1771-NC6/A

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1771-NC6/A is a 6 ft (1.83 m) N-Series interconnect cable used between compatible high-resolution isolated analog modules and remote termination panels.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1771-NC6/A
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1771-NC6/A

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1771-NC6/A
  • Product Family:
    PLC-5
  • Product Type:
    6 foot cable
  • Stock:
    1
  • Cable length:
    6 ft (1.83 m)
  • Product class:
    Interconnect cable
  • Compatible platform:
    1771 N-Series high-resolution isolated analog I/O
  • Connection:
    Analog module to remote termination panel
  • Remote termination panels:
    1771-RTP1, 1771-RTP3, or 1771-RTP4 as applicable
  • Longer cable option:
    1771-NC15, 15 ft (4.57 m)
  • Lifecycle:
    Discontinued 2021-03-31
  • Typical AC Signal Delay (Off):
    45 (+/- 15) ms
  • Typical DC Signal Delay (Off):
    50 ms
  • Weight:
    0.28 kg
  • Estimated shipping dimensions:
    22.9x12.7x22.9cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Length Panels Installation Application
  • Six-foot interconnect cable for 1771 N-Series high-resolution isolated analog modules
  • Connects the module to a separately mounted remote termination panel
  • Panel selection depends on the installed N-Series module and signal arrangement

1771-NC6/A is an Allen-Bradley 6 ft (1.83 m) cable for the 1771 N-Series high-resolution isolated analog I/O platform.

Rockwell Automation documents 1771-NC6 and 1771-NC15 as the 6 ft and 15 ft cables used between N-Series modules and remote termination panels.

Before installation or replacement, verify the connected module, required RTP type, cable length, connector orientation, retention hardware, and existing field wiring.

Availability, condition, price, and shipping time for 1771-NC6/A are confirmed during quotation.
Allen-Bradley 1771-NC6/A 6 foot cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • 1771-NC6 provides a documented cable length of 6 ft (1.83 m)
  • 1771-NC15 is the corresponding 15 ft (4.57 m) N-Series cable
  • Select the cable length before finalizing the remote termination panel location
  • 1771-RTP1 provides cold-junction compensation for thermocouple inputs
  • 1771-RTP3 incorporates resistors and fuses for applicable current-input arrangements
  • 1771-RTP4 provides straight-through general-purpose termination except for thermocouples
  • Match the cable module end and RTP end to their documented connection points
  • Remove 1771 chassis backplane power before removing or installing the connected module
  • Secure the RTP connector and preserve the documented connector orientation and cable routing
  • Thermocouple input systems using a compatible N-Series module and 1771-RTP1
  • Applicable 4...20 mA input arrangements using the documented 1771-RTP3 panel
  • General N-Series analog termination using 1771-RTP4 for non-thermocouple applications
Description

1771-NC6/A is an Allen-Bradley 6 ft (1.83 m) interconnect cable for the 1771 N-Series high-resolution isolated analog I/O platform.

Rockwell Automation documents 1771-N Series modules as cable-connected to a remote termination panel by either the 1771-NC6 6 ft cable or the 1771-NC15 15 ft cable.

Panel selection depends on the signal arrangement: 1771-RTP1 provides thermocouple cold-junction compensation, 1771-RTP3 incorporates resistors and fuses for applicable current inputs, and 1771-RTP4 provides straight-through general-purpose termination except for thermocouples.

Revisions

Revision Part #

Also known as

1771-NC6 Ser A
1771-NC6/A, Series A, Rev A
Alternative Names
1771NC6/A 177I-NC6/A 177INC6/A I771-NC6/A I771NC6/A I77I-NC6/A 1771-NC6 1771-NC15
Technical notes
1771-NC6/A is the 6 ft N-Series interconnect cable between a compatible 1771 high-resolution isolated analog module and the selected remote termination panel; verify the module, RTP type, connector orientation, and cable routing before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How long is Allen-Bradley 1771-NC6/A?
Rockwell Automation documents 1771-NC6 as the 6 ft (1.83 m) N-Series interconnect cable.
What does Allen-Bradley 1771-NC6/A connect?
It connects a compatible 1771 N-Series high-resolution isolated analog module to its remote termination panel.
Which remote termination panels are documented for Allen-Bradley 1771-NC6/A?
The applicable panel can be 1771-RTP1, 1771-RTP3, or 1771-RTP4, depending on the module and signal arrangement.
What is the longer alternative to Allen-Bradley 1771-NC6/A?
The corresponding longer N-Series cable is 1771-NC15, with a documented length of 15 ft (4.57 m).
What should be done before disconnecting Allen-Bradley 1771-NC6/A?
Remove power from the 1771 I/O chassis backplane and disconnect the cable before removing or installing the connected I/O module.
How should the ends of Allen-Bradley 1771-NC6/A be matched?
Connect the module end to the compatible 1771 N-Series module and the RTP end to the selected remote termination panel, preserving connector orientation and retention.
What should be provided with an inquiry for Allen-Bradley 1771-NC6/A?
Provide the full cable catalog number, required length, connected N-Series module, remote termination panel number, and clear photos of both connectors.
