DSDX180 3BSE003859R1

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DSDX180 3BSE003859R1 is an S100 digital input/output module documented for Advant Master, MOD 300, Compact Product Suite, and 800xA control-system contexts.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for DSDX180 3BSE003859R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSDX180 3BSE003859R1

  • Manufacturer:
    ABB
  • Part Number:
    DSDX180 3BSE003859R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Digital Input/Output Module
  • Stock:
    1
  • Redundancy Capability:
    Optional redundancy supported
  • Channel Indication:
    LED status indication for digital I/O channels
  • Diagnostic Execution:
    At system startup and during normal operation
  • Fault Reporting:
    Module LED indication and system error message
  • Online Module Exchange:
    Supported within the documented S100 I/O system
  • Module Activation:
    A newly inserted S100 I/O module is taken into operation within 10 seconds
  • Supported Control Platforms:
    System 800xA; Advant OCS with Master software; Advant OCS with MOD 300 software; Compact Product Suite
  • Weight:
    0.33 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Module Identity Termination System Context Application
  • ABB lists DSDX180 within the S100 digital input/output product group
  • DSTX180 3BUR980025R1 is separately identified as the connection unit for DSDX180
  • TES3BSE003859R1 is a test-and-inspection service identity rather than a bare hardware order record

DSDX180 3BSE003859R1 is the identity shown on this product page, but the bare order number has not been confirmed in a directly accessible ABB hardware record.

ABB documentation confirms DSDX180 within S100 I/O and separately identifies DSTX180 3BUR980025R1 as its connection unit; the located TES-prefixed record covers test and inspection.

Before ordering or replacement, verify the physical module nameplate, rack position, termination unit, field wiring, channel map, controller support, and required service scope.

Availability, condition, price, and shipping time for DSDX180 3BSE003859R1 are confirmed during quotation.

ABB DSDX180 3BSE003859R1 Digital Input/Output Module Manuals, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • ABB documentation places DSDX180 within the S100 digital input/output group
  • DSTX180 3BUR980025R1 is a separate connection-unit identity and must not be ordered as the module
  • TES3BSE003859R1 identifies test and inspection and does not confirm the bare hardware Product ID
  • ABB identifies DSTX180 as the connection unit used with DSDX180 digital I/O.
  • The documented DSTX180 connection-unit identity is 3BUR980025R1.
  • The connection unit and I/O module remain separate hardware identities in system records.
  • The exact module is categorized under 800xA S100 I/O modules.
  • ABB also lists it within Advant OCS with Master software and MOD 300 software structures.
  • MasterPiece 200 and 200/1 plus Compact Product Suite are included in the documented category paths.
  • Mixed digital input and output service in ABB S100 I/O stations.
  • Legacy Advant Master and MasterPiece digital field-signal interfacing.
  • MOD 300 and Compact Product Suite S100 I/O integration.
Description
DSDX180 3BSE003859R1 is presented on this page as an ABB S100 digital input/output module identity.

ABB documentation confirms DSDX180 within S100 I/O and identifies DSTX180 3BUR980025R1 as its separate connection unit. The located TES3BSE003859R1 record describes test and inspection rather than a bare hardware order entry.

Confirm the complete physical nameplate, rack and controller context, termination unit, field wiring, channel assignment, and required service before replacement.
Alternative Names
DSDX180 3BSE003859R1 DSDX 180 3BSE003859R1 DSDX180 DSDX 180 3BSE003859R1 ABB DSDX180 3BSE003859R1 ABB DSDX 180 3BSE003859R1
Technical notes
DSDX180 3BSE003859R1 must be verified from the physical nameplate; ABB documentation confirms DSDX180 within S100 I/O and DSTX180 3BUR980025R1 as its separate connection unit, while TES3BSE003859R1 denotes test and inspection.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Which connection unit is officially associated with ABB DSDX180 3BSE003859R1?
ABB lists DSTX180, order identity 3BUR980025R1, as the connection unit for DSDX180 digital I/O. Confirm that the installed termination hardware and cable path match the system drawings.
What must be checked when ABB DSDX180 3BSE003859R1 is used in an 800xA system retaining S100 I/O?
Confirm the retained S100 rack arrangement, DSTX180 connection unit, controller interface, channel map, field wiring and project configuration. ABB’s category listing establishes system context, not automatic interchangeability between installations.
How should optional redundancy be considered when replacing ABB DSDX180 3BSE003859R1?
Confirm whether the installed S100 configuration uses the optional redundant arrangement, then match the module position, companion hardware, DSTX180 termination, controller configuration and field wiring before commissioning.
Which field details remain essential when replacing ABB DSDX180 3BSE003859R1?
Verify the actual termination assembly, input and output channel map, external voltage sources, commons, output loads, rack address, connector orientation, and controller configuration from the installed system documentation.
Why can a field-signal problem remain after ABB DSDX180 3BSE003859R1 passes a module check?
The fault may be outside the module in the DSTX180 connection unit, field supply, common, connector, wiring or saved channel assignment. Test the complete signal path rather than the board alone.
What evidence should accompany an order for ABB DSDX180 3BSE003859R1?
Provide clear photographs of the complete module nameplate and connectors, the rack position, DSTX180 connection-unit identity, controller platform, channel map, required condition, and the applicable project or wiring reference. Do not substitute the TES3BSE003859R1 test-and-inspection identity for the hardware catalog number.
How should ABB DSDX180 3BSE003859R1 and DSTX180 be distinguished in maintenance records?
Record DSDX180 3BSE003859R1 as the digital I/O module and DSTX180 3BUR980025R1 as its documented connection unit. Keeping the two identities separate prevents the wrong assembly from being requested or serviced.
