  • Lifecycle status

    Active / Available from OEM
    Apter Power verifies catalog identity, coating, touch configuration, condition, and documentation before coordinating quotation and dispatch.

2715P-T15CD-K

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2715P-T15CD-K is a conformal-coated PanelView 5510 terminal with a 15-inch XGA resistive-touch display and two DLR-capable Ethernet ports for Logix-based visualization.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2715P-T15CD-K
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2715P-T15CD-K

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2715P-T15CD-K
  • Product Family:
    Allen Bradley Panelviews
  • Product Type:
    Graphic Terminal
  • Stock:
    1
  • Display Size:
    15 in.
  • Operator Input:
    Resistive touch plus menu navigation button
  • Conformal Coated:
    Yes
  • Resolution:
    1024 × 768 XGA
  • Memory:
    1 GB RAM; 1 GB user project storage
  • Ethernet:
    Two 10/100Base-T ports with DLR
  • Input Voltage:
    24 V DC nominal (18…30 V DC)
  • Weight:
    3.69 kg
  • Estimated shipping dimensions:
    31.8 × 38.1 × 6.96 cm
  • Tariff Code:
    Please confirm the destination before shipping
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Touch Workflow View Designer Panel Integration Product Applications

Features:

  • 15-inch XGA resistive-touch display with menu navigation
  • Conformal-coated PanelView 5510 catalog configuration
  • Two Ethernet ports supporting DLR, linear, or star topology
Allen-Bradley 2715P-T15CD-K provides a touch-only 15-inch operator interface, separating it from the B15 keypad configuration in the same PanelView 5510 family.

View Designer and Logix Designer share the Studio 5000 environment, keeping visualization and controller work inside a coordinated engineering workflow.

The -K suffix identifies the conformal-coated configuration, while the documented panel construction and environmental limits still govern installation.

Apter Power can coordinate 2715P-T15CD-K supply with coating, touch-interface, project, and panel-installation records.
2715P-T15CD-K Manuals, Datasheets, Links Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Build screen navigation for resistive-touch operation
  • Account for the menu navigation button in operator procedures
  • Validate touch targets and project behavior on the installed terminal
  • Create the HMI project in the Studio 5000 environment
  • Validate controller references before download
  • Archive the accepted project and terminal firmware record
  • Provide 24 V DC from a SELV or PELV supply
  • Use the documented 15-inch touch-terminal cutout
  • Select DLR, linear, or star Ethernet topology
  • Treat conformal coating as one protection layer, not the enclosure rating
  • Operate Logix-based machines through a 15-inch touch interface
  • Present alarms, process views, and operator commands in a View Designer project
  • Support industrial visualization where the documented coated touch configuration is required
Description
The conformal-coated Allen-Bradley 2715P-T15CD-K is a PanelView 5510 operator terminal built around a 15-inch, 1024 × 768 XGA resistive-touch display with a menu navigation button.

Within the Studio 5000 environment, Allen-Bradley 2715P-T15CD-K uses View Designer for HMI projects and communicates through two 10/100Base-T Ethernet ports that support DLR, linear, or star topologies. Its T15 catalog configuration is touch-only rather than the B15 keypad arrangement.

For a panel project, Allen-Bradley 2715P-T15CD-K brings a coated PCBA configuration to a 15-inch touch interface intended for documented industrial environments. Engineers can use the common View Designer and Logix Designer environment to coordinate visualization with the associated CompactLogix or ControlLogix application.
Revisions

Revision Part #

Also known as

2715P-T15CD-K Ser A
2715P-T15CD-K/A, Series A, Rev A
Alternative Names
Allen-Bradley 2715P-T15CD-K terminal 2715P T15CD K 2715PT15CDK PanelView 5510 15-inch touch HMI AB conformal-coated 5510 terminal
Technical notes
Catalog coding is critical for Allen-Bradley 2715P-T15CD-K: T15 identifies the touch-only 15-inch terminal, while B15 identifies the keypad version. Retain the -K conformal-coating suffix, use a SELV or PELV 24 V DC supply, and match the panel cutout, Ethernet design, and View Designer project to the exact terminal.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
How should 2715P-T15CD-K touch navigation be represented in a View Designer project?
Build the required screen objects for resistive-touch operation, account for the menu navigation button, and validate operator paths on the target terminal before production use.
Does 2715P-T15CD-K conformal coating remove the need for enclosure review?
No. The coating is a terminal feature; the enclosure, cutout sealing, ambient ratings, and site contaminants still require separate assessment.
Which network layouts can 2715P-T15CD-K support?
Its two Ethernet ports support DLR, linear, or star topology. Select one documented architecture and preserve its addressing and resilience rules.
What should be checked when 2715P-T15CD-K shows STS or ERR indications?
Use the terminal status indicators with the View Designer and controller diagnostics, then check power, network, project download, and configured controller paths.
How can 2715P-T15CD-K project transfer be planned safely?
Archive the current View Designer application, record firmware and controller references, and test the restored project on the target terminal before production use.
Which accessories are relevant to 2715P-T15CD-K panel maintenance?
Review the approved protective overlay, mounting hardware, SD storage, and replacement battery against the exact terminal and enclosure requirements.
