2711P-K12C4A8

/ 4.9
1001 reviews | Need a Specific Revision?
Allen-Bradley 2711P-K12C4A8 is a 12.1-inch PanelView Plus 6 color keypad terminal with Ethernet, RS-232, AC input and Windows CE 6.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 2711P-K12C4A8
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-K12C4A8

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-K12C4A8
  • Product Family:
    Panelview Plus
  • Product Type:
    PanelView Plus 6 Keypad Graphic Terminal
  • Stock:
    1
  • Display Size:
    12.1 in
  • Display Type:
    Color TFT
  • Resolution:
    800 × 600
  • Brightness:
    300 cd/m²
  • Function Keys:
    F1–F20 and K1–K20
  • Ethernet Port:
    10/100 Mbps
  • Serial Port:
    RS-232
  • USB Host Ports:
    Two
  • Removable Storage:
    SD card
  • RAM:
    512 MB
  • Nonvolatile Storage:
    512 MB; approximately 79 MB user storage
  • Operating System:
    Windows CE 6
  • Application Software:
    FactoryTalk View Machine Edition 6.0 or later
  • Power Input:
    100–240 V AC, 50/60 Hz
  • Power Consumption:
    160 VA maximum; 65 VA typical
  • Operating Temperature:
    0 to +55 °C
  • Storage Temperature:
    -25 to +70 °C
  • Relative Humidity:
    5–95%, noncondensing
  • Maximum Altitude:
    2,000 m
  • Front Rating:
    IP65 and NEMA 4X indoor when correctly mounted
  • Dimensions:
    41.6 × 28.2 × 5.5 cm
  • Weight:
    3.4 kg
  • Tariff Code:
    8537101190
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Operator Interface Communication and Storage Migration Planning Application
  • 12.1-inch color PanelView Plus 6 terminal with 800 × 600 graphics
  • Forty programmable keypad functions for gloved industrial operation
  • Ethernet and RS-232 communication with AC-powered A8 computing platform

2711P-K12C4A8 provides a keypad-driven operator interface for FactoryTalk View Machine Edition applications.

Its 12.1-inch color display and dedicated function keys support machine control, alarm response, status viewing and controlled data entry without relying on a touchscreen.

A successful replacement depends on the saved HMI project, communication configuration, installed files, panel sealing, power wiring and a tested migration plan for any newer terminal platform.

Availability, condition, price, and shipping time for 2711P-K12C4A8 are confirmed during quotation.

Allen-Bradley 2711P-K12C4A8 PanelView Plus 6 Terminal Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Combines a 12.1-inch SVGA color display with a physical keypad
  • Provides F1–F20 and K1–K20 application-programmable function keys
  • Uses a stainless-steel membrane suited to repeated industrial operation
  • Connects to plant networks through 10/100 Mbps Ethernet
  • Supports legacy serial equipment through the RS-232 interface
  • Uses two USB host ports and removable SD media for peripherals and file transfer
  • Retain the editable FactoryTalk View ME project and terminal backup
  • Use adapter plate 2711P-RAAT12K for the documented 12-inch migration path
  • Validate keypad-dependent navigation before moving to a touch-only replacement
  • Keypad-operated machine sequencing and mode selection
  • Production status, alarm acknowledgement and process data entry
  • FactoryTalk View ME visualization for controller-based automation systems
Description
2711P-K12C4A8 is an Allen-Bradley PanelView Plus 6 operator terminal with a 12.1-inch color display and a stainless-steel membrane keypad.

The terminal combines 800 × 600 graphics, forty programmable function keys, Ethernet and RS-232 communication, two USB host ports, removable SD storage and an AC power input. The A8 platform provides Windows CE 6 with 512 MB RAM and 512 MB nonvolatile storage.

Replacement requires the saved FactoryTalk View ME application, communication settings, user files and security records to be retained. Verify the panel cutout, front gasket, keypad operation, AC supply, peripheral wiring and migration hardware before commissioning.
Alternative Names
2711P-K12C4A8 Allen-Bradley 2711P-K12C4A8 AB 2711P-K12C4A8 2711PK12C4A8 2711P K12C4A8 PanelView Plus 6 2711P-K12C4A8 2711P-K12C4A8 Keypad HMI 2711P K12 C4 A8
Technical notes
Allen-Bradley 2711P-K12C4A8 replacement requires a verified FactoryTalk View ME backup, AC power and grounding, Ethernet and RS-232 settings, keypad assignments, removable-media content, panel sealing and the approved migration adapter when changing terminal families.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What should be backed up before replacing Allen-Bradley 2711P-K12C4A8?
Retain the FactoryTalk View ME runtime and source project, terminal communication settings, recipes, data logs, security configuration, startup options and any files stored on internal or removable media.
Can Allen-Bradley 2711P-K12C4A8 be replaced by a touch-only terminal without panel changes?
No direct fit should be assumed. The official migration path uses a touch-only PanelView Plus 7 Performance terminal and requires adapter plate 2711P-RAAT12K plus application and communication review.
What network and serial connections must be matched for Allen-Bradley 2711P-K12C4A8?
Preserve the Ethernet addressing and topology, RS-232 pinout and protocol, connected USB devices and any storage-card workflow used by the existing application.
Why can an application behave differently after migrating from Allen-Bradley 2711P-K12C4A8?
A newer terminal can use a different runtime version, operating system, screen aspect behavior and communication architecture. Convert and validate the application rather than loading it without review.
What panel work is normally needed when replacing Allen-Bradley 2711P-K12C4A8?
Inspect the original cutout, mounting-stud area and enclosure depth, then follow the migration instructions for the approved adapter plate and gasket so the environmental seal is preserved.
How should the keypad on Allen-Bradley 2711P-K12C4A8 be verified before service?
Test every required function and navigation key against the loaded application, confirm legends and key assignments, and check that the stainless membrane is not damaged or lifting at the edges.
What commissioning checks matter after installing Allen-Bradley 2711P-K12C4A8?
Verify AC supply and grounding, application startup, controller communications, alarms, data entry, recipes, USB and SD media, display visibility, keypad response and the compressed front gasket.
