  • Lifecycle status

    Discontinued / Obsolete by OEM
    Apter Power provides quotation support, procurement assistance and system-matching guidance for this configured drive.

20BD248A3ANNAEC0

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 20BD248A3ANNAEC0 is a 480 VAC three-phase PowerFlex 700 frame 6 drive rated 248 A, with EtherNet/IP, vector control and no feedback.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 20BD248A3ANNAEC0
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 20BD248A3ANNAEC0

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    20BD248A3ANNAEC0
  • Product Family:
    PowerFlex
  • Product Type:
    PowerFlex 700 AC drive
  • Stock:
    1
  • Input voltage:
    480 VAC, 3 phase, 60 Hz
  • Output current:
    248 A continuous; 273 A for 1 min; 372 A for 3 sec
  • Power rating:
    200 Hp normal duty; 150 Hp heavy duty
  • Output voltage:
    0–460 VAC
  • Input current:
    233 A at 480 VAC
  • Enclosure rating:
    IP20 / NEMA/UL Type 1
  • EMC filter:
    Second-environment filter with common-mode choke
  • Brake IGBT:
    Without brake IGBT
  • Brake resistor:
    No internal brake resistor
  • Communication module:
    EtherNet/IP DPI module
  • Control mode:
    Vector control with 24 V DC I/O
  • Feedback:
    No feedback
  • Carrier frequency:
    2, 4, 8 and 10 kHz; rating based on 4 kHz
  • Operating temperature:
    0 to 50 °C for most frame 5–6 ratings
  • Relative humidity:
    5–95%, noncondensing
  • Altitude:
    1000 m maximum without derating
  • Lifecycle status:
    Discontinued June 1, 2023; functional replacement category
  • Product family:
    PowerFlex 700 AC Drives
  • Weight:
    505 lbs (229.07 kg)
  • Estimated shipping dimensions:
    71.13 x 182.88 x 48.78 cm
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    United States
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication & Connectivity Compatibility Safety & Compliance

Features:

  • Frame 6 PowerFlex 700 construction for 480 VAC three-phase motor systems.
  • 248 A continuous output supports 200 HP normal-duty and 150 HP heavy-duty operation.
  • EtherNet/IP DPI communication works with vector control and 24 V DC I/O.
The current configuration is a high-power 20B drive with an IP20 / NEMA Type 1 enclosure, conformal coating and a second-environment EMC filter.

The drive is intended for coordinated industrial motor control where network commands, local I/O and vector regulation must operate together.

Before installation, match the mains, motor data, cabinet protection, braking hardware, feedback requirements and communication settings to the existing system.

The 20BD248A3ANNAEC0 is listed as discontinued by the manufacturer; confirm current replacement availability before ordering.
Verified resources for Allen-Bradley 20BD248A3ANNAEC0: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • High-power AC motor control in industrial production equipment.
  • Networked drive coordination through EtherNet/IP plant communication.
  • Functional replacement work for installed PowerFlex 700 drive cabinets.
  • The EtherNet/IP DPI module carries drive commands, status data and parameter traffic over the plant network.
  • Vector control uses the drive control system to regulate motor operation for demanding load conditions.
  • 24 V DC I/O provides the stated control-interface arrangement for external machine signals.
  • The 480 VAC three-phase input and frame 6 construction must match the receiving power and cabinet arrangement.
  • IP20 / NEMA Type 1 protection requires installation inside a suitably protected enclosure.
  • Brake hardware, feedback options, EMC filtering and motor data must be checked before functional replacement.
  • Conformal coating is part of the specified configuration for the drive electronics.
  • The second-environment EMC filter with common-mode choke must be integrated according to the cabinet design.
  • Commissioning requires verification of mains isolation, wiring, motor data and protective cabinet conditions.
Description
Allen-Bradley 20BD248A3ANNAEC0 is a PowerFlex 700 frame 6 adjustable-frequency drive for high-power 480 VAC three-phase motor systems. Its 248 A continuous rating supports 200 HP normal-duty operation and 150 HP heavy-duty service, providing controlled acceleration, speed regulation and torque management for demanding industrial loads.

The drive integrates vector control, 24 V DC I/O and an EtherNet/IP DPI communication module for coordinated commands, status exchange and drive-network supervision. Conformal coating and the IP20 / NEMA Type 1 enclosure suit protected control cabinets, while the selected EMC filter supports planned cabinet-level electromagnetic compatibility.

This configuration is suited to networked industrial motor-control installations, large equipment cabinets and functional-replacement projects built around PowerFlex 700 architecture. Before commissioning, verify mains capacity, motor nameplate data, enclosure protection, braking hardware, feedback requirements, wiring arrangement and communication settings so the replacement matches the existing system.
Alternative Names
Allen-Bradley 20BD248A3ANNAEC0 20BD248A3ANNAEC0 Allen-Bradley PowerFlex 700 20B PowerFlex 700 frame 6 drive PowerFlex 700 480 VAC drive PowerFlex 700 248 A drive PowerFlex 700 200 HP normal-duty drive PowerFlex 700 EtherNet/IP vector drive
Technical notes
Allen-Bradley 20BD248A3ANNAEC0 requires a replacement review covering 480 VAC input, frame 6 hardware, feedback, braking, motor data and EtherNet/IP settings before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What electrical input is specified for Allen-Bradley 20BD248A3ANNAEC0?
Rockwell identifies a 480 VAC, three-phase, 60 Hz input for this PowerFlex 700 drive.
What output duty ratings apply to Allen-Bradley 20BD248A3ANNAEC0?
The official record lists 248 A continuous, 273 A for one minute and 372 A for three seconds, with 200 Hp normal duty and 150 Hp heavy duty.
Which communication interface is included in Allen-Bradley 20BD248A3ANNAEC0?
The product record specifies an internal EtherNet/IP communication module and vector control with 24 V DC I/O.
Is Allen-Bradley 20BD248A3ANNAEC0 discontinued?
Rockwell lists June 1, 2023 as the discontinuation date and identifies the replacement category as functional replacement.
What must be checked before replacing Allen-Bradley 20BD248A3ANNAEC0?
Compare 480 VAC mains, frame 6 duty, enclosure, EMC filter, brake IGBT, feedback, motor data and EtherNet/IP requirements before substitution.
What documents support an Allen-Bradley 20BD248A3ANNAEC0 quotation?
Rockwell provides 20B-IN014 installation instructions, 20B-TD001 technical data and 20B-UM002 user documentation; send the nameplate, motor data, quantity and destination for a quotation.
