        • Lifecycle status

          Active / Available from OEM
          Apter Power provides 6AG1532-5HF00-7AB0 quotations, manuals, product selection, and exact-model matching.

        6AG1532-5HF00-7AB0

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Controller values become eight voltage or current field signals through Siemens 6AG1532-5HF00-7AB0, a SIPLUS S7-1500 high-speed analog output module.
        In Stock
        Ships by Friday, October 30
        Fast Shipping Available
        Get a quick price for 6AG1532-5HF00-7AB0
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 6AG1532-5HF00-7AB0

        • Manufacturer:
          Siemens
        • Part Number:
          6AG1532-5HF00-7AB0
        • Product Family:
          Siemens Simatic S7-1500
        • Product Type:
          SIPLUS S7-1500 AQ 8xU/I HS Analog Output Module
        • Stock:
          1
        • Analog Output Channels:
          8
        • Channel Grouping:
          One group of eight channels
        • Output Signal Types:
          Voltage or current per configured channel
        • Maximum Resolution:
          16 bit including sign
        • Minimum Module Cycle:
          125 µs
        • Rated Supply Voltage:
          24 V DC
        • Permissible Supply Range:
          19.2 to 28.8 V DC
        • Voltage Output Ranges:
          ±10 V, 0–10 V and 1–5 V
        • Current Output Ranges:
          ±20 mA, 0–20 mA and 4–20 mA
        • Load for Voltage Output:
          1 kΩ minimum
        • Load for Current Output:
          750 Ω maximum
        • Diagnostic Functions:
          Supply voltage, wire break and short circuit monitoring
        • Status Indicators:
          RUN, ERROR, PWR and channel diagnostics LEDs
        • Horizontal Operating Temperature:
          -40 to +70 °C
        • Vertical Operating Temperature:
          -40 to +40 °C
        • Typical Power Loss:
          7 W
        • Voltage Output Wiring:
          2-wire or 4-wire
        • Vertical Operating RangeCurrent Output Wiring:
          2-wire
        • Weight:
          0.7165 lbs (0.325 kg)
        • Estimated shipping dimensions:
          3.5x14.7x12.9cm
        • Tariff Code:
          85389091
        • Country of origin:
          Germany
        • Place of shipment:
          Xiamen,Fujian,China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Signal Assignment Update Behavior Channel Diagnostics SIPLUS Limits

        Features:

        • Eight channels convert S7-1500 output words into configured voltage or current signals.
        • High-speed updating relates the module cycle to the enabled channel configuration.
        • Supply, wire-break and short-circuit diagnostics identify different output-path faults.
        The AQ module keeps the controller data path separate from the field load connected at each output terminal.

        A configured output range determines the electrical span represented by the channel word.

        Conformal coating and the SIPLUS temperature range address harsher ambient conditions without changing the order number.

        The Siemens 6AG1532-5HF00-7AB0 SIPLUS S7-1500 AQ 8xU/I HS Analog Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Siemens 6AG1532-5HF00-7AB0 SIPLUS S7-1500 AQ Analog Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

        Mapping controller words to field outputs

        • Channel range: Each output uses its configured voltage or current span when converting the assigned digital word.
        • Voltage path: The converted value drives a voltage load within the documented minimum resistance.
        • Current path: A current-loop setting regulates the output through the permitted field resistance.
        • Substitute value: Configured reaction behavior determines the level used after a qualifying controller or module event.

        Relating channel use to output timing

        • Module cycle: The active channel arrangement contributes to the interval required to refresh the output group.
        • High-speed mode: The shortest documented cycle serves setpoints that require faster electrical updates.
        • Settling path: Load and signal type affect how quickly the terminal reaches the commanded level.
        • Controller data: New values enter through the S7-1500 backplane before conversion at the selected channel.

        Separating supply and field-circuit conditions

        • Supply monitoring: Loss of the 24 V DC feed produces a module diagnostic condition.
        • Current monitoring: Wire-break detection supervises the configured current-loop path.
        • Voltage monitoring: Short-circuit detection applies to the configured voltage output.
        • Local indication: Module and channel LEDs identify operating state and the affected diagnostic level.

        Applying the coated module within its environment

        • Conformal coating: The protected assembly is the SIPLUS timplementation based on the stated standard S7-1500 article.
        • Horizontal mounting: The wider documented temperature span applies when the rack orientation is horizontal.
        • Vertical mounting: The upper operating temperature is lower for the vertical installation position.
        • Model boundary: The complete 7AB0 suffix identifies this environmental version rather than the standard module.
        Description
        Siemens 6AG1532-5HF00-7AB0 is the SIPLUS S7-1500 AQ 8xU/I HS analog output module that converts CPU output words into eight field-level voltage or current signals. Its conformal-coated electronics extend the environmental range of the underlying S7-1500 output design while retaining the same controller-side data path.

        Each channel of 6AG1532-5HF00-7AB0 receives its measuring range and substitute-value behavior from the hardware configuration. The module scales the assigned digital word into the selected voltage or current span, then drives the corresponding terminal without mixing that channel's value with the other seven outputs.

        Update timing on 6AG1532-5HF00-7AB0 is determined by the active channel configuration and the output mode rather than by a single static settling value. The documented high-speed cycle lets the controller refresh changing setpoints quickly, while the required load boundary still applies at the field terminal.

        Diagnostic paths in 6AG1532-5HF00-7AB0 distinguish supply loss, a broken current loop and a shorted voltage output. RUN, ERROR, PWR and channel indicators expose those conditions locally, and enabled diagnostic events pass the corresponding module status back through the S7-1500 backplane.
        Alternative Names
        6AG15325HF007AB0 6AG1 532-5HF00-7AB0 6AG1532 5HF00 7AB0 Siemens 6AG1532-5HF00-7AB0 SIPLUS AQ 8xU/I HS 6AG1532-5HF00-7AB0 S7-1500 AQ 8xU/I HS 6AG1532-5HF00-7AB0 6AG1532-5HFOO-7AB0 6AGI532-5HF00-7AB0
        Technical notes
        Siemens 6AG1532-5HF00-7AB0 assigns a voltage or current range to each of its eight output channels and updates the group through the selected operating mode. Wire-break monitoring applies to configured current outputs, while short-circuit diagnostics apply to voltage paths.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Why can 6AG1532-5HF00-7AB0 report a short circuit on one signal type but a wire break on another?
        Siemens 6AG1532-5HF00-7AB0 applies short-circuit diagnosis to voltage outputs and wire-break diagnosis to current outputs, so the configured range determines the fault logic.
        Does disabling unused channels shorten the update cycle of 6AG1532-5HF00-7AB0?
        No. Siemens 6AG1532-5HF00-7AB0 updates the complete group in 125 µs regardless of how many channels are activated or disabled.
        When should four-wire voltage connection be considered on 6AG1532-5HF00-7AB0?
        Use the documented 6AG1532-5HF00-7AB0 four-wire option when the configured voltage circuit requires separate sense conductors; keep the load at or above 1 kΩ.
        Why must rack orientation be checked before using 6AG1532-5HF00-7AB0 at elevated temperature?
        The 6AG1532-5HF00-7AB0 allows 70 °C horizontally but only 40 °C vertically, and ±10 V channel use is limited above 60 °C.
        What should be reviewed before assigning substitute values to 6AG1532-5HF00-7AB0?
        For 6AG1532-5HF00-7AB0, review each channel’s normal range, the expected response to its applicable diagnostic, and the controller logic that commands the fallback value.
        Can 6AG1532-5HF00-7AB0 mix voltage and current outputs in one module?
        Yes. Each 6AG1532-5HF00-7AB0 channel can use its own supported voltage or current range in the hardware configuration.
