Allen-Bradley 1771-NC15 is a 4.6 m interconnect cable linking compatible 1771 N-Series analog I/O modules to remote termination panels.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1771-NC15
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1771-NC15

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1771-NC15
  • Product Family:
    PLC-5
  • Product Type:
    High Resolution N-Series Remote Termination Panel Cable
  • Stock:
    1
  • Cable Function:
    I/O module-to-remote-termination-panel interconnect
  • Cable Length:
    4.57 m (15 ft)
  • Module-End Connection:
    Dedicated 1771-N Series module connector
  • Termination-End Connection:
    Dedicated 1771-RTP connector with retaining screws
  • Compatible Module Groups:
    1771-NIS, 1771-NIV family, 1771-NR, 1771-NT family, 1771-NOC, and 1771-NOV, subject to panel matching
  • Installation Role:
    One of one or two cable sets required according to module channel count and termination arrangement
  • Compatible I/O Modules:
    1771-NIS, 1771-NIV, 1771-NIV1, 1771-NIVR, 1771-NIVT, 1771-NR, 1771-NT1, 1771-NT2, 1771-NOC, and 1771-NOV
  • Compatible Remote Termination Panels:
    1771-RTP1, 1771-RTP3, 1771-RTP4, 1771-RT41, and 1771-RT44
  • Remote Panel Mounting:
    Standard DIN 1 or DIN 3 rail
  • Shorter Cable Alternative:
    1771-NC6, 1.83 m (6 ft)
  • Tariff Code:
    8544200000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Compatibility Termination Installation Application
  • 4.6 m interconnect length for remote termination placement
  • Dedicated connection between 1771 N-Series analog modules and matched RTP hardware
  • Supports panel-based field termination without a conventional module wiring arm

1771-NC15 is an Allen-Bradley high-resolution N-Series remote termination panel cable designed for compatible 1771 analog I/O installations.

Its module and panel connectors carry analog channel wiring across a documented 4.6 m route while field conductors remain landed at the selected termination panel.

Before installation or replacement, verify the N-Series module, termination-panel variant, cable quantity, connector condition, routing, shielding, and enclosure clearance.

Availability, condition, price, and shipping time for 1771-NC15 are confirmed during quotation.

Allen-Bradley 1771-NC15 High Resolution N-Series Cable Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Used with high-resolution 1771 N-Series isolated analog I/O modules
  • Panel selection depends on channel count and current, voltage, RTD, or thermocouple signal type
  • Four-channel arrangements use one cable set; eight-channel arrangements normally use two
  • 1771-RTP1 provides cold-junction compensation for supported thermocouple inputs
  • 1771-RTP3 incorporates resistors for documented current-input arrangements
  • 1771-RTP4 and 1771-RT44 provide straight-through wiring for supported non-thermocouple applications
  • Place the remote termination panel within the 4.6 m cable route
  • Allow front clearance for the connector and protect both D-sub interfaces from strain
  • Route analog cabling away from AC modules and high-voltage DC wiring
  • Remote termination for 1771-NIV and 1771-NIV1 voltage-input systems
  • Remote termination for 1771-NIS, 1771-NR, 1771-NT1, and 1771-NT2 input systems
  • Remote termination for 1771-NOC and 1771-NOV analog-output systems
Description
1771-NC15 is an Allen-Bradley remote termination panel cable for 1771 N-Series high-resolution isolated analog I/O.

The 4.6 m cable carries module-side analog connections to the matched 1771-RTP or 1771-RT termination assembly without landing field wiring on a conventional wiring arm.

Before installation or replacement, confirm the exact N-Series module, required panel type, number of cable sets, connector orientation, routing, and enclosure clearance.
Alternative Names
1771-NC15 1771 NC15 1771NC15 Allen-Bradley 1771-NC15 Allen Bradley 1771-NC15 AB 1771-NC15 Rockwell Automation 1771-NC15
Technical notes
Allen-Bradley 1771-NC15 is the 4.6 m N-Series module-to-RTP cable. Match the module, termination panel, cable count, connector orientation, routing, and enclosure clearance before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should be verified before ordering an Allen-Bradley 1771-NC15 replacement?
Confirm both mating connectors, module and termination-panel compatibility, required routing length, cabinet clearance, and whether the existing cable has shielding or connector damage.
Can Allen-Bradley 1771-NC15 connect directly to field transmitters?
No. It links the I/O module to an approved remote termination panel; transmitters and other field devices land on the panel terminals selected for that module.
Can Allen-Bradley 1771-NC15 replace the shorter 1771-NC6 without rewiring the panel?
Both are documented N-Series interconnect lengths, but verify available enclosure depth, routing, bend radius, connector access, and electrical-noise separation before changing cable length.
What should be checked if signals become intermittent after installing Allen-Bradley 1771-NC15?
Inspect connector seating, bent pins, cable strain, shield grounding, continuity, terminal-panel connections, and routing near electrical-noise sources.
Why should Allen-Bradley 1771-NC15 not be routed beside high-voltage conductors?
It carries low-level analog signals between the module and termination panel. Rockwell instructs users to separate analog and low-voltage wiring from AC and high-voltage DC sources.
Can an existing Allen-Bradley 1771-NC15 remain during a 1771-to-1756 conversion?
Rockwell's conversion system replaces the original N-Series cables with specified 1492 conversion cables while retaining supported remote termination panels and their field wiring.
What distinguishes a cable-path fault from a failed module when Allen-Bradley 1771-NC15 is installed?
Compare both cable sets where applicable, inspect connector seating and pins, verify panel terminals and shields, then test continuity with equipment de-energized before replacing electronics.
