PM5680-2ETH 1SAP152000R0378

/ 4.9
1001 reviews | Need a Specific Revision?
ABB PM5680-2ETH 1SAP152000R0378 is an active AC500 V3 multicore processor with 32 MB user program/data, dual Ethernet, COM1, and CAN.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PM5680-2ETH 1SAP152000R0378
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PM5680-2ETH 1SAP152000R0378

  • Manufacturer:
    ABB
  • Part Number:
    PM5680-2ETH 1SAP152000R0378
  • Product Family:
    ABB AC500
  • Product Type:
    AC500 V3 Multicore Processor Module
  • Stock:
    1
  • ABB Article:
    1SAP152000R0378
  • Processor Architecture:
    Multicore ARM Cortex-A53 64-bit
  • Maximum Downloadable Application:
    176 MB
  • User Program and Data:
    32 MB
  • Minimum Cyclic Task:
    0.5 ms
  • Power Supply:
    24 V DC at terminal base
  • Ethernet Interfaces:
    2 independent RJ45
  • Serial Interface:
    1 configurable RS-232/485
  • CAN Interface:
    1 at terminal base
  • Weight:
    0.135 kg
  • Estimated shipping dimensions:
    6.75 x 13.5 x 8.45 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Multicore Load Communication Design Expansion Base

Features:

  • Multicore processing: ABB uses a 64-bit ARM Cortex-A53 architecture for higher control and communication performance.
  • 160 MB application class: The CPU provides 32 MB for user program and data within a 176 MB maximum download.
  • Modular communication: Dual Ethernet, COM1, CAN, and a supported TB56xx base form the controller architecture.
The PM5680 class is suited to systems where controller tasks and network traffic must share multicore resources without overloading the application.

Real performance should be verified with DeviceTrace or equivalent project evidence while all intended protocols, visualization, and diagnostics are running.

The terminal-base slot count, subnet design, firmware target, communication licenses, thermal conditions, and recovery procedure should be fixed before commissioning.

Availability is subject to Apter Power's current inventory and sourcing confirmation.
ABB PM5680-2ETH 1SAP152000R0378 AC500 V3 Multicore Processor Module Manuals, Datasheets, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB PM5680-2ETH 1SAP152000R0378 AC500 V3 Multicore Processor Module Specs

General

  • ManufacturerABB
  • ModelPM5680-2ETH 1SAP152000R0378
  • ConditionNew Original ready stock
  • Product FamilyABB AC500 V3
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Performance monitoring plan

  • CPU traces: Measure each core and PLC load under realistic operation.
  • Task balance: Review cyclic, event, communication, and visualization workloads.
  • Headroom: Keep capacity for diagnostics and approved expansion.
  • Evidence: Archive accepted traces with the project version.

High-traffic network review

  • Subnets: Keep onboard Ethernet interfaces in documented, non-overlapping networks.
  • Connections: Plan protocol sessions against the ABB limits.
  • Gateway: Apply the AC500 V3 gateway rules to the complete architecture.
  • Security: Restrict web and engineering access to approved zones.

Terminal-base selection

  • Base model: Choose the TB56xx-2ETH base by required communication-module slots.
  • Supported capacity: Do not assume every base or six-slot combination supports PM5680.
  • Power: Calculate the complete module and I/O current requirement.
  • Commissioning: Test each added communication module independently.
Description
PM5680-2ETH 1SAP152000R0378 is ABB’s 160 MB multicore AC500 V3 processor for control systems that need higher computing headroom and substantial Ethernet data handling.

PM5680-2ETH 1SAP152000R0378 allocates 32 MB to user program and data, supports a 0.5 ms minimum cyclic task, and connects through dual Ethernet, configurable RS-232/485, and CAN on the terminal base.

PM5680-2ETH 1SAP152000R0378 should be introduced only after task-load tracing, network-role review, TB56xx base selection, project compatibility, and recovery testing have been completed.
Alternative Names
PM5680 2ETH PM56802ETH ABB PM5680-2ETH 1SAP152000R0378 ABB AC500 V3 PM5680-2ETH PM5680-2ETH PLC CPU
Technical notes
ABB PM5680-2ETH 1SAP152000R0378 must use a supported TB56xx-2ETH base; validate multicore task allocation, non-overlapping Ethernet subnets, firmware, and protocol licenses before deploying the project.
