5462-718

/ 4.9
1001 reviews | Need a Specific Revision?
The 5462-718 is a high-performance speed sensor module designed for speed measurement and control of shafts or turbines in industrial equipment.
Get a quick price for 5462-718
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 5462-718

  • Manufacturer:
    Woodward
  • Part Number:
    5462-718
  • Product Family:
    Woodward 505 Digital Governor Turbine Control
  • Input voltage range:
    1 to 25VRMS
  • Frequency response range:
    100Hz to 25kHz
  • Output type:
    Hall effect output / Analog voltage output (0-10V)
  • Accuracy specifications:
    Typical ±1% (reading value), linearity ±0.5% FS
  • Operating temperature range:
    -40°C to +85°C
  • Weight:
    0.38 kg
  • Estimated shipping dimensions:
    6.3x30x1.8cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
5462-718 — High-performance Speed Sensor Module, designed for speed measurement and control of shafts or turbines in industrial equipment. This module features a Hall effect sensor, built-in amplification and filtering circuitry, and an output that can be matched to the control system. The input voltage range is approximately 1 to 25 VRMS, and the frequency response range is approximately 100Hz to 25kHz, suitable for high-speed shaft measurement.

The module has a wide operating temperature range (-40°C to +85°C) and is adaptable to industrial environments. Its compact size facilitates installation in control cabinets or within equipment. This module is suitable for various scenarios such as engine speed monitoring, water pump speed monitoring, fan or mechanical spindle speed control, and can be used as a spare part for the maintenance or replacement of older systems.
Alternative Names
8237-1104 9907-173 9907-029 5462-758 5462-757 5503-282
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What type of module is 5462-718?
The 5462-718 is a speed sensor module used to detect the rotational speed of rotating shafts or mechanical equipment and output a signal for use by the control system.
What are the input voltage and frequency ranges?
The input voltage range is approximately 1 to 25 VRMS, and the frequency response range is approximately 100Hz to 25kHz.
What is the module's output type?
This module generates an analog voltage output (e.g., 0-10V) using a Hall effect sensor and features signal filtering and amplification functions.
How are the accuracy and linearity performance?
Typical accuracy is ±1% of reading, and linearity is approximately ±0.5% of full scale.
Operating temperature and environmental adaptability?
It can operate from -40°C to +85°C, suitable for industrial environments; it weighs approximately 0.38kg and has a compact size.
Is it still in production?
The information indicates that this model is marked
Is it repairable or replaceable?
Yes. As a speed sensing module for an older system, it is recommended to have it repaired through Woodward authorized service channels or a professional industrial spare parts service provider.
