  • Lifecycle status

    Discontinued
    Discontinued date: 2017-06-01
    Replacement category: Functional Replacement
    Functional replacement: 1756-L73S

1756-L63S

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1756-L63S is an 8 MB/4 MB GuardLogix controller using a 1756-LSP safety partner, RS-232 programming and CompactFlash storage.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1756-L63S
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1756-L63S

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1756-L63S
  • Product Family:
    ControlLogix
  • Product Type:
    GuardLogix 8 MB Standard Memory Controller
  • Stock:
    1
  • Standard memory:
    8 MB
  • Safety memory:
    4 MB
  • Local programming:
    1 RS-232 port
  • Motion axes supported:
    100
  • Nonvolatile storage:
    CompactFlash
  • Replacement battery:
    1756-BA2
  • Controller identity:
    ControlLogix 5563S GuardLogix controller
  • Safety task and components user memory:
    3.75 MB
  • Matched safety partner:
    1756-LSP
  • Programming software:
    RSLogix 5000 software, version 16 or later
  • Weight:
    0.32 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Safety Identity Storage & Service Functional Replacement Application
  • Retain the validated GuardLogix safety project rather than treating this as a standard ControlLogix controller
  • Use the RS-232 programming connection and CompactFlash arrangement specified for this controller generation
  • Check safety memory, firmware and partner-device compatibility before commissioning

1756-L63S is an Allen-Bradley GuardLogix controller for ControlLogix systems requiring both standard control and safety control.

Its published controller features include 8 MB standard memory, 4 MB safety memory, one RS-232 programming connection, CompactFlash storage and support for up to 100 motion axes.

A replacement must be evaluated as a safety-system change: confirm project identity, firmware, chassis arrangement, safety partners and the validation record before returning the machine to service.

Availability, condition, price, and shipping time for 1756-L63S are confirmed during quotation.

Allen-Bradley 1756-L63S GuardLogix Controller Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Keep the 4 MB safety-memory identity distinct from a standard 1756-L63 controller
  • Verify the GuardLogix safety application and validation record before enabling safety functions
  • Confirm safety-partner hardware and project configuration as part of the replacement scope
  • Use the listed CompactFlash storage arrangement for this controller generation
  • Plan for the published RS-232 programming connection rather than assuming a USB port
  • Confirm the 1756-BA2 replacement-battery requirement against the installed controller
  • Rockwell Automation identifies 1756-L73S as the functional replacement
  • Assess controller-generation, firmware and project migration before substituting the replacement
  • Revalidate the complete safety function after any controller-generation change
  • ControlLogix GuardLogix machine safety applications
  • Integrated standard-control and safety-control architectures
  • Safety motion systems requiring the controller’s published 100-axis capability
Description
1756-L63S is an Allen-Bradley GuardLogix controller for ControlLogix safety and standard-control applications.

Rockwell Automation specifies 8 MB standard memory, 4 MB safety memory, one RS-232 programming connection, CompactFlash storage, 100 motion axes, and a 1756-BA2 replacement battery.

It is a safety-controller identity, not a standard 1756-L63 substitute; keep the approved GuardLogix safety project, firmware, chassis and partner components together.
Revisions

Revision Part #

Also known as

1756-L63S Ser B
1756-L63S/B, Series B, Rev B
Alternative Names
1756-L63S 1756 L63S 1756L63S Allen-Bradley 1756-L63S Rockwell Automation 1756-L63S GuardLogix 1756-L63S
Technical notes
1756-L63S is a GuardLogix identity; retain its validated safety project, v20.018 firmware context, RS-232 connection, CompactFlash arrangement and 1756-BA2 battery.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can Allen-Bradley 1756-L63S replace a standard 1756-L63 controller?
No. Allen-Bradley 1756-L63S is a GuardLogix safety controller with dedicated safety memory and safety application architecture; a standard 1756-L63 does not provide that safety function.
What must remain with Allen-Bradley 1756-L63S during replacement?
Keep the approved GuardLogix safety application, firmware revision, chassis arrangement, controller keying, and machine validation record with Allen-Bradley 1756-L63S.
Can Allen-Bradley 1756-L63S use USB programming like newer GuardLogix controllers?
No USB programming port is listed for Allen-Bradley 1756-L63S. Rockwell Automation lists one local RS-232 programming connection; plan the correct cable and workstation interface.
Does moving a CompactFlash card make another Allen-Bradley 1756-L63S ready for service?
No. The card is only one configuration item. Safety signature, firmware, controller revision, and validated safety project must also match the installed system.
Is Allen-Bradley 1756-L73S an ordinary drop-in replacement for 1756-L63S?
Rockwell identifies 1756-L73S as the functional replacement. Review memory, firmware, migration, and safety-validation requirements before changing controller generation.
Why can Allen-Bradley 1756-L63S communicate but refuse safety operation?
Communication alone does not validate a GuardLogix safety application. Check safety-project identity, signatures, firmware compatibility, and all safety-partner configuration.
What should be included in a maintenance plan for Allen-Bradley 1756-L63S?
Document approved shutdown steps, safety-project backup, signature verification, firmware record, partner configuration, battery condition, and post-service validation before returning Allen-Bradley 1756-L63S to operation.
