CI630 3BSE011000R1

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB CI630 3BSE011000R1 Communication Interface Module is a Advant Fieldbus 100 (AF100) communication interface module designed to establish seamless, deterministic data transmission.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for CI630 3BSE011000R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI630 3BSE011000R1

  • Manufacturer:
    ABB
  • Part Number:
    CI630 3BSE011000R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Communication Interface Module
  • Stock:
    1
  • Communication Protocol:
    AF100 (Advant Fieldbus 100)
  • Network Interface:
    Coaxial Connectors
  • Modem:
    Integrated Modem (Built-in)
  • Function:
    Interface between AF100 network and control system backplane
  • Weight:
    1.4 kg
  • Estimated shipping dimensions:
    4x25.3x27.4cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Communication & Connectivity Firmware & Updates

Features:

  • Interface Between the AF100 Communication Network and ABB Control System Backplane
  • Integrates Coaxial Connector Design with Built-In Modem Functionality
  • Functions in Conjunction with ABB AC 800M Controllers and Advant Master Systems
The ABB CI630 3BSE011000R1 Communication Interface Module serves as the AF100 network interface within ABB control system racks, enabling reliable data communication across all connected modules. It continuously facilitates signal transmission between the AF100 fieldbus network and the rack backplane, converting communication protocols and distributing data to support steady state operation of all monitors and controllers. Seamless network connectivity is standard with the CI630 3BSE011000R1, and its integrated modem design eliminates the need for external communication equipment, ensuring uninterrupted data flow even in demanding industrial environments.

The CI630 3BSE011000R1 provides essential communication functions common to the entire rack, and is a critical component of the control network path, directly affecting the proper, normal operation of the overall automation system. One CI630 3BSE011000R1 communication interface is required per rack to establish AF100 network connectivity. The CI630 3BSE011000R1 occupies a dedicated slot in the rack and is positioned according to the specific ABB system architecture requirements.

For systems requiring enhanced communication reliability, the ABB control platform may support redundant network configurations using additional CI630 3BSE011000R1 modules or complementary communication interfaces. In addition to standard single interface operation, redundant configurations perform automatic switchover between communication paths. The system continually monitors the health of the CI630 3BSE011000R1 and associated network connections.

The CI630 3BSE011000R1 ABB Communication Interface Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB CI630 3BSE011000R1 Communication Interface Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB CI630 3BSE011000R1 Communication Interface Module Specs

General

  • Manufacturer ABB
  • Model CI630 3BSE011000R1
  • Condition New Original ready stock
  • Product Family CI615 3BHT300024R1,CI680 3BSE007364R1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Power Plants: Controls turbines, boilers, and auxiliary plant systems.
  • Pulp & Paper: Manages high-speed, multi-sectional paper machine drives.
  • Chemical Processing: Monitors hazardous zones requiring high network availability.
  • Oil & Gas: Connects distributed offshore platforms and pipeline stations.
  • Metals & Mining: Coordinates continuous feedback loops in rolling mills.
  • Network Protocol: Connects directly to Advant Fieldbus 100 (AF100).
  • Physical Interface: Uses dual coaxial connectors for media segments.
  • Built-in Modem: Features an integrated industrial bus modem.
  • Redundancy Support: Configures dual-cable topologies to prevent network failure.
  • Data Transmission: Uses deterministic cyclic data transport mechanisms.
  • Lifecycle Phase: Maintained under ABB Classic or Limited support lifecycle.
  • Firmware Binding: Tied directly to the host controller system software.
  • Compatibility Check: Requires matching hardware revision suffixes on the PCB.
  • System Integration: Validated for Advant Controller AC110, AC150, and AC160.
Description
The ABB CI630 3BSE011000R1 Communication Interface Module is specifically designed to handle AF100 network communication requirements, addressing the challenge of establishing reliable data transmission in industrial automation environments. The CI630 3BSE011000R1 features coaxial connectors and an integrated modem, eliminating the need for external modem equipment and simplifying communication infrastructure deployment. By incorporating the modem directly into the module, the CI630 3BSE011000R1 resolves connectivity complexities and reduces potential points of failure in industrial communication networks.

This CI630 3BSE011000R1 module is widely applied in process control systems, distributed control systems (DCS), and industrial automation networks where AF100 protocol communication is required. Typical application areas include power generation, oil and gas processing, chemical manufacturing, and pulp and paper industries that depend on robust fieldbus communication. The CI630 3BSE011000R1 ensures stable data exchange between control systems and field devices in these demanding industrial environments.

For installation and integration, the CI630 3BSE011000R1 is designed for seamless mounting within ABB control system racks, with its coaxial interface enabling straightforward connection to AF100 network cables. The integrated modem within the CI630 3BSE011000R1 ensures direct network compatibility without additional hardware configuration, facilitating quick system integration and reducing installation complexity. This plug-and-play communication capability allows the CI630 3BSE011000R1 to be easily incorporated into existing automation architectures.
Alternative Names
CI630 3BSE011000R1 C1630 3BSE011000R1 CI610 3BHT300003R1 CI615 3BHT300024R1 CI680 3BSE007364R1
Technical notes
The ABB CI630 3BSE011000R1 module features integrated coaxial connectors and a built-in modem, allowing controllers to link directly to a coaxial-based AF100 bus network without requiring external transceivers.
