0AA3 supplies one controlled motor axis from the shared S120 DC link.

The internal cooling path of 6SL3120-1TE13-0AA3 depends on the documented booksize mounting arrangement.

Control and feedback for 6SL3120-1TE13-0AA3 pass through DRIVE-CLiQ to the configured control unit.

Verify the complete Siemens 6SL3120-1TE13-0AA3 SINAMICS S120 3 A Single Motor Module article number and documented interface before matching the installed unit.
Siemens 6SL3120-1TE13-0AA3 SINAMICS S120 3 A Single Motor Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Common DC Bus Connection

  • Input path: The module receives power from the S120 600 V DC link.
  • Bus assembly: The DC-link connection follows the booksize line-up and protective-cover arrangement.
  • Precharge boundary: The module relies on the configured line-side components for DC-link charging.
  • Isolation work: Stored DC-link voltage is verified before motor-module connections are handled.

Axis Power Conversion

  • Three-phase output: The power stage generates the controlled 400 V three-phase motor supply.
  • Rated current: Continuous axis loading remains within the documented 3 A rating.
  • Peak current: Acceleration demand stays within the documented maximum-current boundary.
  • Motor cable: Conductor size, shielding, routing, and length follow the S120 power-unit requirements.

Control and Feedback Link

  • Module identity: DRIVE-CLiQ reports the module identity to the S120 control unit.
  • Parameter path: Axis parameters and operating commands pass through the configured control topology.
  • Fault data: Diagnostic records distinguish control-link faults from DC-link or motor-side faults.
  • Topology check: The physical DRIVE-CLiQ connection must match the commissioned project.

Booksize Mounting Conditions

  • Internal airflow: Cabinet ventilation carries heat away from the internal air-cooled power stage.
  • Mounting position: The module is installed in the documented upright booksize orientation.
  • Clearance: Required ventilation spaces remain unobstructed above and below the line-up.
  • Thermal diagnosis: Heat-sink temperature, fan path, cabinet temperature, and axis load are checked together.
Description
Siemens 6SL3120-1TE13-0AA3 is a SINAMICS S120 booksize Single Motor Module that converts the common 600 V DC link into a controlled 400 V three-phase motor output. Its 3 A power stage serves one motor axis within the modular S120 drive line-up.

The internal air-cooling path of 6SL3120-1TE13-0AA3 removes power-stage heat through the booksize assembly. The module therefore depends on the documented mounting position, ventilation space, and DC-link connection rather than operating as a stand-alone inverter.

DRIVE-CLiQ connects 6SL3120-1TE13-0AA3 to the control unit for identification, parameter exchange, and operating feedback. Extended Safety Integrated support is available through the configured S120 control system, while the motor cable remains on the module power output.
Alternative Names
6SL31201TE130AA3 6SL3120 1TE13 0AA3 6SL 3120 1TE13 0AA3 Siemens 6SL3120-1TE13-0AA3 6SL3120-1TE13-0AA3 Single Motor Module 6SL3120-1TE13-0AA3 SINAMICS S120 6SL3120-1TEI3-0AA3 6SL3120-1TE13-OAA3
Technical notes
The DC-link, motor, DRIVE-CLiQ, and cooling connections of Siemens 6SL3120-1TE13-0AA3 must follow the configured SINAMICS S120 axis layout.
