1771-IR

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1771-IR is a six-channel RTD and resistance input module for PLC-5 and 1771 I/O temperature-measurement applications.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1771-IR
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1771-IR

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1771-IR
  • Product Family:
    PLC-5
  • Product Type:
    6-Channel RTD Input Module
  • Stock:
    1
  • Input Channels:
    6 RTD or resistance channels
  • Supported RTDs:
    100 Ω platinum, α = 0.00385; 10 Ω copper, α = 0.00386
  • Platinum RTD Range:
    -200 to 870°C
  • Copper RTD Range:
    -200 to 260°C
  • Resistance Range:
    1 to 600 Ω
  • Platinum RTD Resolution:
    0.1°C or 0.1°F
  • Copper RTD Resolution:
    0.3°C or 0.5°F
  • Resistance Resolution:
    10 mΩ or 30 mΩ
  • Sensor Excitation Current:
    1 mA
  • Input Isolation:
    1000 V peak channel-to-channel and channel-to-backplane for 1 second
  • Common-Mode Rejection:
    120 dB at 60 Hz, up to 1000 V peak
  • Input Impedance:
    Greater than 10 MΩ
  • Normal-Mode Rejection:
    60 dB
  • Continuous Input Overvoltage:
    120 V rms
  • Six-Channel Scan Time:
    50 ms
  • Backplane Current:
    0.85 A at 5 V DC
  • Power Dissipation:
    4.25 W maximum
  • Field-Wiring Arm:
    1771-WF
  • Keying Positions:
    10–12 and 28–30
  • Operating Temperature:
    0 to 60°C
  • Storage Temperature:
    -40 to 85°C
  • Relative Humidity:
    5 to 95%, non-condensing
  • Tariff Code:
    8538900000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals RTD Selection Wiring Practice Calibration Application
  • Accepts documented RTD and resistance inputs for PLC-5 temperature measurement
  • Uses configurable sensor type, excitation and engineering-unit conversion
  • Depends on correct RTD lead compensation, shielding and channel calibration

1771-IR is an Allen-Bradley RTD input module for measuring temperature and resistance through a 1771 I/O chassis.

Its accuracy depends on the selected RTD curve, lead-wire arrangement and channel configuration rather than the sensor resistance alone.

Preserve sensor type, wiring, scaling, alarm limits and calibration records before exchanging the module or field termination.

Availability, condition, price, and shipping time for 1771-IR are confirmed during quotation.

Allen-Bradley 1771-IR 6-Channel RTD Input Module Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Select the documented platinum or copper RTD curve for temperature conversion
  • Use resistance mode when automatic RTD linearization is not applicable
  • Preserve the selected Celsius or Fahrenheit engineering-unit format
  • Follow the three-wire RTD diagrams to support lead-resistance compensation
  • Route shields and grounds according to the official installation instructions
  • Keep channel assignments and field-wiring-arm terminals consistent during replacement
  • Confirm the saved block-transfer configuration before calibration
  • Allow the module and sensors to reach stable operating conditions
  • Verify all channels against the application accuracy requirement after replacement
  • Platinum RTD temperature measurement
  • Copper RTD temperature measurement
  • Direct resistance-transducer acquisition
Description
1771-IR is a single-slot Allen-Bradley RTD input module that connects as many as six temperature or resistance sensors to controllers supporting the 1771 I/O structure and block-transfer communication.

The module supports 100-ohm platinum and 10-ohm copper RTDs, along with other sensor types such as 120-ohm nickel RTDs. Measurement results can be reported in degrees Celsius, degrees Fahrenheit, or ohms using BCD or binary data formats.

Software-selectable operation includes 0.1-degree or 10-milliohm resolution, automatic calibration, and open-wire detection. The module receives power from the chassis backplane and uses a 1771-WF field-wiring arm for sensor connections.

Before installation or replacement, confirm the hardware series, RTD type, sensor wiring arrangement, 1771-WF wiring arm, chassis slot and addressing, backplane capacity, grounding, measurement units, data format, and existing block-transfer configuration.
Alternative Names
1771-IR 1771 IR 1771IR Allen-Bradley 1771-IR Allen Bradley 1771-IR Rockwell Automation 1771-IR PLC-5 1771-IR
Technical notes
1771-IR replacement requires matching Series B hardware, 1771-WF arm, RTD type, three-wire routing, units, calibration, slot, and block-transfer setup; sensor mismatch can create temperature error.
