    Apter Power offers 6ES7272-0AA30-0YA1 documentation, quotations and SIMATIC S7-200 model review.

6ES7272-0AA30-0YA1

/ 4.9
1001 reviews | Need a Specific Revision?
Configured from an S7-200 parameter block, Siemens 6ES7272-0AA30-0YA1 is a two-line TD 200 text display for operator screens and CPU-triggered alarms.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 6ES7272-0AA30-0YA1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 6ES7272-0AA30-0YA1

  • Manufacturer:
    Siemens
  • Part Number:
    6ES7272-0AA30-0YA1
  • Product Family:
    Siemens Simatic S7-200
  • Product Type:
    TD 200 Text Display
  • Stock:
    1
  • Display:
    2 lines, up to 20 characters per line
  • Keypad:
    9-key membrane keypad
  • Configurable Function Keys:
    4, up to 8 with SHIFT
  • User Screens:
    Up to 64
  • Alarm Messages:
    Up to 80
  • PLC Interface:
    RS485 (PPI)
  • Data Rates:
    9.6 / 19.2 / 187.5 kbit/s
  • Supply Voltage:
    15–30 V DC
  • Current Consumption:
    70 mA typical; 120 mA maximum
  • Front Protection:
    IP65 when correctly panel-mounted
  • Case Protection:
    IP20
  • Panel Cutout:
    138×68mm
  • Operating Temperature:
    0 to +60 °C
  • Included Cable:
    2.5 m TD/CPU cable
  • Weight:
    0.915 lbs (0.415 kg)
  • Estimated shipping dimensions:
    23.1×20×5.1cm
  • Tariff Code:
    85371098
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Screen Storage Alarm Flow Panel Mounting Network Setup

Features:

  • 6ES7272-0AA30-0YA1 displays two lines with up to 20 characters on each line.
  • The standard keypad combines four configurable function keys with fixed navigation keys.
  • A TD/CPU cable carries RS485 PPI communication and power from the S7-200 connection.
Up to four user menus can organize as many as eight screens per menu, within the 64-screen limit.

The CPU program can activate up to 80 alarm messages, each able to include embedded process variables.

Panel installation uses the supplied gasket and spacers to maintain the documented front protection.

The Siemens 6ES7272-0AA30-0YA1 TD 200 Text Display may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Siemens 6ES7272-0AA30-0YA1 TD 200 Text Display Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

V-Memory Parameter Block

  • Storage location: Screen text, variables and formatting remain in the S7-200 CPU's V memory.
  • Wizard allocation: STEP 7-Micro/WIN assigns the starting address and reserves the required memory.
  • Display request: The TD 200 reads the selected screen from the parameter block after an operator command.
  • Multiple displays: Separate parameter blocks with different addresses can serve more than one TD device on a CPU.

CPU-Initiated Messages

  • Trigger: An alarm bit in the S7-200 user program starts the corresponding message.
  • Message source: The alarm text and embedded variables are read from the configured parameter block.
  • Display capacity: The TD 200 configuration can contain up to 80 alarm messages.
  • Priority order: Alarm priority follows the sequence established in the Text Display wizard.

Front-Panel Installation

  • Opening size: The mounting surface requires a 138×68 mm cutout.
  • Panel thickness: At least 1.5 mm is required for the documented sealing arrangement.
  • Spacer count: One spacer is used up to 1.5 mm and two spacers from 1.5 to 4.0 mm.
  • Seal path: The supplied gasket sits between the TD frontplate and the mounting surface.

PPI Addressing and Power

  • Direct connection: The supplied straight-through cable links one TD 200 directly to one S7-200 CPU.
  • Default addresses: The display starts at address 1 and looks for a CPU at address 2.
  • Data rate: PPI communication can be set to 9.6, 19.2 or 187.5 kbit/s.
  • Power source: The TD/CPU cable can power the display, or a grounded 15–30 V DC supply can be used.
Description
For the SIMATIC S7-200, Siemens 6ES7272-0AA30-0YA1 is the TD 200 text display with a two-line, 40-character display area and a nine-key membrane keypad. It presents operator screens and alarm messages generated through the S7-200 program.

Screen text, embedded variables and formatting for 6ES7272-0AA30-0YA1 reside in a parameter block in the CPU's V memory. The STEP 7-Micro/WIN Text Display wizard allocates that block; the TD 200 reads the selected screen after an operator command and displays an alarm when the associated CPU alarm bit becomes active.

The supplied 2.5 m TD/CPU cable connects 6ES7272-0AA30-0YA1 directly to the S7-200 for both RS485 PPI communication and power. Network settings in the TD setup menu define the display address, CPU address and data rate when the device is not left at its default one-to-one arrangement.

A 138×68 mm panel opening accepts 6ES7272-0AA30-0YA1; the front reaches IP65 when installed with the gasket in a panel at least 1.5 mm thick, while the casing remains IP20. The display operates from 0 to +60 °C and can also be powered from a grounded 15–30 V DC source.
Alternative Names
6ES72720AA300YA1 6ES7272 0AA30 0YA1 6ES7 272-0AA30-0YA1 Siemens 6ES7272 0AA30 0YA1 SIMATIC S7-200 TD 200 Text Display 6ES7272-0AA30-0YA1 TD200 6ES7272-0AA3O-0YA1 6ES7272-OAA30-0YA1
Technical notes
Siemens 6ES7272-0AA30-0YA1 reads screens, variables and alarm text from a parameter block stored in S7-200 V memory. The 2.5 m TD/CPU cable carries both PPI communication and power in the direct CPU connection.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How do I verify that 6ES7272-0AA30-0YA1 is the TD 200 rather than the TD 200C?
Siemens 6ES7272-0AA30-0YA1 is the standard TD 200 with a nine-key membrane keypad and a two-line, 40-character display area.
Does 6ES7272-0AA30-0YA1 store its screen text inside the display?
No. 6ES7272-0AA30-0YA1 reads screen text, variables and formats from a parameter block stored in the S7-200 CPU's V memory.
What causes an alarm to appear on 6ES7272-0AA30-0YA1?
An alarm bit set by the S7-200 user program tells 6ES7272-0AA30-0YA1 to read and display the associated message from the parameter block.
Can the supplied cable power 6ES7272-0AA30-0YA1 as well as carry data?
Yes. In a direct CPU connection, the 2.5 m TD/CPU cable supplies both PPI communication and power to 6ES7272-0AA30-0YA1.
Which opening should be prepared before mounting 6ES7272-0AA30-0YA1?
The panel cutout for 6ES7272-0AA30-0YA1 is 138×68 mm, and a minimum panel thickness of 1.5 mm is required for the documented sealed installation.
Where are the PPI addresses changed if 6ES7272-0AA30-0YA1 is not used in the default one-to-one setup?
Use the TD setup menu on 6ES7272-0AA30-0YA1 to change its address, the CPU address and the PPI data rate.
