PM5650-2ETH-XC 1SAP341000R0378

/ 4.9
1001 reviews | Need a Specific Revision?
ABB PM5650-2ETH-XC 1SAP341000R0378 is the active revision 3 AC500-XC V3 processor with an 84 MB application class, dual Ethernet, COM1, and CAN.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PM5650-2ETH-XC 1SAP341000R0378
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PM5650-2ETH-XC 1SAP341000R0378

  • Manufacturer:
    ABB
  • Part Number:
    PM5650-2ETH-XC 1SAP341000R0378
  • Product Family:
    ABB AC500
  • Product Type:
    AC500-XC V3 Processor Module
  • Stock:
    1
  • ABB Article:
    1SAP341000R0378
  • Processor Revision:
    3
  • Maximum Downloadable Application:
    84 MB
  • User Program and Data:
    8 MB
  • Power Supply:
    24 V DC at terminal base
  • Ethernet Interfaces:
    2 independent RJ45
  • Serial Interface:
    1 configurable RS-232/485
  • CAN Interface:
    1 at terminal base
  • Terminal Base:
    TB56xx-2ETH(-XC) family
  • Weight:
    0.135 kg
  • Estimated shipping dimensions:
    6.75 x 13.5 x 8.45 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Memory Planning Protocol Setup Cold Start

Features:

  • Mid-range memory class: The CPU provides 8 MB for user program and data within an 84 MB application allocation.
  • Independent communication paths: Dual Ethernet complements configurable RS-232/485 and CAN on the terminal base.
  • XC system compatibility: The module uses ABB AC500-XC environmental data and approved TB56xx-2ETH(-XC) hardware.
The PM5650 class supports projects that have outgrown entry-level memory but do not require the fastest PM567x execution resources.

Its modular base lets the panel designer choose communication expansion capacity while retaining consistent Ethernet, serial, CAN, and I/O-bus connections.

Commissioning should include compiled-memory review, protocol and license validation, cold-environment checks, network testing, and a controlled revision 3 recovery plan.

Availability is subject to Apter Power's current inventory and sourcing confirmation.
ABB PM5650-2ETH-XC 1SAP341000R0378 AC500-XC V3 Processor Module Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB PM5650-2ETH-XC 1SAP341000R0378 AC500-XC V3 Processor Module Specs

General

  • ManufacturerABB
  • ModelPM5650-2ETH-XC 1SAP341000R0378
  • ConditionNew Original ready stock
  • Product FamilyABB AC500-XC V3
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Controller resource review

  • Compiled project: Measure code, data, visualization, and retained-variable use.
  • Web content: Include file and visualization growth in the resource plan.
  • Communication buffers: Account for enabled protocols and connection counts.
  • Reserve: Keep margin for diagnostics and approved future changes.

Communication commissioning

  • Ethernet roles: Record the subnet and service assigned to each interface.
  • Serial mode: Select RS-232 or RS-485 and document protocol parameters.
  • CAN network: Verify node IDs, baud rate, cable, shielding, and termination.
  • Licenses: Match optional Ethernet protocols to the installed runtime scope.

Low-temperature startup review

  • Display response: Expect slower LCD behavior below 0 °C.
  • Diagnostics: Use controller state and network evidence before replacing hardware.
  • Condensation: Prevent moisture during temperature transitions.
  • Recovery test: Verify project restart and field communication under controlled conditions.
Description
PM5650-2ETH-XC 1SAP341000R0378 sits in the mid-range AC500-XC V3 class, giving engineers more application and web-server capacity than the PM5630 while retaining the same modular communication architecture.

PM5650-2ETH-XC 1SAP341000R0378 allocates 8 MB to user program and data within an 84 MB maximum downloadable application and connects through two independent Ethernet ports, configurable COM1, and CAN.

PM5650-2ETH-XC 1SAP341000R0378 requires an ABB-supported revision 3 project, a suitable TB56xx-2ETH(-XC) base, documented protocol roles, and environmental installation practices appropriate to the XC platform.
Alternative Names
PM5650 2ETH XC PM56502ETHXC ABB PM5650-2ETH-XC 1SAP341000R0378 ABB AC500-XC V3 PM5650-2ETH-XC PM5650-2ETH-XC PLC CPU
Technical notes
ABB PM5650-2ETH-XC 1SAP341000R0378 requires Automation Builder 2.6.0 or later and an approved TB56xx-2ETH-XC base; verify the compiled 8 MB program/data demand and protocol configuration before deployment.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Why choose PM5650-2ETH-XC 1SAP341000R0378 instead of PM5630-2ETH-XC?
Select it when the validated project needs greater program, data, web, or communication resources while keeping the AC500-XC V3 architecture.
How should PM5650-2ETH-XC 1SAP341000R0378 memory demand be checked before purchase?
Review compiled code, data, visualization files, retained variables, protocol buffers, diagnostic needs, and the expected project growth.
What can cause intermittent Ethernet service on PM5650-2ETH-XC 1SAP341000R0378?
Investigate duplicate addresses, subnet overlap, switch faults, cable quality, enabled services, traffic load, interface roles, and security settings.
How should PM5650-2ETH-XC 1SAP341000R0378 CAN faults be isolated?
Verify physical wiring, reference potential, shielding, termination, baud rate, node addresses, bus length, and controller configuration.
What revision checks apply when replacing an older PM5650-2ETH-XC 1SAP341000R0378?
Match the R0378 hardware target, Automation Builder and firmware requirements, libraries, licenses, project checksum, and acceptance procedure.
How should PM5650-2ETH-XC 1SAP341000R0378 be protected in corrosive service?
Follow ABB XC enclosure, connector-cap, grounding, humidity, salt-mist, and unused-slot requirements for the actual installation.
What should procurement confirm for PM5650-2ETH-XC 1SAP341000R0378?
Confirm the exact nameplate, terminal base, licenses, accessories, quantity, required condition, destination, inspection needs, and delivery date.
