Allen-Bradley 2711P-T12C4A8 is the PanelView Plus 6 1250 Touch Terminal for PanelView Plus 6. It provides a 12.1-inch touch operator interface for FactoryTalk View Machine Edition applications.
In Stock
Ships by Friday, October 30
Get a quick price for 2711P-T12C4A8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-T12C4A8

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-T12C4A8
  • Product Family:
    Panelview Plus
  • Product Type:
    PanelView Plus 6 Operator Terminal
  • Stock:
    1
  • Terminal Family:
    PanelView Plus 6
  • Terminal Size:
    1250
  • Input Type:
    Touchscreen
  • Display:
    12.1-inch color TFT
  • Resolution:
    800 x 600 pixels
  • Color Depth:
    18-bit graphics
  • Ethernet:
    Integrated 10/100 port
  • Serial Port:
    RS-232
  • USB:
    Two host ports
  • Removable Storage:
    Secure Digital card slot
  • Input Power:
    85-264 VAC
  • Frequency:
    47-63 Hz
  • Operating System:
    Windows CE 6.0
  • Runtime Software:
    FactoryTalk View Machine Edition
  • Application Memory:
    512 MB RAM
  • Nonvolatile Memory:
    512 MB
  • Panel Cutout:
    257 x 338 mm
  • Environmental Rating:
    NEMA/UL Type 12, 13 and 4X indoor; IEC IP54/IP66
  • Approximate Weight:
    3.2 kg
  • Lifecycle:
    Discontinued 2021-12-30
  • Engineering Replacement:
    2711P-T12W22A9P
  • Weight:
    7.055 lbs (3.2 kg)
  • Estimated shipping dimensions:
    36.3x28.2x5.5cm
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Communication Configuration Performance

Features:

  • Terminal family is set to PanelView Plus 6.
  • The module's terminal size is 1250.
  • The input type is Touchscreen.
2711P-T12C4A8 combines terminal family of PanelView Plus 6, terminal size of 1250, and input type of Touchscreen in the PanelView Plus 6 platform.

It provides a 12.1-inch touch operator interface for FactoryTalk View Machine Edition applications. This role connects the PanelView Plus 6 1250 Touch Terminal to the surrounding PanelView Plus 6 architecture.

Before commissioning, back up the FactoryTalk View ME application before removal; compare display, power, network and panel-cutout requirements; and treat 2711P-T12W22A9P as an engineered replacement rather than a drop-in unit.

Availability is subject to Apter Power inventory and sourcing confirmation.
Verified resources for Allen-Bradley 2711P-T12C4A8: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Presents alarms, trends and machine status to plant-floor operators.
  • Runs FactoryTalk View ME applications for ControlLogix and CompactLogix equipment.
  • Supports panel-mounted operator stations in industrial control enclosures.
  • This configuration uses integrated 10/100 port for ethernet.
  • The applicable value for serial port is RS-232.
  • The design provides two host ports for USB.
  • Operation uses Secure Digital card slot as the removable storage setting.
  • The configured value for operating system is Windows CE 6.0.
  • System integration relies on FactoryTalk View Machine Edition for runtime software.
  • Hardware setup assigns 12.1-inch color TFT to display.
  • The requirement for resolution corresponds to 800 x 600 pixels.
  • This assembly specifies 18-bit graphics for color depth.
Description
Allen-Bradley 2711P-T12C4A8 is a PanelView Plus 6 1250 Touch Terminal for the PanelView Plus 6 platform. It provides a 12.1-inch touch operator interface for FactoryTalk View Machine Edition applications. The design preserves the hardware role required by the installed control platform.

The display is 12.1-inch color TFT. The resolution is 800 x 600 pixels. This combination helps engineers preserve the PanelView Plus 6 1250 Touch Terminal's intended interface and operating role.

The color depth is 18-bit graphics. The ethernet is Integrated 10/100 port. These features provide a clear fit for PanelView Plus 6 expansion, service, or lifecycle support.
Revisions

Revision Part #

Also known as

2711P-T12C4A8 Ser A
2711P-T12C4A8/A, Series A, Rev A
2711P-T12C4A8 Ser B
2711P-T12C4A8/B, Series B, Rev B
2711P-T12C4A8 Ser C
2711P-T12C4A8/C, Series C, Rev C
2711P-T12C4A8 Ser D
2711P-T12C4A8/D, Series D, Rev D
2711P-T12C4A8X
2711P-T12C4A8/X, Series X, Rev X
Alternative Names
2711P-T12C4A8 2711PT12C4A8 Allen-Bradley 2711P-T12C4A8 PanelView Plus 6 1250 PanelView 2711P-T12C4A8 AB 2711P-T12C4A8 2711P T12C4A8 2711P-T12C4A8 PanelView Plus 6 1250 Touch Terminal
Technical notes
Before servicing 2711P-T12C4A8, back up the FactoryTalk View ME application before removal; compare display, power, network and panel-cutout requirements before commissioning.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What terminal family separates 2711P-T12C4A8 from nearby variants?
Terminal family is set to PanelView Plus 6. This characteristic separates the PanelView Plus 6 1250 Touch Terminal from visually similar hardware.
Which installed interface must suit 2711P-T12C4A8?
Confirm the PanelView Plus 6 architecture, then back up the FactoryTalk View ME application before removal. Compatibility depends on the installed interfaces and project configuration.
What maintenance scenario calls for 2711P-T12C4A8?
Runs FactoryTalk View ME applications for ControlLogix and CompactLogix equipment. The selected use must remain within the intended PanelView Plus 6 architecture.
What information speeds a quote for 2711P-T12C4A8?
Provide clear nameplate photographs, required condition, quantity, destination, and the installed-system context. Apter Power can then review sourcing options.
Can 2711P-T12C4A8 be replaced without an engineering check?
Do not assume a drop-in substitution. Compare display, power, network and panel-cutout requirements. Compare mechanical, electrical, communication, and software dependencies before approval.
Which records help validate a 2711P-T12C4A8 order?
Use the model-specific PDF in Manuals and compare the module's display is 12.1-inch color tft and the color depth is 18-bit graphics with the installed equipment before requesting a quote.
