    Obsolete — Allen-Bradley lists 1336-BDB-SP38D as the replacement for 1336-BDB-SP38A.

1336-BDB-SP38A

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1336-BDB-SP38A is an obsolete gate-driver PCB spare part for documented 460 V, 200 HP 1336 drive configurations.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1336-BDB-SP38A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1336-BDB-SP38A

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1336-BDB-SP38A
  • Product Family:
    1336 Drives
  • Product Type:
    1336 460 V 200 HP Gate Driver PCB Spare Part
  • Stock:
    1
  • Spare-part class:
    Gate driver printed circuit board
  • Documented drive group:
    1336 PLUS, PLUS II, FORCE, IMPACT and related 1336STEF structures
  • Documented voltage class:
    460 V
  • Documented power class:
    200 HP
  • Official successor:
    1336-BDB-SP38D
  • Replacement scope:
    Board-level spare; drive, power devices and other assemblies are separate
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Drive Matching Successor Planning Fault Isolation Application
  • Match the 460 V, 200 HP drive identity before selecting the SP38 gate-driver board
  • Treat SP38A as a board-level spare, not as a complete 1336 drive or power assembly
  • Use the documented SP38D successor only after checking drive series and conversion requirements

1336-BDB-SP38A is an Allen-Bradley gate-driver PCB spare part for documented 1336 drive power structures.

The official spare-parts list binds the SP38 identity to 460 V, 200 HP 1336STEF configurations and groups the A and C revisions as obsolete.

Confirm the drive nameplate, frame, series, power devices and conversion requirements before replacing it with 1336-BDB-SP38D.

Availability, condition, price, and shipping time for 1336-BDB-SP38A are confirmed during quotation.

Allen-Bradley 1336-BDB-SP38A Gate Driver PCB Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Verify the complete drive catalog number and 460 V input class
  • Confirm the documented 200 HP power structure and frame
  • Do not substitute gate-driver boards from other SP power classes
  • Record whether the removed board is revision A or C
  • Use 1336-BDB-SP38D as the official replacement identity
  • Apply any series-conversion instructions required by the installed drive
  • Test power transistors and the DC bus before fitting another board
  • Inspect gate leads, snubbers, insulation and board connectors
  • Correct contamination, cooling or power-structure faults before energizing
  • Gate-driver control for 460 V, 200 HP Allen-Bradley 1336 PLUS (1336S) drives
  • Gate-driver control for 460 V, 200 HP Allen-Bradley 1336 FORCE (1336T) and 1336 IMPACT (1336E) drives
  • Gate-driver control for 460 V, 200 HP Allen-Bradley 1336 PLUS II (1336F) drives
Description
1336-BDB-SP38A is an Allen-Bradley gate-driver printed circuit board spare part for documented 1336 drive power structures.

The official 1336 spare-parts list groups revision A and C under this identity and binds the replacement path to 460 V, 200 HP 1336STEF drive configurations. It is a board-level spare, not a complete drive or power assembly.

Selection must be based on the complete drive catalog number, input-voltage class, horsepower, frame and existing power structure. Allen-Bradley identifies 1336-BDB-SP38D as the replacement for the obsolete A/C versions.
Alternative Names
1336-BDB-SP38A 1336 BDB SP38A Allen-Bradley 1336-BDB-SP38A Allen Bradley 1336-BDB-SP38A Rockwell Automation 1336-BDB-SP38A AB 1336-BDB-SP38A
Technical notes
1336-BDB-SP38A is an obsolete gate-driver PCB for documented 460 V, 200 HP 1336STEF drive configurations. Allen-Bradley identifies 1336-BDB-SP38D as its successor; the PCB is not a complete drive or power assembly.
