1734-OE2V

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1734-OE2V is a two-channel POINT I/O analog voltage output module with configurable 0...10 V or ±10 V ranges.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 1734-OE2V
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1734-OE2V

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1734-OE2V
  • Product Family:
    Point I/O 1734
  • Product Type:
    POINT I/O 2-Channel Analog Voltage Output Module
  • Stock:
    1
  • Outputs:
    2 single-ended non-isolated voltage channels
  • Output ranges:
    0...10 V or ±10 V
  • Resolution:
    14 bits across -10...+10 V
  • Resolution increment:
    1.28 mV/count
  • Startup output:
    0 V until configured
  • POINTBus current:
    75 mA at 5 V DC
  • Weight:
    0.036 kg
  • Estimated shipping dimensions:
    5.66x1.21x7.75cm
  • Tariff Code:
    8537101190
  • Country of origin:
    Singapore
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Bipolar Range Setup Load and Fault Review Product Applications

Features:

  • Voltage command: two single-ended analog outputs
  • Unipolar or bipolar: selectable 0...10 V and ±10 V ranges
  • Controller transitions: configurable clamp and communication-fault behavior
1734-OE2V supports devices that need a voltage reference rather than a current loop.

The bipolar option changes sign handling, receiver expectations, scaling, and commissioning measurements, so range choice must be explicit.

Ground reference and load impedance should be verified with the same care as the controller configuration.

Availability of 1734-OE2V is subject to Apter Power inventory and sourcing confirmation.
Allen-Bradley 1734-OE2V POINT I/O 2-Channel Analog Voltage Output Module Manuals and Product Resources
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Allen-Bradley 1734-OE2V POINT I/O 2-Channel Analog Voltage Output Module Specs

General

  • ManufacturerAllen-Bradley
  • Model1734-OE2V
  • ConditionNew Original ready stock
  • Product FamilyPOINT I/O 1734
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

Configure signed voltage control

  • Range: select 0...10 V or ±10 V for the receiver.
  • Sign: confirm controller scaling and device direction across zero.
  • Common: verify reference potential before energizing.
  • Span test: measure negative, zero, and positive commands where applicable.

Protect the voltage receiver path

  • Impedance: confirm the connected input is suitable.
  • Clamps: limit commands to the approved process range.
  • Fault action: define behavior for communication loss or program mode.
  • Recovery: observe the receiver when normal control returns.

Supported product applications

  • Drive references: supply 0...10 V or bipolar speed demand where supported.
  • Servo commands: provide signed analog references to compatible equipment.
  • Position demand: control voltage-input actuators and instruments.
  • Legacy integration: retain voltage-based control in a POINT I/O architecture.
Description
1734-OE2V creates two single-ended, non-isolated voltage outputs for the POINT I/O platform. A channel can operate over 0...10 V or ±10 V, with 14-bit resolution across the bipolar span and signed-integer controller data.

Scaling, clamps, alarms, and communication-fault settings allow 1734-OE2V to serve unipolar references and bipolar command signals without external range conversion. Because the outputs share a non-isolated architecture, load impedance and reference-potential control remain part of the circuit design.

Before applying 1734-OE2V, verify Series C, terminal-base wiring, 10...28.8 V DC field power, receiver input range, common reference, controller profile, startup value, and program-mode response. An OE2C current-output project cannot be reused by changing only engineering units.
Revisions

Revision Part #

Also known as

1734-OE2V Series B
1734-OE2V/B, Series B
1734-OE2V Series C
1734-OE2V/C, Series C
Alternative Names
Allen-Bradley 1734-OE2V Rockwell Automation 1734-OE2V AB 1734-OE2V 1734OE2V 1734 OE2V POINT I/O two-channel voltage output
Technical notes
The key engineering boundary for 1734-OE2V is the selected unipolar or bipolar voltage range. Confirm Series C, 0...10 V or ±10 V configuration, receiver impedance, common reference, terminal-base wiring, field power, scaling, clamps, alarms, startup state, and communication-fault response; then measure both outputs through their complete command span.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should 1734-OE2V be configured for a receiver that expects reverse and forward commands?
Use the documented ±10 V range, verify signed scaling and common reference, then test negative, zero, and positive commands with the machine inhibited.
Why can the zero command from 1734-OE2V still produce movement?
Check receiver zero offset, reference-potential difference, controller scaling, output clamp, wiring common, and the measured terminal voltage before adjusting mechanics.
What happens at startup before 1734-OE2V receives its configuration?
The output remains at 0 V; confirm that this state is safe for the connected receiver and that enabling logic prevents unintended operation.
Can 1734-OE2V drive a low-impedance load intended for a current source?
Do not assume so. Verify the receiver input specification and module load limits; use a current-output catalog when the circuit requires a current loop.
Which checks isolate noise on a 1734-OE2V bipolar command?
Measure output-to-common voltage, inspect shield and grounding, compare controller data, disconnect the receiver safely if permitted, and review nearby switching circuits.
What should a buyer document for a 1734-OE2V spare?
Capture Series, terminal base, voltage ranges, receiver impedance, fallback settings, project profile, quantity, label photos, destination, and required delivery date.
