    Allen-Bradley 1305-BA01A is a discontinued Bulletin 1305 adjustable-frequency AC drive.

1305-BA01A

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1305-BA01A is a 0.37 kW, 380/460 V three-phase Bulletin 1305 adjustable-frequency AC drive.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1305-BA01A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1305-BA01A

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1305-BA01A
  • Product Family:
    1305 Drives
  • Product Type:
    Adjustable Frequency AC Drive
  • Stock:
    1
  • Rated Input:
    380/460 V AC three-phase, 50/60 Hz
  • Operational Input Range:
    340...500 V AC at 47...63 Hz
  • Motor Rating:
    0.37 kW (0.5 hp)
  • Output Current:
    1.3 A rms
  • Output Voltage:
    Adjustable from 0 V to input voltage
  • Output Frequency:
    0.00...400.00 Hz programmable
  • Input kVA:
    0.9 kVA
  • Power Factor:
    0.8 lagging
  • Efficiency:
    97.5% typical
  • Power Dissipation:
    21 W
  • SCANport Load:
    250 mA maximum, all adapters combined
  • Enclosure:
    NEMA Type 1 (IP30)
  • Weight:
    4 kg
  • Tariff Code:
    8504409999
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Protection Grounding Control Application
  • Bulletin 1305 control for a low-power three-phase induction motor
  • Programmable acceleration, deceleration, speed-reference, and protection parameters
  • Documented SCANport connection supports compatible operator and communication adapters

Allen-Bradley 1305-BA01A is the 0.37 kW catalog configuration in the 380/460 V Bulletin 1305 family.

Successful replacement depends on reproducing the original command source, terminal functions, frequency limits, stopping mode, motor settings, and external option arrangement.

Check the complete nameplate, hardware Series, firmware, parameter record, motor, supply, wiring, adapter load, clearances, grounding, and ventilation before commissioning.

Availability, condition, price, and shipping time for 1305-BA01A are confirmed during quotation.

Allen-Bradley 1305-BA01A Bulletin 1305 AC Drive Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Branch-circuit protection must be selected from the official drive instructions for the installed supply
  • Motor overload settings must be based on the connected motor nameplate
  • Ground-fault or overcurrent trips require inspection of the motor leads and motor before drive replacement
  • The drive chassis and motor frame require the grounding arrangement specified in the installation manual
  • Shielded signal wiring should be terminated according to Rockwell Automation guidance
  • RFI-filter effectiveness depends on a short mounting path and solid ground connection
  • Start, stop, direction, and speed-reference functions are assigned through documented terminals and parameters
  • Two-wire and three-wire control arrangements must not be interchanged without checking the machine circuit
  • The saved parameter set must be compared with the machine drawing before returning the axis to service
  • Low-power variable-speed control of a correctly sized three-phase induction motor
  • 380/460 V machines using documented Bulletin 1305 terminal logic
  • Service replacement where the original parameters, firmware, and hardware Series can be confirmed
Description
Allen-Bradley 1305-BA01A is a Bulletin 1305 adjustable-frequency AC drive for a small 380/460 V three-phase induction motor.

Its official rating is 0.37 kW (0.5 hp) with 1.3 A rms output current. The drive provides programmable output from 0.00 to 400.00 Hz and adjustable output voltage up to the applied line voltage.

Before installation or replacement, match the motor nameplate current, supply, hardware Series, firmware, speed-reference source, terminal wiring, SCANport accessories, protection, grounding, and enclosure conditions.
Revisions

Revision Part #

Also known as

1305-BA01A Ser A
1305-BA01A/A, Series A, Rev A
1305-BA01A Ser B
1305-BA01A/B, Series B, Rev B
1305-BA01A Ser C
1305-BA01A/C, Series C, Rev C
Alternative Names
1305-BA01A 1305BA01A 1305 BA01A Allen-Bradley 1305-BA01A Allen Bradley 1305-BA01A AB 1305-BA01A Rockwell Automation 1305-BA01A Bulletin 1305 1305-BA01A
Technical notes
Verify the 1.3 A motor-current limit, selected control source, grounding, branch protection, SCANport accessories, firmware, and hardware Series before replacement.
