ABB PM253V01 is a 1 MB Advant Controller 250 processor unit with SattBus communication and floating-point support.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for PM253V01
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PM253V01

  • Manufacturer:
    ABB
  • Part Number:
    PM253V01
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Advant Controller 250 Processor Unit
  • Stock:
    1
  • Controller platform:
    Advant Controller 250
  • Processor:
    Motorola MC68020
  • Clock frequency:
    16.7 MHz
  • RAM:
    1 MB
  • I/O capacity:
    32 I/O units
  • Power supply:
    24 V DC; 19.2–30 V DC including ripple
  • Current consumption:
    Maximum 0.6 A
  • Serial channels:
    Two RS-232 channels
  • Serial distance:
    Maximum 15 m
  • Backplane key code:
    5
  • Protection:
    IP20
  • Operating temperature:
    +5 to +55 °C
  • Storage temperature:
    -25 to +70 °C
  • Dimensions:
    4.5 × 16.3 × 9.1 cm
  • Weight:
    0.43 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Memory and Project Serial Channels Processor Service Application
  • One-megabyte processor unit for Advant Controller 250
  • Motorola MC68020 CPU operating at 16.7 MHz
  • SattBus plus two configurable RS-232 channels

PM253V01 provides the processing, memory and real-time control resources for a modular Advant Controller 250 installation.

Its 1 MB memory, serial channel roles and SattBus configuration must fit the saved control application rather than only the physical backplane.

Back up the project and record battery, keying and communication settings before replacing the processor.

Availability, condition, price, and shipping time for PM253V01 are confirmed during quotation.

ABB PM253V01 Advant Controller 250 Processor Unit Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm the application fits the 1 MB PM253V01 memory class.
  • Retain the complete controller project and parameter archive.
  • Compare the configured I/O count with the documented 32-unit capacity.
  • Record both RS-232 channel roles before replacement.
  • Preserve baud rate, protocol and cable assignments for each channel.
  • Keep every serial run within the documented installation limit.
  • Verify backplane key code 5 before inserting the module.
  • Check memory-backup battery condition and replacement interval.
  • Validate SattBus, serial communication and I/O after project restoration.
  • Advant Controller 250 sequence control
  • Advant Controller 250 continuous process control
  • SattBus-connected modular automation systems
Description
ABB PM253V01 is the processor unit used in modular Advant Controller 250 configurations.

It combines a 16.7 MHz Motorola MC68020 processor with 1 MB of memory, SattBus communication and two configurable RS-232 channels.

Processor replacement requires the saved control project, battery condition, module keying and serial-channel configuration to be recorded before removal.
Alternative Names
PM253V01 ABB PM253V01 Advant Controller 250 PM253V01 PM253V01 Controller
Technical notes
ABB PM253V01 requires the 1 MB project fit, key code 5, 24 V DC supply, battery condition, SattBus setup and both RS-232 channel configurations to be preserved.
