Allen-Bradley 2711P-T7C22D9P is an active 6.5-inch PanelView Plus 7 Performance touchscreen terminal with dual Ethernet DLR ports.
In Stock
Ships by Thursday, October 29
Fast Shipping Available
Get a quick price for 2711P-T7C22D9P
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 2711P-T7C22D9P

  • Manufacturer:
    Allen-Bradley
  • Part Number:
    2711P-T7C22D9P
  • Product Family:
    Panelview Plus
  • Product Type:
    PanelView Plus 7 Performance Graphic Terminal
  • Stock:
    1
  • Display Size:
    6.5 in
  • Display Type:
    Color TFT
  • Resolution:
    640 × 480 VGA
  • Aspect Ratio:
    4:3
  • Touch Technology:
    Analog resistive
  • Typical Brightness:
    300 cd/m²
  • Ethernet Ports:
    2 × 10/100Base-T with Device Level Ring
  • USB Ports:
    1 host, 1 device
  • Input Power:
    18…30 V DC
  • Dimensions:
    21.2 × 17.0 × 6.96 cm
  • Weight:
    1.2 kg
  • Tariff Code:
    8537109090
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Memory Accessories Power Applications
  • 6.5-inch color TFT display with 640 × 480 VGA resolution
  • Analog resistive touchscreen for PanelView Plus 7 Performance applications
  • Dual 10/100Base-T Ethernet ports with Device Level Ring support

2711P-T7C22D9P provides the operator display and touch interface for a PanelView Plus 7 Performance HMI application.

Replacement planning must preserve the FactoryTalk View ME project, communication path, terminal settings, user files, and supported firmware environment.

Confirm the exact catalog number, hardware series, panel cutout, mounting hardware, gasket, DC power, Ethernet topology, and connected peripherals before installation.

Availability, condition, price, and shipping time for 2711P-T7C22D9P are confirmed during quotation.

Allen-Bradley 2711P-T7C22D9P PanelView Plus 7 Performance Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • Series A provides 512 MB RAM and 512 MB storage
  • Series B provides 4 GB RAM and 19.87 GB storage
  • Approximate user storage is 80 MB for Series A and 2 GB for Series B
  • Use black 2711P-RMCP replacement mounting levers; gray mounting levers are not compatible
  • The SD-card slot supports 1784-SD1, 1784-SD2, 1784-SDHC8, and 1784-SDHC32 cards
  • The documented replacement battery is 2711P-RY2032, equivalent to a CR2032 lithium coin cell
  • Series A maximum power consumption is 50 W
  • Series B maximum power consumption is 29 W
  • The DC terminal supports SELV and PELV 24 V DC power supplies
  • PanelView Plus 7 Performance machine operator interfaces
  • Touchscreen HMI applications using 640 × 480 VGA graphics
  • EtherNet/IP installations that use dual Ethernet DLR connections
Description

2711P-T7C22D9P is an Allen-Bradley PanelView Plus 7 Performance graphic terminal with a 6.5-inch color TFT display, 640 × 480 VGA resolution, and analog resistive touch input.

The terminal operates from 18…30 V DC and provides two 10/100Base-T Ethernet ports with Device Level Ring support. Series A provides two USB 2.0 host ports and uses Windows CE 6.0; Series B provides one USB 3.0 host port plus one USB 2.0 host port and uses Windows 10 IoT Core. Both series include one USB 2.0 device port identified in Rockwell Automation technical data as reserved for future functionality.

Before installation or replacement, back up the FactoryTalk View ME application and terminal settings, then verify the hardware series, firmware, cutout, gasket, DC supply, Ethernet topology, USB devices, and peripheral compatibility.

Revisions

Revision Part #

Also known as

2711P-T7C22D9P Series A
2711P-T7C22D9P/A, Series A
2711P-T7C22D9P Series B
2711P-T7C22D9P/B, Series B
Alternative Names
2711P-T7C22D9P 2711PT7C22D9P 2711P T7C22D9P Allen-Bradley 2711P-T7C22D9P Allen Bradley 2711P-T7C22D9P AB 2711P-T7C22D9P Rockwell Automation 2711P-T7C22D9P PanelView Plus 7 2711P-T7C22D9P
Technical notes
2711P-T7C22D9P requires the FactoryTalk View ME backup, hardware series, firmware, panel cutout, gasket, 18…30 V DC supply, Ethernet topology, and connected peripherals to be verified before replacement.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can an existing FactoryTalk View ME application be restored to Allen-Bradley 2711P-T7C22D9P?
Restore only after checking the application version, terminal firmware, hardware series, communication paths, and any unsupported runtime features.
Will Allen-Bradley 2711P-T7C22D9P fit an existing PanelView cutout without panel changes?
Compare the official cutout drawing, terminal dimensions, gasket, mounting hardware, and surrounding clearances before assuming a drop-in fit.
Can Allen-Bradley 2711P-T7C22D9P join a Device Level Ring network?
Yes. The catalog number provides two Ethernet ports with DLR support, but the saved topology and device configuration must be restored correctly.
What should be backed up before replacing Allen-Bradley 2711P-T7C22D9P?
Back up the runtime application, communication configuration, terminal settings, user files, security information, and any removable media contents.
Does Allen-Bradley 2711P-T7C22D9P have a physical keypad?
No. This T-series catalog number uses touchscreen input, so the application must provide the required on-screen navigation and controls.
Why must the hardware series be checked for Allen-Bradley 2711P-T7C22D9P?
Series A and Series B terminals can differ in hardware resources and supported firmware, which can affect image restoration and application compatibility.
What details should accompany a quote request for Allen-Bradley 2711P-T7C22D9P?
Provide the full catalog number, hardware series, firmware, application version, supply voltage, required condition, quantity, and clear nameplate and connector photos.
