The Yokogawa AAI543-S03 S1 is a 16-channel isolated analog output module that supplies precise 4–20 mA control signals for industrial DCS actuators and process regulation.
Get a quick price for AAI543-S03 S1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for AAI543-S03 S1

  • Manufacturer:
    Yokogawa
  • Part Number:
    AAI543-S03 S1
  • Product Family:
    Centum CS-Centum VP
  • Product Type:
    Isolated Analog Output Module
  • Number of Channels:
    16
  • Signal Type:
    4 to 20mA
  • Isolation Type:
    Electrical
  • Response Time:
    Standard or Fast
  • Configuration:
    Redundant
  • Power Supply Voltage:
    DC 24V
  • Operating Temperature:
    -20°C to +60°C
  • Storage Temperature:
    -40°C to +70°C
  • Communication Interface:
    Pressure clamp terminal, MIL connector cable, Dedicated cable
  • Weight:
    0.32 kg
  • Estimated shipping dimensions:
    3.2x10.6x13cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Japan
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Applications Manuals Specifications Applications Performance Safety & Compliance

Features:

  • High-Density 16-Channel Isolation
  • Standard Analog Output (4-20 mA)
  • Redundant Configuration with Switch-Over Response
Maximize your control cabinet space with 16 individually isolated channels in a single slot. This design eliminates cross-channel interference, ensuring that a fault on one loop does not affect the other 15 outputs, significantly improving system uptime and signal integrity.

Delivers precise 4-20 mA current output for direct control of modulating valves, I/P converters, and positioners. The module provides high accuracy of ±48 µA with minimal drift of ±16 µA per 10°C, ensuring stable process regulation even in fluctuating ambient temperatures.

Ensure maximum process availability by deploying two modules in a dual-redundant setup. The module supports standard switch-over response in redundant configurations,maintaining continuous output and preventing process disruptions in the event of a failure. Note: Fast switch-over response option is also available on select suffix codes.

The AAI543-S03 S1 YOKOGAWA Isolated Analog Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
YOKOGAWA AAI543-S03 S1 Isolated Analog Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
YOKOGAWA AAI543-S03 S1 Isolated Analog Output Module

General

  • Manufacturer YOKOGAWA
  • Model AAI543-S03 S1
  • Condition New Original ready stock
  • Product Family AAI543-H03 S1,AAI543-S50 S1,AAI543-S53 S1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Precise Final Element Control:Directly control modulating valves, I/P converters, and positioners in critical loops requiring high-resolution 4-20 mA current regulation.
  • High-Availability Critical Processes:Ideal for emergency shutdown systems (ESD) and burner management systems (BMS), where redundant configuration ensures safety and operational continuity.
  • Remote Asset Management:Suitable for oil & gas pipelines or large chemical plants where accessing physical instruments is difficult; however, no HART diagnostics are supported on this module.
  • Retrofits & Expansions:Compatible with existing Yokogawa I/O nodes (ANB10/ANB11), allowing easy system expansion without hardware overhaul.
  • Rapid Data Refresh:Fast update period (typical for FIO modules) supports real-time process responsiveness. (Note: 10ms not explicitly confirmed in GS)
  • High Precision Engineering:Delivers accuracy of ±48 µA with minimal drift of ±16 µA per 10°C, ensuring stable output in fluctuating ambient temperatures.
  • Flexible Power Architecture:Operates efficiently on standard DCS backplane power:230 mA @ 5V DC, 540 mA @ 24V DC — reducing thermal load on the cabinet.
  • Universal Load Driving:Capable of driving loads up to 750 Ω, compatible with a wide range of passive and active field devices without external signal conditioners.
  • High Dielectric Strength:Withstand voltage rating of 1500 V AC between output channels and system for 1 minute.
  • Open Circuit Detection:Actively detects circuit-open conditions (current dropping below 0.65 mA), alerting maintenance teams to wiring breaks immediately.
  • Rugged Environmental Tolerance:The -S03 suffix typically includes ISA Standard G3 coating and extended temperature range (-20 to 70°C), allowing reliable operation in harsh industrial environments with corrosive gases.
  • Integrated Surge Protection (Optional):Available via terminal block options (e.g., /A4S10), which include built-in surge absorbers for protection against transient voltage spikes from lightning or inductive switching.
Description
The Yokogawa AAI543-S03 S1 Analog Output Module delivers 4 to 20 mA current signals across 16 isolated channels, powered by a 24 V DC supply and supporting redundant operation with selectable standard or fast response times to meet diverse process control demands.

The Yokogawa AAI543‑S03 S1 is a high‑performance analog output module offering 16 isolated 4–20 mA current outputs, designed for precision control in industrial DCS environments.

In terms of reliability, the Yokogawa AAI543-S03 S1 boasts superior electrical safety performance. Its output channels can withstand 1500V AC withstand voltage (for 1 minute) between the output channels and the system, effectively resisting electrical surges and overvoltage impacts, protecting the control system and field equipment. The module's maximum current consumption is only 230mA (5V DC) and 540mA (24V DC), exhibiting low power consumption and low heat generation, making it suitable for high-density rack mounting environments. Furthermore, the Yokogawa AAI543-S03 S1 supports various external connection methods, including pressure-clamp terminals, MIL connector cables, and dedicated cables, allowing for flexible selection of wiring schemes according to site requirements, significantly simplifying engineering design, installation, and maintenance.

The "-S03" suffix in the Yokogawa AAI543-S03 S1 indicates compliance with ISA standard G3 anti-corrosion coating protection, enabling stable operation over a wide temperature range of -20°C to +60°C, making it suitable for harsh industrial environments containing corrosive gases. This module is widely used in distributed control systems (DCS) in industries such as petroleum, chemical, power, and water treatment, providing high-precision 4-20mA control signals for field actuators such as control valves, I/P converters, and positioners. Whether for new projects or retrofitting existing systems, the Yokogawa AAI543-S03 S1 can be seamlessly integrated into mainstream control platforms such as the Yokogawa Centum VP/ProSafe-RS. With its 16-channel high-density design and redundant configuration capabilities, it significantly reduces system footprint and total cost of ownership while improving control accuracy.
Alternative Names
AAI543S03S1 AA1543-S03 S1 AAI543-SO3 S1 AAI543-H03 S1 AAI543-S50 S1 AAI543-S53 S1 AAR145-S03 S1 AAR145-S50 S1
Technical notes
The Yokogawa AAI543-S03 S1 is a 16-channel isolated analog output module for Centum VP / ProSafe-RS DCS. It converts digital signals to precise 4-20 mA currents to drive field actuators. It does NOT support HART protocol — for HART analog output, please refer to other Yokogawa module models.
