AB9001-B

/ 4.9
1001 reviews | Need a Specific Revision?
Anybus AB9001-B is an X-gateway that exchanges cyclic and acyclic data between Modbus TCP client connections and a PROFIBUS DP/DPV1 slave interface.
In Stock
Fast Shipping Available
Get a quick price for AB9001-B
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for AB9001-B

  • Manufacturer:
    ANYBUS
  • Part Number:
    AB9001-B
  • Product Family:
    ANYBUS
  • Product Type:
    Anybus X-gateway Modbus TCP Client to PROFIBUS Slave
  • Stock:
    1
  • Modbus TCP servers:
    Up to 64 transactions
  • Modbus TCP functions:
    1, 2, 3, 4, 5, 6, 15, 16 and 23
  • Ethernet rate:
    10/100 Mbit/s
  • Modbus TCP process data:
    256-byte input and 256-byte output
  • PROFIBUS address range:
    0–125
  • PROFIBUS baud rate:
    9.6 kbit/s–12 Mbit/s
  • PROFIBUS process data:
    244-byte input and 244-byte output
  • Network connectors:
    Two RJ45 ports and one female 9-pin D-sub
  • Power loading:
    150 mA typical, 300 mA maximum at 24 V DC
  • Mounting:
    DIN rail, EN 50022
  • Enclosure:
    IP20
  • Operating temperature:
    -25 to 60 °C
  • Weight:
    0.485 lbs (0.22 kg)
  • Estimated shipping dimensions:
    17x13.5x5.5cm
  • Tariff Code:
    8517620000
  • Country of origin:
    Sweden
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Data Mapping Modbus TCP PROFIBUS Hardware

Features:

  • Operates as a Modbus TCP client while presenting data as a PROFIBUS DP/DPV1 slave.
  • Maps cyclic process data between two independently configured industrial networks.
  • Mounts on DIN rail and uses an isolated 24 V DC-powered gateway architecture.
Anybus AB9001-B establishes the data bridge when a Modbus TCP device must exchange information with a PROFIBUS controller.

The Ethernet side schedules the requested server transactions, while the PROFIBUS side exposes the mapped bytes to the master.

Status indicators and network-specific configuration files separate commissioning checks for the two protocol sides.

The Anybus AB9001-B X-gateway Modbus TCP Client to PROFIBUS Slave may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
Anybus AB9001-B X-gateway Manuals,Datasheets,LinkImportant Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Process-Image Transfer

  • Register Assignment: Modbus registers are assigned to the gateway input and output areas.
  • PROFIBUS Image: The mapped bytes become the cyclic PROFIBUS process image seen by the master.
  • Status Data: Control and status data remain available for monitoring the two network sides.

Ethernet-Side Client Operation

  • Client Requests: The gateway initiates Modbus TCP requests as the client or master.
  • Ethernet Ports: Two RJ45 ports carry 10/100 Mbit/s Ethernet communication.
  • Function Setup: Function codes and server transactions are defined in the gateway configuration.

Fieldbus-Side Slave Operation

  • Slave Interface: The 9-pin female D-sub presents a PROFIBUS DP/DPV1 slave interface.
  • Master Exchange: The PROFIBUS master assigns the station address and exchanges the configured I/O bytes.
  • Acyclic Services: DPV1 adds acyclic parameter and diagnostic exchanges alongside cyclic data.

Power, Mounting, and Isolation

  • Power Connector: A 3-pin connector supplies the 24 V DC gateway electronics.
  • DIN Rail: DIN-rail mounting keeps the gateway outside the PLC card rack.
  • Electrical Isolation: Network isolation separates the Ethernet and PROFIBUS electrical domains.
Description
Anybus AB9001-B is an X-gateway protocol converter that connects Modbus TCP devices to a PROFIBUS control system. It acts as a Modbus TCP client on its Ethernet side and presents the exchanged process data to the controller through a PROFIBUS DP/DPV1 slave interface.

Across the two RJ45 ports, Anybus AB9001-B organizes Modbus transactions for as many as 64 server connections and maps their data into dedicated input and output areas. The female 9-pin D-sub carries the PROFIBUS network, where the gateway accepts the configured station address and data-exchange parameters from the master.

DIN-rail mounting places Anybus AB9001-B between the two networks without consuming a PLC card slot. Its 24 V DC power connector supplies the gateway electronics, while the isolated network sections keep the Ethernet and PROFIBUS interfaces electrically separated.
Alternative Names
AB9001-B AB9001B AB9001 B Anybus AB9001-B HMS AB9001-B Anybus X-gateway AB9001-B AB9001-B Modbus TCP PROFIBUS Gateway Anybus Modbus TCP Client PROFIBUS Slave AB9001-B
Technical notes
Anybus AB9001-B maps Modbus TCP client transactions into PROFIBUS DP/DPV1 slave process data through two RJ45 ports and a 9-pin D-sub.
