CI853K01 3BSE018103R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB CI853K01 3BSE018103R1 is a dual-channel RS-232C communication interface kit for AC 800M CEX-Bus systems, supplied with TP853.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CI853K01 3BSE018103R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI853K01 3BSE018103R1

  • Manufacturer:
    ABB
  • Part Number:
    CI853K01 3BSE018103R1
  • Product Family:
    ABB Advant AC800M
  • Product Type:
    Dual RS-232C Communication Interface Kit
  • Stock:
    1
  • ABB Article Number:
    3BSE018103R1
  • Package Contents:
    CI853 interface and TP853 baseplate
  • Interface:
    Dual unisolated RS-232C
  • Channels:
    2
  • Communication Speed:
    75 to 19200 baud
  • Supported Protocols:
    Modbus, Siemens 3964R, COMLI, and custom protocols
  • Hot Swap:
    Supported
  • Protection Rating:
    IP20
  • Weight:
    0.7 kg
  • Estimated shipping dimensions:
    5.9 x 18.5 x 12.75 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Serial Channels Protocol Setup TP853 Wiring

Product overview

  • Interface role: Two-channel RS-232C communication for AC 800M controllers
  • Kit scope: CI853 communication interface with TP853 baseplate
  • Serial range: 75 to 19200 baud on both unisolated channels

CI853K01 3BSE018103R1 connects serial devices to the AC 800M CEX-Bus through two RS-232C channels. Protocol support depends on controller software and licensing.

Confirm the selected protocol, cable pinout, software support, and project configuration before ordering.

ABB CI853K01 3BSE018103R1 Dual RS-232C Interface Kit Specifications

General

  • ManufacturerABB
  • ModelCI853K01 3BSE018103R1
  • ConditionNew and factory sealed
  • Product FamilyAC 800M Communication Interfaces

Dual RS-232C channel data

  • Channels: Two independent unisolated RS-232C interfaces
  • Connectors: Two RJ45 ports on TP853
  • Speed: 75 to 19200 baud
  • Modem signals: Hayes-compatible control signals are available

Software-selected communication

  • Modbus: Supported through the applicable controller software
  • Siemens 3964R: Available when the documented protocol package is selected
  • COMLI: Supported for documented serial applications
  • Custom protocols: Require the corresponding software and project implementation

Installation and commissioning checks

  • Baseplate: Mount CI853 on TP853 at the AC 800M CEX-Bus
  • Pinout: Verify each RJ45 serial cable against the connected device
  • Isolation: Both RS-232C channels are unisolated
  • Hot swap: Supported according to ABB hardware documentation
Description
The CI853K01 3BSE018103R1 kit combines the CI853 dual RS-232C communication interface with the TP853 baseplate for connection to the AC 800M CEX-Bus.

Its two unisolated serial channels support 75 to 19200 baud. ABB documents Modbus, Siemens 3964R, COMLI, and custom protocol applications determined by controller software and licenses.

CI853 supports hot swap and uses two RJ45 serial connectors on TP853. Confirm the target protocol, cable pinout, software license, and controller project before ordering.
Alternative Names
CI853K01 3BSE018103R1 ABB CI853K01 3BSE018103R1 CI853K01 3BSE018103R1 CI853K01-3BSE018103R1 CI853 3BSE018103R1 ABB AC 800M CI853K01 CI853 Dual RS-232C Interface Kit
Technical notes
CI853K01 is a dual unisolated RS-232C interface kit with TP853. Confirm protocol software, pinout, and controller-project compatibility.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is included in ABB CI853K01 3BSE018103R1?
ABB lists the CI853 interface and TP853 baseplate in the K01 package.
How many serial channels does CI853K01 provide?
CI853 provides two independent RS-232C channels.
Which protocols are documented for CI853 applications?
ABB documents Modbus, Siemens 3964R, COMLI, and custom protocols subject to software support.
What baud-rate range does CI853 support?
ABB specifies 75 to 19200 baud.
Are the CI853 RS-232C channels galvanically isolated?
No. ABB describes both RS-232C channels as unisolated.
Can CI853 be replaced while the controller is powered?
Yes. ABB documentation states that CI853 supports hot swap.
Which physical connectors are provided on TP853?
TP853 provides two RJ45 connectors for the serial channels.
