    Apter Power supplies completely regulation-verified, out-of-production energizing units to stabilize your rail-mounted logic nests and insulate your central processors from catastrophic dark-start faults and logic loop collapses.

SA811F 3BDH000013R1

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB SA811F 3BDH000013R1 is a power supply module specifically engineered to provide stable and reliable DC power to the ABB Freelance AC 800F control system.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for SA811F 3BDH000013R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SA811F 3BDH000013R1

  • Manufacturer:
    ABB
  • Part Number:
    SA811F 3BDH000013R1
  • Product Family:
    ABB Advant OCS and Advant-800xA
  • Product Type:
    Power Supply Module
  • Stock:
    1
  • Input Voltage:
    115 / 230 VAC (auto-adjusting, self-selecting)
  • Input Voltage Permissible Range:
    90 – 260 VAC
  • Input Frequency:
    50 / 60 Hz (47 – 63 Hz)
  • Input Current at Nominal Load:
    230 VAC: 275 mA; 115 VAC: 541 mA
  • Rated Input Power:
    63 VA
  • Total Output Power:
    Max. 35 W
  • Weight:
    0.46 kg
  • Estimated shipping dimensions:
    15.5x6.7x15.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Installation & Integration Monitoring & Control

Features:

  • Dual-voltage AC input support with automatic self-selection for the ABB Freelance AC 800F control rack
  • Integrated 5 VDC and 3.3 VDC output channels delivering regulated power to all CPU and I/O modules
  • Advanced power-fail prediction circuitry with sustained overload and short-circuit protection
The SA811F 3BDH000013R1 serves as the primary AC power supply module within the ABB Freelance AC 800F distributed control system, converting incoming universal AC power (90–260 VAC, 47–63 Hz) into precisely regulated dual DC outputs. It continuously supplies 5 VDC and 3.3 VDC through the rack backplane to ensure steady-state operation of the PM 802F or PM 803F processor modules and associated I/O units. The SA811F 3BDH000013R1 incorporates enhanced power-fail prediction circuitry that generates a shutdown warning signal when mains interruption exceeds 5 milliseconds, while internal energy storage maintains output voltage within tolerance for at least 15 milliseconds after the warning, allowing the system to manage total mains drops of up to 20 milliseconds without operational disruption.

The SA811F 3BDH000013R1 provides essential power functions common to the entire AC 800F rack and represents a critical component of the control path, directly affecting the proper, normal operation of the overall automation system. One SA811F 3BDH000013R1 power supply is required per rack, occupying a dedicated slot with secure DIN rail or panel mounting. The module features front-panel LED indicators that display both power supply status and the operating condition of the AC 800F controller, enabling rapid visual diagnostics during commissioning and maintenance activities.

The SA811F 3BDH000013R1 includes comprehensive internal protection mechanisms to ensure long-term reliability in harsh industrial environments. Its output is fully electrically isolated from the AC input, and the module delivers current-limited operation with automatic recovery from overload and sustained short-circuit conditions. A subminiature 2.5 AT fuse provides additional input-side protection, while the unit’s automatic return-to-normal behavior eliminates the need for manual intervention after transient fault events, minimizing system downtime and maintenance requirements.

The SA811F 3BDH000013R1 ABB Power Supply Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB SA811F 3BDH000013R1 Power Supply Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB SA811F 3BDH000013R1 Power Supply Module Specs

General

  • Manufacturer ABB
  • Model SA811F 3BDH000013R1
  • Condition New Original ready stock
  • Product Family SA610 3BHT300019R1,SA801F 3BDH000011R1
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Petrochemical & Refining: Powers critical pipelines and safety interlock systems.
  • Power Generation: Stabilizes grid fluctuations for processing units.
  • Intelligent Manufacturing: Delivers isolated power to motion controllers and sensors.
  • Batch Chemical Processing: Ensures uninterrupted execution of automated formulas.
  • Dual-Voltage Input: Supports wide-range inputs of 115V AC or 230V AC.
  • Modular Form Factor: Slides directly into standard AC 800F slots.
  • Thermal Layout: Designed for optimal convection cooling within enclosed panels.
  • System Retrofitting: Integrates directly with legacy and newer hardware variants.
  • Power Conditioning: Provides clean, ripple-free energy to prevent data corruption.
  • Parametric Tracking: Oversees system temperature, load fluctuations, and voltage limits.
  • Protocol Support: Connects to frameworks via standard Modbus RTU channels.
  • Cloud Integration: Links to ABB Ability for predictive analytics and reporting.
Description
The ABB SA811F 3BDH000013R1 Power Supply Module is a robust and reliable power supply unit designed specifically for industrial automation and control systems. Engineered to handle demanding operational environments, the SA811F 3BDH000013R1 supports dual voltage input of 115/230 VAC, providing flexibility for global deployment across different electrical standards. This module is built to deliver consistent and stable DC power to critical control components, ensuring uninterrupted system performance even under fluctuating input conditions.

The SA811F 3BDH000013R1 is specifically designed to address the challenge of power instability in industrial settings, where voltage fluctuations and electrical noise can compromise system reliability. By incorporating advanced power regulation and protection mechanisms, the SA811F 3BDH000013R1 effectively eliminates downtime risks caused by power supply failures, safeguarding sensitive control logic and I/O modules from electrical disturbances. This makes the SA811F 3BDH000013R1 an essential component for maintaining continuous operations in mission-critical applications.

The SA811F 3BDH000013R1 finds extensive application across multiple industrial sectors, including process control, manufacturing automation, power generation, and infrastructure management. It is commonly deployed in chemical plants, oil and gas facilities, water treatment systems, and discrete manufacturing lines where reliable power delivery is paramount. The SA811F 3BDH000013R1 is also widely utilized in building automation systems and material handling operations, supporting the stable operation of PLCs, distributed control systems (DCS), and field instrumentation networks.
Alternative Names
SA811F 3BDH000013R1 SA 811F 3BDH000013R1 SA167 3BSE003390R1 SA168 3BSE003389R1 SA610 3BHT300019R1 SA801F 3BDH000011R1
Technical notes
The ABB SA811F 3BDH000013R1 power module serves as a critical infrastructure component, converting standard 115/230 VAC input AC power into the precise low-voltage DC current required by the central processing unit.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the primary function of the ABB SA811F 3BDH000013R1?
The ABB SA811F 3BDH000013R1 is a power supply module designed for the AC 800F control system. Its primary function is to provide stable and reliable power to controller components, ensuring continuous operation of industrial automation processes.
Why is stable power supply important in industrial automation systems?
Industrial control systems rely on uninterrupted power to execute process logic, maintain communication with field devices, and store operational data. Even brief power disturbances can disrupt production, trigger alarms, or lead to unexpected equipment shutdowns.
How does the ABB SA811F 3BDH000013R1 help protect control systems from power fluctuations?
The module acts as a dependable power interface between the electrical network and the controller system. It helps reduce the impact of voltage variations and short-term power disturbances, improving overall system reliability and operational stability.
Can the ABB SA811F 3BDH000013R1 reduce production downtime?
Yes. By providing consistent power to critical controller hardware, the module helps prevent unexpected controller resets and operational interruptions, reducing the likelihood of costly production downtime.
