    Elevate your drive system intelligence with this original ABB ZCU-12 control unit, sourced by Apter Power for high-performance motor regulation and reliable operation.

ZCU-12 3AXD50000005751

/ 4.9
1001 reviews | Need a Specific Revision?
The ABB ZCU-12 3AXD50000005751 is a high-performance Zone Control Unit designed for seamless integration within ABB's distributed drive and automation systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for ZCU-12 3AXD50000005751
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ZCU-12 3AXD50000005751

  • Manufacturer:
    ABB
  • Part Number:
    ZCU-12 3AXD50000005751
  • Product Family:
    ABB Drives
  • Product Type:
    Control Unit
  • Stock:
    2
  • Rated:
    24 V DC
  • Inrush:
    ≤ 2 A, 5 ms
  • Analog inputs:
    3 × ±10 V / 0…20 mA
  • Digital inputs:
    8 × 24 V DC
  • Operating temp:
    -25 … +60 °C (up to 70 °C with derating)
  • Storage temp:
    -40 … +85 °C
  • Humidity:
    5 … 95 % RH, non-condensing, class 3K3
  • Weight:
    0.38 kg
  • Estimated shipping dimensions:
    35x11.7x3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Application Firmware & Updates Configuration

Features:

  • Serves as the primary control unit for high-performance industrial drives, managing motor control and I/O processing
  • Provides extensive digital and analog I/O, relay outputs, and supports Modbus/EtherCAT protocols
  • Features a compact, modular architecture for flexible system integration and compatibility with ZMU memory units
The ZCU-12 3AXD50000005751 functions as the central processing unit for ABB's ACS880 drive series . It is designed to execute the primary control program for advanced motor control applications, including precise speed, torque, and position regulation . This control unit manages all internal calculations and logic, ensuring high-performance operation for demanding industrial tasks. Its robust hardware and real-time processing capabilities make it a reliable choice for applications requiring dynamic and accurate motor control.

The ZCU-12 3AXD50000005751 offers a full suite of I/O connections, including digital inputs/outputs and relay outputs for flexible process integration . It supports a wide range of communication protocols, such as Modbus RTU and EtherCAT, facilitating seamless connection to controllers and field devices . This comprehensive interface allows the control unit to gather sensor data and send control commands to actuators in real-time, making it a vital component for building complex and integrated automation systems.

The ZCU-12 3AXD50000005751 features a modular and compact design that simplifies installation and maintenance . Its compatibility with specific ZMU memory units ensures the unit can be updated with the latest firmware and adapted to different application needs . This modularity allows for easy integration into new or existing control cabinets and supports hot-swappable firmware updates to minimize downtime . This design approach provides a scalable and future-proof solution for industrial control requirements.

The ZCU-12 3AXD50000005751 ABB Control Unit may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
ABB ZCU-12 3AXD50000005751 Control Unit Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
ABB ZCU-12 3AXD50000005751 Control Unit Specs

General

  • Manufacturer ABB
  • Model ZCU-12 3AXD50000005751
  • Condition New Original ready stock
  • Product Family ZCU-14 3AXD50000005164,ZCU-12L 3AXD50000794058
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Heavy Material Handling & Cranes: Manages torque proving, mechanical brake control, and anti-sway logic in tower cranes, winches, and heavy-duty hoists.
  • Pumps, Fans, & Compressors: Optimizes energy consumption and pressure regulation in high-capacity water treatment pumps, multi-pump systems, and large HVAC air handlers.
  • Extruders, Mixers, & Conveyors: Provides precise speed and tension control in continuous manufacturing lines, such as plastics extrusion, rubber mixing, and mining conveyor networks.
  • Primary System Compatibility: It is the native main control unit for the ABB ACS880 drive series (specifically frame sizes R6 through R9, and various multidrive configurations). It handles ABB’s proprietary Direct Torque Control (DTC) technology, enabling superior motor performance without requiring encoder feedback in most setups.
  • Application Firmware Loading: The control unit features a dedicated ZMU-02 Memory Unit slot. The firmware is physically stored on this removable memory card. Swapping the ZMU-02 automatically transfers the drive parameters and firmware version to a new ZCU-12 board, minimizing downtime during hardware replacements.
  • Updating Procedures: Firmware updates and flashes are executed using ABB Drive Composer Pro software via a PC connection (utilizing an assistant control panel via USB or an Ethernet tool like NETA-21). Updates are critical for unlocking newer safety parameters, optimizing DTC algorithms, and patching network communication bugs.
  • Drive Composer Toolchain: System configuration is primarily handled via Drive Composer (Entry/Pro). This software allows technicians to perform commissioning, tune PID loops, monitor real-time tracking signals via high-speed data loggers, and back up user parameters.
  • IEC 61131-3 Programming (Drive Application Programming): For highly complex automation, developers can write customized code in structured text or ladder logic using Drive Application Builder (based on CoDeSys), effectively allowing the ZCU-12 to function as a localized PLC.
  • Fieldbus Interoperability: The board features embedded Drive-to-Drive (D2D) communication links and slots for option modules to bridge seamlessly with major protocols like PROFINET (FENA-21/FPNO-21), EtherNet/IP, Modbus TCP, and CANopen.
Description
The ABB ZCU-12 3AXD50000005751 is a high-performance Zone Control Unit designed for seamless integration within ABB's distributed drive and automation systems. Engineered for industrial applications, it provides precise control, monitoring, and coordination of multiple drive zones, ensuring optimized performance and reliability across complex machinery setups. The unit features robust construction suitable for harsh industrial environments, offering resistance to vibration, temperature fluctuations, and electrical disturbances.

With advanced communication interfaces, the ZCU-12 3AXD50000005751 enables real-time data exchange between connected drives, facilitating efficient system diagnostics, predictive maintenance, and enhanced operational safety. Ideal for applications in material handling, manufacturing, and large-scale automation systems, this unit ensures high availability, improved energy efficiency, and consistent performance, making it a critical component for modern industrial automation solutions.
Alternative Names
ZCU-12 3AXD50000005751 ZCU-I2 3AXD5000000575I ZCU12 3AXD50000005751 ZCU-12L 3AXD50000794058 ZCU-14 3AXD50000005164 NDSC-02 3ADT220090R0039 NI0C01 3BSE005735R1
Technical notes
The ABB ZCU-12 (3AXD50000005751) is a high-performance control unit engineered for ACS880 drives, enabling precise motor control with firmware support for AINLX version 1.63 or higher. It serves as the intelligent core to optimize adaptive multi-axis motion and real-time process monitoring in demanding industrial setups.
