ZINT-7B1C

/ 4.9
1001 reviews | Need a Specific Revision?
ABB ZINT-7B1C is the main circuit board of the ACS880 drive, supporting 24 V DC input and a wide range of industrial operating temperatures and humidity.
Get a quick price for ZINT-7B1C
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for ZINT-7B1C

  • Manufacturer:
    ABB
  • Part Number:
    ZINT-7B1C
  • Product Family:
    ABB Drives
  • Product Type:
    3AUA0000119630
  • Series:
    ACS880
  • Input Voltage Range:
    24 V DC
  • Operating Temperature:
    -25°C to +70°C
  • Storage Temperature:
    -40°C to +85°C
  • Humidity:
    5% to 95% (non-condensing)
  • Weight:
    0.15 kg
  • Estimated shipping dimensions:
    19.8x12.9x3cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.
Description
As a key main circuit board in the ACS880 series, the ABB ZINT-7B1C is designed as the central control and power distribution hub of the drive system, ensuring seamless coordination between different functional modules. Its fixed 24V DC input voltage design simplifies power supply configuration, eliminates compatibility issues caused by voltage fluctuations, and provides a stable power foundation for the entire drive system. This standardized voltage input also makes the board easy to integrate into existing ACS880 systems, reducing the complexity of field installation and commissioning.

A key design advantage of the ABB ZINT-7B1C main board is its environmental adaptability, with an operating temperature range of -25°C to +70°C. This wide temperature tolerance range enables reliable operation in environments where equipment generates significant heat during continuous operation, such as cold industrial storage areas and high-temperature production workshops. The board also has a wider storage temperature range, from -40°C to +85°C, ensuring component integrity during long-term storage or inter-regional transportation, even under extreme climatic conditions.

The adaptability to humid environments further enhances the versatility of the ABB ZINT-7B1C main board. This circuit board operates stably within a humidity range of 5% to 95% without condensation, which is crucial for applications in industries with high air humidity, such as food processing, textile manufacturing, and chemical production. Its robust design effectively resists corrosion and short-circuit risks from humid air, thereby extending its service life and reducing maintenance and replacement frequency. As a core component of the ACS880 series, it plays a vital role in ensuring the stable and efficient operation of high-performance drive systems in various industrial scenarios.
Alternative Names
Z1NT-7B1C ZINT-7BIC ZINT-781C ZINT7B1C Z1NT7B1C ZINT7BIC ZINT781C
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the input voltage range of the ABB ZINT-7B1C main circuit board?
It can operate within a stable 24V DC input voltage range to ensure reliable performance.
What is the operating temperature range of the ABB ZINT-7B1C main circuit board?
In industrial environments, it can operate stably within a temperature range of -25°C to +70°C.
How long will it take to receive the ABB ZINT-7B1C circuit board after placing an order?
The circuit board is in stock, and we can arrange shipment within 2-3 business days after order confirmation.
What is the suitable humidity for the ABB ZINT-7B1C main circuit board?
It operates normally in non-condensing humidity ranges from 5% to 95%, resisting humid workshop environments.
Is the ABB ZINT-7B1C main circuit board a brand new original product?
Yes, every product we provide is 100% brand new and original.
