CI871K01 3BSE056767R1

/ 4.9
1001 reviews | Need a Specific Revision?
CI871K01 3BSE056767R1: PROFINET IO Interface Kit.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CI871K01 3BSE056767R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI871K01 3BSE056767R1

  • Manufacturer:
    ABB
  • Part Number:
    CI871K01 3BSE056767R1
  • Product Family:
    ABB Advant AC800M
  • Product Type:
    PROFINET IO Interface Kit
  • Stock:
    1
  • ABB Article Number:
    3BSE056767R1
  • Protocol:
    PROFINET IO
  • Application:
    PROFINET device integration
  • Package contents:
    CI871 and TP867
  • Physical network:
    Industrial Ethernet
  • Controller connection:
    AC 800M CEX-Bus
  • Weight:
    1.543 lbs (0.7 kg)
  • Estimated shipping dimensions:
    59 x 186 x 127.5 mm (W x H x D)
  • Tariff Code:
    85176200
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications PROFINET IO Roles Device Capacity Media Redundancy

Features:

  • PROFINET IO Interface Kit for ABB AC 800M Communication Interfaces
  • Protocol: PROFINET IO
  • Application: PROFINET device integration
CI871K01 3BSE056767R1 is the ABB PROFINET IO interface kit containing the CI871 communication module and TP867 baseplate.

It provides the AC 800M communication path for supported PROFINET IO devices and their cyclic process data and diagnostics.

Confirm device description files, PROFINET names and addresses, network topology, controller-software support and diagnostic mapping before startup.

Availability for CI871K01 3BSE056767R1 is subject to Apter Power stock and sourcing confirmation.

Verified resources for ABB CI871K01 3BSE056767R1:

ABB CI871K01 3BSE056767R1 Specifications

General

  • ManufacturerABB
  • ModelCI871K01 3BSE056767R1
  • ConditionNew and factory sealed
  • Product FamilyABB AC 800M Communication Interfaces
  • Controller function: CI871 provides the documented PROFINET IO interface for AC 800M.
  • Device data: Configure each supported IO device from its official description file.
  • Cyclic exchange: Verify cyclic input and output data in the controller project.
  • Project scope: Keep configured devices within the supported system release limits.
  • Addressing: Assign unique PROFINET device names and network addresses.
  • Diagnostics: Map device and channel diagnostics required by the application.
  • Topology: Design the industrial Ethernet network for the required availability.
  • Switching: Use compatible managed network equipment where specified.
  • Commissioning: Test cable paths, device recovery, diagnostics, and controller communication.
Description
ABB CI871K01 3BSE056767R1 is the PROFINET IO Interface Kit for ABB AC 800M Communication Interfaces.

ABB CI871K01 provides a PROFINET IO communication interface for connecting supported PROFINET devices to an AC 800M controller.

The kit combines CI871 with TP867 and supports the documented controller-side PROFINET IO application.
Alternative Names
CI871K01 3BSE056767R1 CI871K01 ABB ABB 3BSE056767R1 CI871K01 module 3BSE056767R1 module ABB PROFINET IO Interface Kit CI871K01 ABB AC 800M Communication Interfaces ABB CI871K01 replacement
Technical notes
CI871K01 3BSE056767R1 is the exact ABB article for this PROFINET IO Interface Kit. Confirm system compatibility before ordering.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which industrial Ethernet protocol does CI871K01 support?
It supports PROFINET IO.
What hardware is supplied with CI871?
ABB packages CI871 with the TP867 baseplate.
How are PROFINET devices added to the project?
Use the official device description file and verified device configuration.
Why are PROFINET device names important?
Each device name must uniquely match the engineered network configuration.
What data should be checked at startup?
Verify cyclic I/O, device status, channel diagnostics, and controller alarms.
Is CI871K01 identified by a specific ABB article?
Yes. The official article is 3BSE056767R1.
Can any Ethernet device connect directly?
Only supported PROFINET IO devices engineered for the applicable system release should be used.
What must be planned for a network modification?
Plan addressing, topology, supported devices, controller software, diagnostics, and required network availability.
