1771-NC6

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1771-NC6 is a 6 ft N-series cable for high-resolution isolated analog modules and remote termination panels.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1771-NC6
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1771-NC6

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1771-NC6
  • Product Family:
    PLC-5
  • Product Type:
    N-Series Interconnect Cable
  • Stock:
    1
  • Cable length:
    6 ft (1.83 m)
  • Module interface:
    1771 N-series analog module
  • Remote termination panels:
    1771-RTP1, 1771-RTP3, or 1771-RTP4 as applicable
  • Product class:
    Interconnect cable
  • Compatible platform:
    1771 N-Series high-resolution isolated analog I/O
  • Longer cable option:
    1771-NC15, 15 ft (4.57 m)
  • Lifecycle:
    Discontinued 2021-03-31
  • Tariff Code:
    8544200000
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Length Panels Interface Application
  • Six-foot interconnect cable for 1771 N-series high-resolution isolated analog modules
  • Links the module to the separately mounted remote termination panel
  • Panel selection depends on the installed N-series signal and termination requirements

1771-NC6 is an Allen-Bradley N-series interconnect cable designed for 1771 high-resolution isolated analog I/O hardware.

The cable carries the module connection to a compatible remote termination panel, with RTP1, RTP3, or RTP4 selected for the documented signal arrangement.

Before installation or replacement, verify the module catalog number, required remote termination panel, cable length, connector condition, routing, and existing field wiring.

Availability, condition, price, and shipping time for 1771-NC6 are confirmed during quotation.

Allen-Bradley 1771-NC6 N-Series Interconnect Cable Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • 1771-NC6 provides a documented cable length of 6 ft (1.83 m)
  • 1771-NC15 is the corresponding 15 ft (4.57 m) N-Series cable
  • Select the cable length before finalizing the remote termination panel location
  • 1771-RTP1 provides cold-junction compensation for thermocouple inputs
  • 1771-RTP3 incorporates resistors and fuses for applicable current-input arrangements
  • 1771-RTP4 provides straight-through general-purpose termination except for thermocouples
  • The cable connects a compatible 1771 N-Series analog module to its remote termination panel
  • Match the documented module end and RTP end before securing the connectors
  • Remove 1771 chassis backplane power before removing or installing the connected I/O module
  • Thermocouple input systems using a compatible N-series module and 1771-RTP1
  • 4...20 mA input systems using the documented 1771-RTP3 arrangement
  • General N-series analog field termination using the compatible 1771-RTP4 panel
Description
1771-NC6 is an Allen-Bradley 6 ft interconnect cable for the 1771 N-series high-resolution isolated analog I/O platform.

It connects an N-series analog module to the applicable remote termination panel, keeping the field termination separate from the PLC chassis module.

Before installation or replacement, confirm the complete cable number, N-series module, RTP type, cable length, connector orientation, routing, and field termination arrangement.
Revisions

Revision Part #

Also known as

1771-NC6 Series A
1771-NC6/A, Series A
Alternative Names
1771-NC6 1771NC6 1771 NC6 Allen-Bradley 1771-NC6 AB 1771-NC6 1771 N-Series 6 ft Cable
Technical notes
1771-NC6 must be matched to the installed 1771 N-series module and the correct RTP1, RTP3, or RTP4 remote termination panel before reconnecting field wiring.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How long is Allen-Bradley 1771-NC6?
The official N-series documentation identifies 1771-NC6 as the 6 ft interconnect cable.
What does Allen-Bradley 1771-NC6 connect?
It connects a compatible 1771 N-series high-resolution isolated analog module to a remote termination panel.
Which remote termination panels can be used with Allen-Bradley 1771-NC6?
The applicable panel can be 1771-RTP1, 1771-RTP3, or 1771-RTP4, depending on the module and signal type.
Is Allen-Bradley 1771-NC6 the same length as 1771-NC15?
No. 1771-NC6 is 6 ft, while 1771-NC15 is the separately documented 15 ft cable.
Can Allen-Bradley 1771-NC6 be selected without checking the RTP type?
No. The module, signal type, and remote termination panel must be matched before ordering the cable.
What connector checks matter for Allen-Bradley 1771-NC6 replacement?
Inspect both cable ends, keying and orientation, retention hardware, routing, and the remote termination panel connector.
What should be provided with an inquiry for Allen-Bradley 1771-NC6?
Provide the cable catalog number, N-series module number, RTP number, required length, and photos of both installed connectors.
