1785-V40L

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1785-V40L is a PLC-5/V40L VMEbus processor with 48K words of user memory for supported VME and 1771 I/O systems
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1785-V40L
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1785-V40L

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1785-V40L
  • Product Family:
    PLC-5
  • Product Type:
    PLC-5/V40L VMEbus Processor
  • Stock:
    1
  • Official Catalog Number:
    1785-V40L
  • Official Product Designation:
    PLC-5/V40L
  • Maximum User Memory:
    48K words
  • Maximum Total I/O:
    1920 input and 1920 output
  • Maximum Analog I/O:
    1920
  • DH+ or Remote I/O Ports:
    2
  • Extended-local I/O Ports:
    1
  • RS-232 Ports:
    1
  • Maximum Number of I/O Racks:
    15
  • Maximum Extended-local I/O Chassis:
    16
  • Maximum Remote I/O Chassis:
    60
  • Backplane Current Load:
    3.5 A maximum; 2.9 A typical
  • Power:
    21 W maximum; 16 W typical
  • Operating Temperature:
    0 to 65°C with 200 LFM forced air across the circuit board
  • Storage Temperature:
    -40 to 85°C
  • Dimensions:
    4.1 × 18.8 × 26.2 cm
  • Weight:
    0.68 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals VME Installation Extended-local I/O Thermal Control Application
  • Provides 48K words of user memory in the PLC-5/V40L VMEbus processor format
  • Supports one extended-local I/O port and as many as sixteen extended-local chassis
  • Requires 200 LFM forced-air cooling across the circuit board at the documented operating range

1785-V40L is the Allen-Bradley PLC-5/V40L processor for a VMEbus assembly.

Its architecture combines two DH+ or Remote I/O ports with one extended-local I/O port, 48K words of user memory, and one RS-232 interface.

Before replacement, preserve the VME slot and backplane details, application, channel assignments, rack plan, airflow, and power requirements.

Availability, condition, price, and shipping time for 1785-V40L are confirmed during quotation.

Allen-Bradley 1785-V40L PLC-5/V40L VMEbus Processor Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The official catalog number is 1785-V40L and the product designation is PLC-5/V40L.
  • The processor uses the documented VMEbus hardware format.
  • Slot, backplane, addressing, power, and connector details must match the host system.
  • One extended-local-I/O port distinguishes the V40L architecture.
  • The official table permits up to sixteen extended-local I/O chassis.
  • Extended-local and remote-I/O plans must be restored with the controller project.
  • The operating specification assumes 200 LFM forced air across the board.
  • Maximum processor power is documented as 21 W.
  • Airflow, temperature, and clearances should be verified before commissioning.
  • VMEbus control assemblies requiring the documented PLC-5/V40L processor format.
  • Systems combining remote I/O with an extended-local-I/O chassis network.
  • Board-level controller replacement where airflow, VME power, project, and rack records are retained.
Description
Allen-Bradley 1785-V40L is the official hardware catalog for the PLC-5/V40L processor; PLC-5/V40L is the product designation, not an added part of the catalog number.

The processor provides 48K words of user memory, two Data Highway Plus or remote-I/O ports, one extended-local-I/O port, one RS-232 port, and support for the documented VME and 1771 architecture.

Replacement planning should confirm the complete 1785-V40L nameplate, VME slot and backplane, forced-air requirement, extended-local chassis layout, remote-I/O rack plan, processor image, and communication-channel assignments.
Alternative Names
1785-V40L Allen-Bradley 1785-V40L Allen Bradley 1785-V40L PLC-5/V40L PLC-5/V40L 1785-V40L
Technical notes
1785-V40L replacement requires the exact V40L catalog, VME slot and power, 200 LFM airflow, saved PLC-5 project, extended-local chassis plan, remote-I/O racks, and communication assignments; standard PLC-5/40 is different.
