PP836A 3BSE042237R2

/ 4.9
1001 reviews | Need a Specific Revision?
ABB PP836A 3BSE042237R2 is a 6.5-inch Panel 800 operator panel with 640 × 480 color display, Ethernet, serial interfaces and USB connectivity.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for PP836A 3BSE042237R2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for PP836A 3BSE042237R2

  • Manufacturer:
    ABB
  • Part Number:
    PP836A 3BSE042237R2
  • Product Family:
    ABB Operator Panel
  • Product Type:
    Panel 800 operator panel
  • Stock:
    1
  • Panel family:
    Panel 800
  • Display size:
    6.5 inch TFT-LCD
  • Display resolution:
    640 × 480 pixels
  • Display colors:
    64K colors
  • Backlight:
    LED, >25,000 h at 25 °C
  • Active display area:
    131.5 × 98.6 mm
  • Front keyboard:
    Membrane switch keyboard with metal domes
  • Keyboard life:
    1 million operations
  • Front material:
    Autotex F157 surface
  • Rear material:
    Powder-coated aluminum
  • Front protection:
    IP66
  • Rear protection:
    IP20
  • Ethernet:
    RJ45 interface
  • Serial interface 1:
    RS422/RS485, 25-pin D-sub female
  • Serial interface 2:
    RS232C, 9-pin D-sub male
  • USB host:
    Type A, USB 1.1, max 500 mA
  • USB device:
    Type B
  • Memory slot:
    CompactFlash Type I/II
  • Application flash:
    12 MB
  • RTC accuracy:
    ±20 ppm, max 1 min/month at 25 °C
  • Power supply:
    +24 V DC, 20–30 V DC
  • Power consumption:
    0.4 A normal; 0.9 A maximum
  • Operating temperature:
    0–50 °C vertical; 0–40 °C horizontal
  • Storage temperature:
    −20 to 70 °C
  • Humidity:
    5–85% RH non-condensing
  • Fuse:
    3.15 AT 5 × 20 mm internal DC fuse
  • Compliance:
    CE, UL/cUL, DNV, NEMA 4x indoor
  • Weight:
    3.09 lbs (1.4 kg)
  • Estimated shipping dimensions:
    285 × 177 × 6 mm front panel; mounting depth 56 mm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration Temperature Certifications

Features:

  • 6.5-inch TFT operator display with 640 × 480 color resolution.
  • Ethernet, serial, USB and CompactFlash interfaces support Panel 800 integration.
  • IP66 front protection is paired with an aluminum rear housing.
ABB PP836A 3BSE042237R2 combines a color operator display with membrane controls for Panel 800 visualisation and command tasks.

The front interface supports operator views while Ethernet, serial and USB ports provide practical links to the configured automation project.

Match the panel cut-out, 24 V DC source and Panel Builder 800 project before installation; keep the rear IP20 side protected inside the enclosure.

The PP836A remains a Panel 800 operator-panel configuration; Apter Power supports quotation and project-matching checks.
Verified resources for ABB PP836A 3BSE042237R2: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Operator visualisation for ABB Panel 800 automation projects.
  • Local command and status presentation in industrial enclosures.
  • Panel-mounted HMI duties where Ethernet and serial links are required.
  • Panel Builder 800 is the engineering environment associated with the panel.
  • Project configuration must match the 640 × 480 display and available keys.
  • Use the specified article number when selecting compatible Panel 800 accessories.
  • Vertical operation is specified for 0 to 50 °C ambient temperature.
  • Horizontal operation is specified for 0 to 40 °C ambient temperature.
  • Storage is rated from −20 to 70 °C with 5–85% non-condensing humidity.
  • The front panel is rated IP66 for indoor enclosure applications.
  • The rear side is rated IP20 and requires enclosure protection.
  • Published compliance includes CE, UL/cUL, DNV and NEMA 4x indoor.
Description
ABB PP836A 3BSE042237R2 is a Panel 800 operator terminal with a 6.5-inch TFT display, 640 × 480 pixel resolution and 64K colour presentation. Its active display area is sized for compact HMI panels that need clear process graphics without a large enclosure cutout.

The front interface combines a membrane keyboard with metal-dome switches, while Ethernet, RS422/RS485 and RS232C ports provide practical connections for control-system communication. USB host/device ports and a CompactFlash Type I/II slot support service access and application storage.

The terminal accepts +24 V DC power and uses an IP66 front with an IP20 rear, so enclosure sealing and cabinet-side protection must be planned separately. Check mounting orientation, ambient temperature and the installed application media before commissioning this PP836A operator panel.
Alternative Names
PP836A 3BSE042237R2 PP836A 3BSE042237R2 Panel 800 ABB PP836A Panel 800 PP836A 3BSE042237R2 ABB 6.5 inch operator panel PP836A TFT HMI ABB PP836A 640x480 panel
Technical notes
Before installing ABB PP836A 3BSE042237R2, verify the Panel Builder 800 project, 24 V DC supply, panel cut-out and rear clearance for the specified IP66 front / IP20 rear construction.
