YPM102E YT204001-FL

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB YPM102E YT204001-FL is a analog output module engineered for legacy distributed control systems (DCS) and drive architectures, delivering ultra-precise loop control to critical field actuators and regulation systems.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for YPM102E YT204001-FL
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for YPM102E YT204001-FL

  • Manufacturer:
    ABB
  • Part Number:
    YPM102E YT204001-FL
  • Product Family:
    ABB Drives
  • Product Type:
    Analog Output Module
  • Stock:
    2
  • Operating Voltage (Nominal):
    24 VDC (±10% System Backplane Supply)
  • Power Consumption:
    < 1.5 W
  • Hardware Core:
    Dedicated Signal Processing Core
  • Signal Conditioning:
    Onboard Integrated Resistive Network
  • Diagnostic Indicators:
    Board-Mounted Status LED Arrays
  • Operating Temperature Range:
    0°C to +55°C (32°F to 131°F)
  • Storage Temperature Range:
    -40°C to +70°C (-40°F to 158°F)
  • Relative Humidity:
    5% to 95% (Non-condensing)
  • Mounting Configuration:
    Rack/Chassis Stand-off Mounting
  • Weight:
    0.08 kg
  • Estimated shipping dimensions:
    14.8x7.5x1.2cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Firmware & Updates Safety & Compliance

Features:

  • Precision Onboard Resistive Network Conditioning
  • Instantaneous Component-Level LED Visual Diagnostics
  • Robust Plug-and-Play Legacy System Extension
The ABB YPM102E YT204001-FL features a highly stable, integrated resistive network layout that eliminates signal distortion and handles linear digital-to-analog tracking with exceptional precision across fluctuating ambient conditions. This high-grade hardware filter guarantees that analog control values remain accurate over long cable runs, keeping final control elements perfectly responsive.

Outfitted with board-mounted diagnostic status LED indicators, the ABB YPM102E YT204001-FL delivers real-time visualization of output states and backplane power rail tracking directly to the factory floor. This diagnostic transparency allows maintenance teams to distinguish system-level anomalies from module faults immediately without connecting external engineering tools.

Built specifically for drop-in retrofits within established control infrastructures, the mechanical stand-off mount profile of the ABB YPM102E YT204001-FL aligns perfectly with legacy ABB chassis slots. This hardware alignment guarantees seamless drop-in deployment, helping industrial plants bypass engineering redesign costs and eliminate long maintenance outages.

The YPM102E YT204001-FL ABB Analog Output Module may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB YPM102E YT204001-FL Analog Output Module Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB YPM102E YT204001-FL Analog Output Module

General

  • Manufacturer ABB
  • Model YPM102E YT204001-FL
  • Condition New Original ready stock
  • Product Family YPM106E YT204001-FN,YPM102A YT204001-AA,YPH105E YT204001-FC
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Metallurgical & Rolling Mill Controls: Deployed in hot and cold rolling mills running vintage ABB drives to manage real-time motor speed references and tension control loops, maintaining uniform sheet thickness.
  • Pulp & Paper Processing Lines: Integrates with sectional paper machine drives to manage web tension and speed synchronization, preventing web breaks and reducing scrap material.
  • Marine Automation & Propulsion Systems: Installed within main propulsion control cabinets and onboard generation setups to convert governing commands into precise thruster and fuel valve adjustments.
  • Chemical & Petrochemical Plant Infrastructure: Used to control critical modulating valves, damper positioners, and dosing pumps within legacy DCS control setups, ensuring stable process conditions.
  • Hardware-Driven Parameter Configurations: The module relies on firmware managed by the primary controller card, meaning parameter settings, span limits, and fault modes are assigned over the backplane during startup.
  • Zero-Flash Lifecycle Architecture: Designed with hard-coded logic paths that remove the risk of firmware corruption from field updates, ensuring predictable operation over decades.
  • Controller Software Compatibility: Fully compatible with original ABB system software tools (such as early-generation engineering environments), allowing it to read and execute channel configurations without patch upgrades.
  • Seamless Hot-Swap & Warm-Start Alignment: Supports the storage and automated reload of system parameters, letting a replacement module download its operational profile from the rack master instantly upon installation.
  • Galvanic Isolation Protection: Features rugged component isolation boundaries that protect delicate internal system processors from dangerous voltage spikes and ground loops originating in the field.
  • Industrial CE & EMC Directive Conformity: Built in line with early European industrial standards, offering strong resistance against radio frequency interference and electrostatic discharges.
  • RoHS Directive Alignment for Global Shipping: Refurbished and surplus units are thoroughly inspected and cleaned to meet environmental shipping compliance, ensuring smooth customs processing at international boundaries.
  • Fail-Safe Output State Mapping: Configured via the host system to hold its last valid output value or drop to a safe zero state if a backplane communication failure occurs, protecting downstream mechanical equipment.
Description
The ABB YPM102E YT204001-FL functions as a highly accurate channel for converting digital processor commands into smooth, low-noise analog steering signals. Outfitted with an expertly tuned integrated resistive network, this module minimizes thermal drift and cross-channel interference, allowing process engineers to manage positioners, flow valves, and variable-speed speed regulators with exceptional linearity. By maintaining razor-sharp control loops, it significantly reduces mechanical wear on field hardware and optimizes final product quality.

As asset life-cycle management becomes a primary priority for capital-intensive industries, the ABB YPM102E YT204001-FL provides a seamless, risk-free mitigation path against system obsolescence. Designed as a direct fit for mature ABB DCS chassis and drive control panels, it removes the need for highly expensive, disruptive system overhauls or extensive software re-engineering. This plug-and-play hardware profile ensures that mature control topologies remain fully operational without altering existing application logic or field terminal footprints.

Engineered to withstand the taxing electrical and thermal stress of heavy processing zones, the board-level architecture of the ABB YPM102E YT204001-FL features reinforced components and high-grade soldering substrates. Onboard diagnostic status LED indicators provide real-time, visual confirmation of loop health and internal processing states, empowering local technicians to execute instant fault localization. This visual troubleshooting boundary shortens Mean Time to Repair (MTTR) and minimizes costly unscheduled downtime in continuous production lines.
