The ABB CI852K01 3BSE018102R1 is a Foundation Fieldbus H1 communication interface module kit designed for the AC 800M controller family within the ABB System 800xA architecture.
Get a quick price for CI852K01 3BSE018102R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for CI852K01 3BSE018102R1

  • Manufacturer:
    ABB
  • Part Number:
    CI852K01 3BSE018102R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Foundaton Fieldbus Module Kit
  • Communication Protocol:
    Foundation Fieldbus H1
  • Diagnostic Integration:
    Built-in FDS-DTM server functionality
  • Diagnostic Communication:
    Ethernet TCP/IP transmission
  • Address Configuration:
    Manual onboard DIP switches
  • Compatible Hardware:
    AC 800M Hardware 4.1 / 5.0 / 5.1
  • Weight:
    0.48 kg
  • Estimated shipping dimensions:
    18.5 cm x 6.5 cm x 12.7 cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Temperature & Humidity Range Firmware & Updates

Features:

  • Foundation Fieldbus H1 Communication Gateway for AC 800M Rack Systems
  • Complete Kit Including CI852 Interface Module and TP852 60mm Baseplate
  • Compatible with AC 800M Hardware Versions 4.1, 5.0 and 5.1 within ABB 800xA Architecture
The CI852K01 3BSE018102R1 serves as the FOUNDATION Fieldbus H1 Interface Kit in an AC 800M rack, enabling reliable bidirectional communication between the AC 800M controller and FOUNDATION Fieldbus H1 field devices. It continuously translates protocol data between the AC 800M backplane and the H1 fieldbus network, supporting real-time process variable exchange, device configuration, and diagnostic information transfer. The CI852K01 3BSE018102R1 contains the CI852 Communication Interface and the TP852 Baseplate (width = 60 mm), which together provide the physical and logical connection point for H1 segments. Seamless integration is standard with the CI852K01 3BSE018102R1, allowing direct attachment of intelligent transmitters, valves, and analyzers to the 800xA control environment without additional protocol converters.

The CI852K01 3BSE018102R1 provides essential communication functions for fieldbus segments in the rack, and is a critical component of the control path, directly affecting the proper, normal operation of the overall fieldbus monitoring and control system. One or more CI852K01 3BSE018102R1 kits may be installed per rack depending on the number of required H1 segments. The CI852K01 3BSE018102R1 occupies a standard module slot together with its TP852 baseplate and is mounted within the AC 800M rack structure.

For multi-segment FOUNDATION Fieldbus H1 applications, the AC 800M system supports installation of additional CI852K01 3BSE018102R1 modules in available rack slots. In addition to single-segment operation, multiple modules execute independent communication handling for each H1 line. Using this method, the control system continually monitors the communication health of each fieldbus segment managed by the CI852K01 3BSE018102R1. If the system detects that a particular H1 segment is no longer providing valid device communication (outside configured response or signal quality thresholds), it will automatically flag the segment diagnostic status and place an event in the System Event List for operator notification.

The CI852K01 3BSE018102R1 ABB Foundaton Fieldbus Module Kit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB CI852K01 3BSE018102R1 Foundaton Fieldbus Module Kit Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB CI852K01 3BSE018102R1 Foundaton Fieldbus Module Kit Specs

General

  • Manufacturer ABB
  • Model CI852K01 3BSE018102R1
  • Condition New Original ready stock
  • Product Family CI852KO1 3BSEO181O2R1,CI840 3BSE022457R1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • ABB System 800xA DCS integration.
  • High-performance AC 800M controller communication interface.
  • Intelligent field instrument link (valves, transmitters, sensors).
  • Decentralized process control loop processing.
  • Industrial process automation (oil, gas, chemical, water treatment).
  • Operating Temperature: 0 to +55 °C (32 to 131 °F).
  • Storage Temperature: -40 to +70 °C (-40 to 158 °F).
  • Relative Humidity: 5% to 95% (non-condensing).
  • Protection Class: IP20 standard casing.
  • Updates are embedded in System 800xA software releases.
  • Managed directly via ABB Control Builder M software.
  • Compatibility verification required on ABB My Control System portal.
  • Flash updates executed during scheduled system maintenance windows.
Description
ABB CI852K01 3BSE018102R1 Foundation Fieldbus H1 Interface Kit is specifically designed to address the critical challenge of seamless communication between ABB's AC 800M controllers and FOUNDATION Fieldbus H1 networks. CI852K01 3BSE018102R1 solves the problem of integrating intelligent field devices into centralized control systems, enabling real-time data exchange and control command transmission across distributed industrial processes. This 3BSE018102R1 kit eliminates communication barriers between legacy control architectures and modern smart instrumentation, providing a robust bridge that ensures reliable fieldbus connectivity in demanding automation environments.

The CI852K01 3BSE018102R1 package includes the CI852 Communication Interface Module and the TP852 Baseplate (width: 60 mm), offering a complete hardware solution for FOUNDATION Fieldbus H1 deployment. The CI852K01 3BSE018102R1 module supports FOUNDATION Fieldbus H1 protocol, which is the internationally recognized standard for process automation fieldbus communication, ensuring interoperability with a wide range of field devices from various manufacturers.

CI852K01 3BSE018102R1 is primarily applied in process industries where reliable fieldbus communication is essential for operational efficiency and safety. Typical application fields include oil and gas production and refining, chemical and petrochemical processing, power generation and distribution, pharmaceutical manufacturing, water and wastewater treatment, and pulp and paper production. In these sectors, 3BSE018102R1 enables the connection of intelligent transmitters, valves, analyzers, and other FOUNDATION Fieldbus devices directly to the ABB 800xA distributed control system, facilitating advanced diagnostics, predictive maintenance, and optimized process control.

For installation and integration, ABB CI852K01 3BSE018102R1 is designed for straightforward mounting on the TP852 baseplate within the AC 800M controller rack. The 3BSE018102R1 module is compatible with AC 800M Hardware versions 4.1, 5.0, and 5.1, ensuring broad system integration flexibility. When deploying CI852K01 3BSE018102R1, engineers should ensure proper grounding and shielding of FOUNDATION Fieldbus H1 cables to maintain signal integrity in electrically noisy industrial environments. The module interfaces seamlessly with ABB's 800xA engineering and operator workplaces, allowing for centralized configuration, commissioning, and monitoring of all connected fieldbus segments.
Alternative Names
CI852K01 3BSE018102R1 CI852KO1 3BSEO181O2R1 CI840 3BSE022457R1 CI810V1 3BSE008584R1 CI810V2 3BSE013224R1 CI854BK01 3BSE069449R1 CI857K01 3BSE018144R1 CI860 CI860K01 3BSE032444R1
Technical notes
The ABB CI852K01 3BSE018102R1 acts as a communication bridge between the central AC 800M controller and Foundation Fieldbus H1 field devices, enabling stable bidirectional data exchange and centralized device management.
