SPDSI13

/ 4.9
1001 reviews | Need a Specific Revision?
ABB SPDSI13 is a Symphony Plus HR Series digital-input module with 16 optically isolated channels fixed for 24 VDC field signals.
In Stock
Ships by Friday, October 30
Fast Shipping Available
Get a quick price for SPDSI13
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for SPDSI13

  • Manufacturer:
    ABB
  • Part Number:
    SPDSI13
  • Product Family:
    ABB Symphony Plus SD
  • Product Type:
    Symphony Plus 16-Channel 24 VDC Digital Input Module
  • Stock:
    1
  • Product Type:
    Digital input module
  • Channels:
    16
  • Input Voltage:
    24 VDC fixed
  • Input Current:
    5.5 mA per channel
  • Isolation:
    Optical isolation on each channel
  • System Power:
    5 VDC ±5%
  • System Current:
    95 mA typical
  • Ambient Temperature:
    0 to 70°C
  • System Family:
    Symphony Plus HR Series I/O
  • Weight:
    0.441 lbs (0.2 kg)
  • Estimated shipping dimensions:
    3.5 x 31.5 x 17.6 cm
  • Tariff Code:
    85389081
  • Country of origin:
    Switzerland
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Monitoring Safety Temperature & Humidity

Features:

  • Processes up to sixteen fixed 24 VDC digital field inputs.
  • Optically isolates every input channel from the module logic.
  • Operates in the documented 0 to 70°C HR Series ambient range.
The exact configuration is SPDSI13, the ABB Symphony Plus HR Series digital-input module with sixteen fixed 24 VDC channels.

It converts isolated on/off field states into data for the associated Symphony Plus controller while drawing power from the 5 VDC system bus.

Before installation, verify field voltage, channel polarity and commoning, HR Series slot and controller database so the fixed 24 VDC design is preserved.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for ABB SPDSI13: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Collects 24 VDC contact and status signals for a Symphony Plus controller.
  • Monitors sixteen optically isolated field inputs in an HR Series I/O cabinet.
  • Replaces an installed fixed-voltage SPDSI13 while preserving the existing 24 VDC channel design.
  • The module reports up to sixteen discrete field states to the Symphony Plus controller.
  • Each channel operates from a fixed 24 VDC field input drawing 5.5 mA.
  • Controller configuration maps each isolated input to its assigned process indication or logic point.
  • Isolate field power before disturbing 24 VDC input conductors.
  • Verify polarity and the documented common arrangement before energizing a replacement module.
  • Do not apply the 48 VDC or 120 VAC ratings belonging to other SPDSI variants.
  • ABB specifies an ambient operating range from 0 to 70°C.
  • Cabinet ventilation must keep the module within that temperature range at full channel loading.
  • Environmental conditions must remain within the limits of the complete Symphony Plus HR Series enclosure.
Description
SPDSI13 is an ABB Symphony Plus HR Series digital-input module for as many as sixteen 24 VDC field inputs. Every channel is optically isolated and uses the fixed 24 VDC input configuration documented for this exact model.

The module conditions discrete field states for use by a Symphony Plus controller. It draws 95 mA typical from the 5 VDC system supply while each input channel draws 5.5 mA at its nominal field voltage.

Confirm the SPDSI13 code rather than the 48 VDC SPDSI14 or multi-voltage SPDSI22, then verify the HR Series mounting position, field common, polarity and controller configuration. The documented ambient range is 0 to 70°C.
Alternative Names
SPDSI13 ABB SPDSI13 SPDSI 13 SPDSI-13 ABB Bailey SPDSI13 ABB Symphony Plus 16-Channel 24 VDC Digital Input Module
Technical notes
SPDSI13 is fixed for 24 VDC service; verify input polarity, optical isolation, termination, and field supply rather than applying SPDSI14 or SPDSI22 voltage rules.
