1747-L543P

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 1747-L543P is an SLC 5/04P processor documented for Pro-Set 200 plastic injection-molding control systems.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 1747-L543P
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 1747-L543P

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    1747-L543P
  • Product Family:
    SLC 500
  • Product Type:
    SLC 5/04P Processor
  • Stock:
    1
  • Processor Family:
    SLC 5/04P
  • Compatible Chassis:
    Same SLC chassis used by other SLC 5/04 processors
  • Compatible Power Supplies:
    Same SLC power supplies used by other SLC 5/04 processors
  • Compatible I/O:
    Same I/O modules used by other SLC 5/04 processors
  • Applicable Hardware Manual:
    1747-UM011
  • Applicable Instruction Reference:
    1747-RM001
  • Pro-Set Job Setting Guide:
    6500-6.9.4
  • Pro-Set Design Manual:
    6500-6.2.3
  • Pro-Set Data Table Reference:
    6500-6.4.4
  • Dimensions:
    3.6 × 13.0 × 14.5 cm
  • Weight:
    0.3 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Platform Documentation Replacement Application
  • SLC 5/04P processor identified in Rockwell release notes
  • Uses the established SLC 5/04 chassis, power-supply, and I/O platform
  • Referenced with Pro-Set 200 job-setting, design, and data-table documentation

1747-L543P supports legacy SLC 5/04P installations built around the Pro-Set 200 application environment and their established rack architecture.

For maintenance planning, treat the controller program, Pro-Set job data, PanelView files, and machine sequence as one coordinated control package rather than independent assets.

When preparing a swap, document the processor series, slot arrangement, communications, I/O order, and verified backups so the replacement can be commissioned against the existing machine configuration.

Availability, condition, price, and shipping time for 1747-L543P are confirmed during quotation.

Allen-Bradley 1747-L543P Manuals, Product Family, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The processor belongs to the SLC 5/04P group
  • It uses the same chassis and power supplies as other SLC 5/04 processors
  • It supports the same SLC 5/04 I/O platform
  • 1747-UM011 covers modular SLC hardware
  • 1747-RM001 provides the SLC instruction reference
  • Three dedicated Pro-Set 200 publications are listed for the application
  • Match the complete P-suffix catalog number
  • Preserve Pro-Set data tables and machine-specific ladder changes
  • Confirm the installed Series B or C hardware and associated project
  • Plastic injection-molding machine sequence control
  • Pressure and velocity profile control in Pro-Set 200 systems
  • Mold-part recipe, barrel-temperature, sensor, and valve coordination
Description
1747-L543P is the P-version SLC 5/04 processor listed by Rockwell for a Pro-Set 200 control environment.

Its hardware platform follows the SLC 5/04 chassis, supply, and I/O arrangement, while the application depends on the Pro-Set data structure and machine-specific control program.

Before replacement, preserve the processor program, Pro-Set tables, PanelView application, hardware series, I/O order, communications, and validated machine sequence.
Revisions

Revision Part #

Also known as

1747-L543P Ser B
1747-L543P/B, Series B, Rev B
1747-L543P Ser C
1747-L543P/C, Series C, Rev C
Alternative Names
1747-L543P 1747 L543P 1747L543P Allen-Bradley 1747-L543P Allen Bradley 1747-L543P Rockwell Automation 1747-L543P SLC 5/04P 1747-L543P
Technical notes
1747-L543P requires matched Series B/C hardware, SLC project, Pro-Set data tables, PanelView files, I/O layout, and machine-specific ladder logic; a base 1747-L543 is not equivalent.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What is the main ordering risk when sourcing Allen-Bradley 1747-L543P?
The P suffix identifies the SLC 5/04P processor used with Pro-Set 200 documentation. Do not accept a standard 1747-L543 solely because the base memory designation looks similar.
Can the existing SLC 5/04 chassis hardware remain when installing Allen-Bradley 1747-L543P?
Rockwell states that the 5/04P uses the same chassis, power supplies, and I/O modules as other SLC 5/04 processors, but the exact series, project, and machine configuration must still match.
Which project records should be saved before replacing Allen-Bradley 1747-L543P?
Back up the SLC program, data tables, Pro-Set job settings, PanelView files, I/O configuration, channel settings, and any machine-specific ladder modifications.
Where should a technician look when standard SLC manuals do not explain Allen-Bradley 1747-L543P machine functions?
Use the Pro-Set 200 job-setting, design, and data-table manuals referenced by Rockwell together with the standard SLC 500 hardware and instruction-set documentation.
Must the hardware series be checked for Allen-Bradley 1747-L543P?
Yes. Official certification evidence covers Series B or C, so match the installed series, firmware, project, and certification requirements before replacement.
Can the memory module already fitted to a controller be reused with Allen-Bradley 1747-L543P?
Confirm the memory-module catalog, connector, jumper arrangement, stored image, and project compatibility first; the official installation instruction lists 1747-L543P but does not make every memory module interchangeable.
What machine functions should be tested after installing Allen-Bradley 1747-L543P?
Validate the complete injection-molding sequence, pressure and velocity profiles, temperature control, valve and sensor operation, alarms, recipes, and operator-interface commands.
