1SDA083360R1

/ 4.9
1001 reviews | Need a Specific Revision?
1SDA083360R1 is an ABB Ekip UP Protect unit for low voltage feeder and switchgear protection using current, voltage, frequency, and power measurements.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1SDA083360R1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1SDA083360R1

  • Manufacturer:
    ABB
  • Part Number:
    1SDA083360R1
  • Product Family:
    ABB Electrical
  • Product Type:
    Ekip UP Protect low voltage digital protection unit
  • Stock:
    1
  • Protection role:
    feeder and low voltage distribution protection
  • Operating voltage:
    up to 1150 V
  • Operating current:
    100 to 6300 A
  • Operating frequency:
    50 to 60 Hz
  • Operating temperature:
    minus 25 to plus 70 degrees C; up to plus 60 degrees C under UL conditions
  • Protection degree:
    IP40; IP54 with an external cover
  • Standards:
    IEC 60255, UL 508, CSA C22.2 No. 14-13
  • Mounting:
    DIN rail or door mounted
  • Programmable contacts:
    four I/O contacts
  • Connectivity:
    up to eight field bus protocols plus a property bus
  • Dimensions:
    29.58 × 10.95 × 8.62 cm
  • Weight:
    1.15 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Protection functions Mounting and integration Use cases Application
  • ABB identifies 1SDA083360R1 as the Ekip UP Protect version.
  • It provides current-, voltage-, frequency- and power-based protection for low-voltage distribution.
  • The platform supports DIN-rail or door mounting with modular sensors, signalling and communications.

1SDA083360R1 is the ABB Ekip UP Protect low-voltage digital protection unit.

Current ABB catalog data specifies operation up to 1150 V, 100 to 4000 A and 50 to 60 Hz, with the selected sensors and rating plug determining the protected circuit range.

Before installation or replacement, verify the current-sensor set, rating plug, supply and measuring modules, communication cartridges, switchgear interface, mounting and saved protection settings.

Availability, condition, price, and shipping time for 1SDA083360R1 are confirmed during quotation.

1SDA083360R1 Ekip UP Protect Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, and related items are not included unless listed in the stock item description. All prices are shown in USD.

  • ABB documents feeder protection based on current, voltage, frequency, and power.
  • Protect supports switch disconnectors and breakers with simple trip units.
  • Optional Ekip software modules can add load shedding, synchrocheck, and interface protection.
  • The unit can be DIN rail mounted or door mounted.
  • Current sensors connect to dedicated numbered sockets and must match the plant current range.
  • The terminal box accepts supply, communication, signalling, and synchrocheck modules.
  • Industrial and utility distribution and generation plants.
  • Marine switchgear electronic retrofit.
  • Microgrid protection for data centers, hospitals, and solar factories.
  • Industrial and utility power distribution protection.
  • Marine switchgear electronic retrofit.
  • Microgrid protection and continuity applications.
Description
1SDA083360R1 is an Ekip UP Protect low voltage digital protection unit for the ABB Ekip UP product platform.

The Protect version applies current, voltage, frequency, and power based protection to feeders and switchgear while retaining Ekip UP measurement, connectivity, programmable contacts, and modular accessories.

Before installation or replacement, confirm the complete catalog number, current sensors, rating plug, supply module, communication cartridges, switchgear interface, wiring, mounting, and saved protection settings.
Alternative Names
1SDA083360R1 ABB 1SDA083360R1 ABB Ekip UP Protect 1SDA083360R1 Ekip UP Protect 1SDA083360R1 Ekip UP 1SDA083360R1 1SDA083360 R1
Technical notes
1SDA083360R1 is the Ekip UP Protect order code. Match sensors, rating plug, supply, communication options, and switchgear mounting before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How do I distinguish ABB 1SDA083360R1 from the other Ekip UP versions when planning a retrofit?
ABB identifies this order code as Ekip UP Protect. Confirm the protection role, sensor set, rating plug, switchgear interface, and required trip functions before ordering.
Which current sensors and rating plug should be selected for ABB 1SDA083360R1?
Select the ABB sensor range and rating plug that cover the installation current and pole arrangement, then verify compatibility with the Ekip UP configuration.
Can ABB 1SDA083360R1 be added to an existing breaker or switch disconnector?
It can support documented Ekip UP retrofit applications, but the mechanical interface, available switchgear space, sensor routing, and wiring must be checked first.
What communication architecture should be reviewed before selecting ABB 1SDA083360R1?
Review the required field bus or property bus, gateway and cybersecurity requirements, optional communication cartridges, endpoint compatibility, and the saved network configuration.
How should ABB 1SDA083360R1 be commissioned?
Confirm sensor phase assignment, rating plug, voltage wiring, protection settings, trip outputs, and coordination with the upstream and downstream protection scheme.
What accessories are normally associated with ABB 1SDA083360R1?
The ABB documentation describes sensors and cabling, insertion bridge, supply cartridge, measurement module, and programmable contacts. Verify the actual quotation scope.
What should be recorded when replacing ABB 1SDA083360R1?
Record the sensor type, rating plug, wiring, communication cartridges, protection settings, trip tests, and switchgear mounting details.
