DI810 3BSE008508R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DI810 3BSE008508R1 is a 16-channel S800 digital input module for 24 V DC current-sinking field signals.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for DI810 3BSE008508R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DI810 3BSE008508R1

  • Manufacturer:
    ABB
  • Part Number:
    DI810 3BSE008508R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    S800 I/O 24 V DC Digital Input Module
  • Stock:
    1
  • Signal Specification:
    24 V DC
  • Input Channels:
    16
  • Signal Type:
    Current sinking
  • Isolation:
    Two groups of eight, isolated from ground
  • Filter Times:
    2, 4, 8, or 16 ms
  • Voltage Supervision:
    One input per group
  • Compatible MTUs:
    TU810, TU812, TU814, TU818, TU830, TU833, TU838, TU850
  • Keying Code:
    AA
  • Operating Temperature:
    0 to +55 C
  • Protection Rating:
    IP20
  • Weight:
    0.15 kg
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Input Wiring Voltage Supervision Diagnostics

Features:

  • Sixteen 24 V inputs: The channels accept current-sinking field signals.
  • Two isolated groups: Each eight-channel group has its own voltage supervision.
  • Input indication: Front LEDs show module and channel status.

This configuration is the standard two-group 24 V DC digital input variant, not the redundant SOE-capable DI840.

It converts field contact states and reports both channel condition and supervised process-power status through the S800 system.

Map the two field-power groups, supervision inputs, filter settings, terminal unit, and channel schedule before replacement.

Availability is subject to Apter Power inventory and sourcing confirmation.

DI810 3BSE008508R1 Manuals, Datasheets, and Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

DI810 3BSE008508R1 S800 I/O 24 V DC Digital Input Module Specifications

General

  • ManufacturerABB
  • ModelDI810 3BSE008508R1
  • ConditionNew and factory sealed
  • Product FamilyABB S800 I/O

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Two-group field wiring

  • Group separation: Keep each set of eight channels on its approved field supply.
  • Polarity: Confirm current-sinking signal polarity before energizing.
  • Common conductors: Do not combine returns outside the approved drawing.
  • Channel map: Transfer every field tag to the same channel position.

Process-power monitoring

  • Supervision input: Wire one monitored field supply for each group.
  • Alarm path: Confirm loss of voltage reports through the ModuleBus.
  • Supply test: Test each supervision group separately.
  • Fault isolation: Separate field-power loss from an individual input fault.

Input fault checks

  • No input: Check field power, contact state, polarity, and terminal continuity.
  • Group alarm: Inspect the corresponding supervision input and supply.
  • Intermittent state: Review filter selection, contact bounce, shielding, and grounding.
  • Module warning: Read controller diagnostics before replacing hardware.
Description
DI810 3BSE008508R1 is an ABB S800 I/O digital input module with sixteen 24 V DC current-sinking channels arranged in two isolated groups of eight.

DI810 3BSE008508R1 provides channel status indication and one process-voltage supervision input for each group, allowing the ModuleBus to report loss of the monitored field supply.

Before installing DI810 3BSE008508R1, confirm field polarity, the two voltage groups, supervision wiring, selectable filtering, compatible MTU, mechanical keying, and complete article number.
Alternative Names
DI810 3BSE008508R1 DI810-3BSE008508R1 DI 810 3BSE 008508 R1 DI8103BSE008508R1 ABB DI810 3BSE008508R1 Asea Brown Boveri DI810 ABB S800 I/O DI810 DI810 24 V Digital Input Module
Technical notes
DI810 3BSE008508R1 provides sixteen 24 V DC current-sinking inputs in two isolated groups with separate voltage supervision. Verify both field-power groups and the MTU.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
When is DI810 appropriate for a supervised digital input panel?
Use it for the approved 24 V DC current-sinking design with two groups of eight and group-level voltage supervision.
Which MTU and field-supply details should be checked before ordering DI810?
Match the full MTU label to ABB's compatibility list, then review terminal numbering, field-power distribution, and mechanical keys.
What project information should accompany a DI810 quotation request?
Provide module and MTU nameplates, field voltage, quantity, required condition, channel use, and delivery destination.
What wiring checks are required before energizing DI810 input groups?
Document each group supply, supervision input, returns, channel tags, polarity, and isolation boundary before disconnecting wiring.
What should be checked when several DI810 channels alarm together?
Check the process-voltage supervision and field supply for that group before treating all eight channels as separate failures.
How should DI810 input filtering be tested during commissioning?
Use the approved 2, 4, 8, or 16 ms setting and confirm expected contact transitions without unwanted chatter.
What engineering review is required before replacing another DI model with DI810?
Compare voltage, sinking or sourcing logic, group isolation, supervision, MTU, filtering, channel map, and software configuration.
