1794-OB8EP

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1794-OB8EP is an eight-point 24 V DC sourcing FLEX I/O output module with electronic protection and per-channel fault indication.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1794-OB8EP
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1794-OB8EP

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1794-OB8EP
  • Product Family:
    Flex I/O
  • Product Type:
    FLEX I/O Eight-Point Electronically Protected DC Output Module
  • Stock:
    1
  • Output Points:
    8 current-sourcing outputs
  • Field Supply Range:
    19.2…31.2 V DC
  • Nominal Field Supply:
    24 V DC
  • Maximum Output Current:
    2 A per output
  • Maximum Module Current:
    10 A
  • Output Surge:
    4 A for 50 ms, repeatable every 3 seconds
  • Protection:
    Electronic output protection with fault status
  • Status Indicators:
    8 yellow output indicators and 8 red fault indicators
  • Maximum Off-State Leakage:
    0.5 mA
  • FLEXBUS Current:
    73 mA at 5 V DC
  • Operating Temperature:
    -20…55 °C
  • Dimensions:
    9.4 × 4.6 × 5.3 cm
  • Weight:
    0.104 kg
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Output Protection Load Matching Fault Recovery Application
  • Eight current-sourcing DC outputs with electronic fault protection
  • Operates from a 19.2…31.2 V DC field supply for nominal 24 V DC systems
  • Channel indicators and controller status support fault identification and reset

1794-OB8EP combines eight higher-current DC sourcing outputs with electronic fault protection at the distributed I/O point.

A tripped channel can be identified from its red indicator and controller status, then reset after the field fault has been corrected.

Match the positive-logic load, supply, base wiring, surge duty, suppression, and reset method before returning the station to service.

Availability, condition, price, and shipping time for 1794-OB8EP are confirmed during quotation.

Allen-Bradley 1794-OB8EP FLEX I/O Eight-Point Electronically Protected DC Output Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Each sourcing output is electronically protected against documented fault conditions.
  • Red channel indicators and controller status identify a tripped output.
  • Correct the field fault before using the approved reset method.
  • Connect only compatible positive-logic DC loads to the sourcing outputs.
  • Check steady current and starting surge against both channel and module limits.
  • Use suitable suppression for inductive loads without reversing required polarity.
  • Inspect the channel wiring and load before attempting a reset.
  • Choose front-button, controller-bit, or power-cycle reset according to the safe procedure.
  • Confirm normal status indication and commanded operation before restoring production.
  • Protected switching of compatible 24 V DC solenoids and actuators in distributed FLEX I/O stations.
  • Machine-output control requiring per-channel electronic fault detection and reset capability.
  • Higher-current DC load control where sourcing polarity and channel diagnostics are required.
Description
Allen-Bradley 1794-OB8EP provides eight current-sourcing DC outputs for a FLEX I/O station and electronically protects each channel against an output fault.

The module reports output faults through red indicators and status bits, supports a documented reset process, and operates from a 19.2…31.2 V DC field supply.

Before installation, verify sourcing-load polarity, terminal-base compatibility, channel current and surge, group commons, suppression, field power, reset logic, and the saved output map.
Revisions

Revision Part #

Also known as

1794-OB8EP Ser A
1794-OB8EP/A, Series A, Rev A
Alternative Names
1794-OB8EP 1794OB8EP 1794 OB8EP Allen-Bradley 1794-OB8EP Allen Bradley 1794-OB8EP AB 1794-OB8EP Rockwell Automation 1794-OB8EP
Technical notes
1794-OB8EP provides protected sourcing outputs; verify load polarity, inrush, terminal base, suppression, reset behavior, and output mapping before replacement.
