DSQC 611 3HAC13389-2

/ 4.9
1001 reviews | Need a Specific Revision?
ABB DSQC 611 3HAC13389-2 is the contactor interface board listed for an IRC5 Panel Mounted Controller drive-module assembly.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for DSQC 611 3HAC13389-2
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for DSQC 611 3HAC13389-2

  • Manufacturer:
    ABB
  • Part Number:
    DSQC 611 3HAC13389-2
  • Product Family:
    ABB Robots
  • Product Type:
    Contactor Interface Board
  • Stock:
    1
  • Controller Configurations:
    PMC Small and PMC Large
  • Assembly context:
    Large drive module
  • Hardware role:
    Contactor interface board
  • Dimensions:
    21.5 × 12.9 × 2.7 cm
  • Installation Position:
    Drive Module
  • PMC Small Robot Compatibility:
    IRB 140, IRB 340, IRB 360
  • Mounting Method:
    Attachment Screws
  • Connection Method:
    Detachable Connectors
  • ESD Sensitive:
    Yes
  • Post-installation Requirement:
    Safety Function Tests
  • Weight:
    0.28 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Drive-Module Match Connector Record Replacement Check Application
  • Contactor interface board for IRC5 Panel Mounted Controller PMC Small and PMC Large configurations
  • Documented for PMC Small drive modules used with IRB 140, IRB 340, and IRB 360 robots
  • Exact DSQC 611 and 3HAC13389-2 identity controls replacement compatibility

DSQC 611 3HAC13389-2 is the contactor interface board identified in ABB's IRC5 Panel Mounted Controller spare-parts and replacement documentation.

ABB documents the board in both PMC Small and PMC Large drive-module assemblies. The PMC Small spare-parts information specifically identifies applications involving IRB 140, IRB 340, and IRB 360 robots.

Before replacement, confirm the complete 3HAC13389-2 identity, record every connector position, observe ESD precautions, and complete the applicable IRC5 safety function tests after refitting.

Availability, condition, price, and shipping time for DSQC 611 3HAC13389-2 are confirmed during quotation.

ABB DSQC 611 3HAC13389-2 Contactor Interface Board Datasheet, Manuals, and Support Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Confirm the installed controller is the Panel Mounted Controller configuration.
  • Verify the board occupies the documented large drive-module position.
  • Do not extend the fit claim to other IRC5 drive-module layouts.
  • Photograph all mating connectors before the board is removed.
  • Label cable positions so they can be restored without ambiguity.
  • Inspect connector seating and routing before power is restored.
  • Match both DSQC 611 and 3HAC13389-2 on the replacement label.
  • Compare mounting points and adjacent components with the removed board.
  • Run the applicable IRC5 drive-module diagnostic checks after installation.
  • ABB DSQC 611 3HAC13389-2 is used in IRC5 Panel Mounted Controller PMC Small drive modules for IRB 140 robots.
  • ABB DSQC 611 3HAC13389-2 is used in IRC5 Panel Mounted Controller PMC Small drive modules for IRB 340 and IRB 360 robots.
  • ABB DSQC 611 3HAC13389-2 is used as the contactor interface board in IRC5 Panel Mounted Controller PMC Large drive module assemblies.
Description
DSQC 611 3HAC13389-2 is ABB's contactor interface board identified in the IRC5 Panel Mounted Controller spare-parts manual.

The board is listed in the drive-module parts for the large Panel Mounted Controller arrangement under ordering number 3HAC13389-2.

Replacement requires an exact label match and preservation of connector locations because ABB does not document this board as a universal IRC5 interface.
Alternative Names
DSQC 611 3HAC13389-2 DSQC611 3HAC13389-2 3HAC13389-2 DSQC 611 3HAC13389-2 DSQC611 ABB DSQC 611 3HAC13389-2 ABB 3HAC13389-2 DSQC 611
Technical notes
DSQC 611 3HAC13389-2 requires verification of the large IRC5 Panel Mounted Controller drive-module position, complete label and recorded connectors before replacement to prevent interface mismatch.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How does the installed PMC configuration affect selection of ABB DSQC 611 3HAC13389-2?
ABB lists 3HAC13389-2 DSQC 611 as the contactor interface board in both PMC Small and PMC Large drive-module assemblies. Confirm the complete article number and the installed PMC drive-module arrangement rather than restricting selection to the large configuration.
Can ABB DSQC 611 3HAC13389-2 be used in every IRC5 controller?
ABB documents it in the Panel Mounted Controller large drive-module arrangement, so use in another IRC5 configuration must not be assumed.
What should be photographed before removing ABB DSQC 611 3HAC13389-2?
Photograph the complete board label, connector positions and surrounding drive-module layout before isolation and removal.
How should connector compatibility be checked for ABB DSQC 611 3HAC13389-2?
Compare the installed mating connectors and cable routing with the replacement board before reconnecting; a matching DSQC name without the complete ABB number is insufficient.
What should be checked after ABB DSQC 611 3HAC13389-2 is installed?
Check that all recorded connectors are fully seated and correctly routed, then use the applicable IRC5 Panel Mounted Controller diagnostic procedure before operation.
May ABB DSQC 611 3HAC13389-2 be substituted by a similar interface board?
No substitution is supported by the located ABB evidence. The replacement must match 3HAC13389-2 unless ABB issues a specific replacement instruction.
Are cables included with ABB DSQC 611 3HAC13389-2?
ABB's spare-parts entry identifies the board only and does not confirm bundled cables, so accessories must be verified from the quoted stock description.
