DO820 3BSE008514R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DO820 3BSE008514R1 is an eight-channel S800 normally open relay output module with individually isolated channels.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for DO820 3BSE008514R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DO820 3BSE008514R1

  • Manufacturer:
    ABB
  • Part Number:
    DO820 3BSE008514R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    S800 I/O Normally Open Relay Output Module
  • Stock:
    1
  • Signal Specification:
    5-250 V AC/DC, maximum 3 A
  • Output Channels:
    8
  • Signal Type:
    Relay, normally open
  • Isolation:
    Individually isolated channel to channel
  • Relay Supervision:
    24/12 V relay power converter
  • Compatible MTUs:
    TU811, TU813, TU831, TU836, TU837, TU851
  • Keying Code:
    AD
  • Operating Temperature:
    0 to +55 C
  • Protection Rating:
    IP20
  • Weight:
    0.23 kg
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Relay Loads Isolation Terminal Selection

Features:

  • Normally open relays: Eight channels switch the ABB-documented AC or DC load range.
  • Individual isolation: Each output is isolated from the other channels and circuit common.
  • Relay supervision: Internal relay-power monitoring reports a warning when its supply is lost.

This ordering code is the normally open relay variant and must not be confused with DO821 normally closed or transistor DO810 outputs.

The module isolates and switches field loads while reporting output state and relay-power supervision through S800 I/O.

Confirm voltage category, load current and inrush, contact suppression, MTU voltage class, terminal spacing, OSP, and safety isolation before installation.

Availability is subject to Apter Power inventory and sourcing confirmation.
