B&R 8BVI0055HWD0.000-1 is an ACOPOSmulti 2-axis inverter module rated 7.6 Aeff continuous per motor connection with wall mounting.
In Stock
Ships by Wednesday, October 28
Fast Shipping Available
Get a quick price for 8BVI0055HWD0.000-1
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 8BVI0055HWD0.000-1

  • Manufacturer:
    B&R
  • Part Number:
    8BVI0055HWD0.000-1
  • Product Family:
    B&R ACOPOS
  • Product Type:
    ACOPOSmulti 2-axis Inverter Module
  • Stock:
    1
  • Motor connections:
    2
  • Continuous power per motor connection:
    5.5 kW
  • Continuous current per motor connection:
    7.6 Aeff
  • Peak current per motor connection:
    18.9 Aeff
  • Nominal DC bus voltage:
    750 VDC
  • Continuous DC bus power consumption:
    11.19 kW
  • DC bus capacitance:
    330 µF
  • 24 VDC supply input:
    25 VDC ±1.6%
  • Slots for plug-in modules:
    2
  • Nominal switching frequency:
    5 kHz
  • Maximum output frequency:
    598 Hz
  • Dynamic node allocation:
    Supported
  • Degree of protection:
    IP20
  • Operating temperature:
    5 to 40 °C nominal; 55 °C maximum with derating
  • Maximum installation elevation:
    4000 m; current derating starts above 500 m
  • Dimensions:
    5.3 × 31.7 × 26.3 cm
  • Weight:
    2.9 kg
  • Tariff Code:
    8503009090
  • Country of origin:
    Germany
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals DC Bus Axis Configuration Installation Application
  • Provides 2 independent motor connections at 7.6 Aeff each
  • Installs by wall mounting on an ACOPOSmulti system
  • Includes motor-brake, temperature-sensor, enable and trigger interfaces

8BVI0055HWD0.000-1 is an ACOPOSmulti 2-axis inverter module rated 7.6 Aeff continuous per motor connection with wall mounting.

It supplies 2 independently controlled motor axes from the ACOPOSmulti DC bus and provides motor-brake, temperature-sensor, enable and trigger connections.

Before installation or replacement, verify the complete material number and ACOPOSmulti backplane and power-supply compatibility, cooling method, motor and feedback data, required terminal and shielding sets, plug-in modules, saved parameters, enable wiring, grounding and cabinet thermal design.

Availability, condition, price, and shipping time for 8BVI0055HWD0.000-1 are confirmed during quotation.

B&R 8BVI0055HWD0.000-1 Manuals, Datasheets, Links

Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.

  • The inverter operates from the ACOPOSmulti 750 VDC nominal bus
  • The 25 VDC electronics supply and bus power must both be available
  • Backplane, supply and regenerative power budgets must be checked for the full station
  • The module provides 2 motor connections
  • Each connection is rated 7.6 Aeff continuous and 18.9 Aeff peak
  • Motor, feedback, brake and temperature-sensor assignments must match the saved project
  • The documented mounting method is wall mounting
  • Airflow or cold-plate thermal design must satisfy the documented derating limits
  • Required terminal, shielding and plug-in components must be confirmed separately
  • Paper and print-processing machines using registration and cross-cutting motion
  • Packaging equipment using synchronized sealing, labeling, and product-feed axes
  • Textile machinery using coordinated winding, unwinding, and line-shaft functions
Description
8BVI0055HWD0.000-1 is an ACOPOSmulti 2-axis inverter module rated 7.6 Aeff continuous per motor connection with wall mounting.

It supplies 2 independently controlled motor axes from the ACOPOSmulti DC bus and provides motor-brake, temperature-sensor, enable and trigger connections.

Before installation or replacement, confirm the complete material number and ACOPOSmulti backplane and power-supply compatibility, cooling method, motor and feedback data, required terminal and shielding sets, plug-in modules, saved parameters, enable wiring, grounding and cabinet thermal design.
Alternative Names
8BVI0055HWD0.000-1 8BVI0055HWD0 000 1 8BVI0055HWD00001 B&R 8BVI0055HWD0.000-1 BR 8BVI0055HWD0.000-1 B&R ACOPOSmulti 8BVI0055HWD0.000-1 ACOPOSmulti 8BVI0055HWD0.000-1
Technical notes
B&R 8BVI0055HWD0.000-1 requires exact motor, feedback, power, cooling, accessory and parameter matching. Record the installed configuration and validate grounding, shielding, thermal limits, enable or safety wiring and controlled startup before returning the axis to service.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
Can B&R 8BVI0055HWD0.000-1 directly replace an HCD0 or HCS0 cooling variant?
No. The HWD0 suffix identifies a specific cooling and mounting configuration. Confirm the complete material number, cooling interface, dimensions, connector arrangement, axis ratings and installed hardware before substitution.
How can maintenance identify whether a fault belongs to one axis or the complete B&R 8BVI0055HWD0.000-1 module?
Compare alarms and live values by channel, inspect the associated motor, feedback, brake, sensor, and cable, and use only approved isolation or swap tests that do not risk the healthy axis.
How does switching frequency affect the continuous-current rating of B&R 8BVI0055HWD0.000-1?
No derating is specified at 5 kHz. At 10 kHz, derating is 0.22 A/K beginning at 43°C; at 20 kHz, it is 0.15 A/K beginning at –14°C.
Which backup information reduces downtime when replacing B&R 8BVI0055HWD0.000-1?
Keep the complete Automation Studio project plus separate records for both axes, including motor and encoder data, limits, homing, gearing, tuning, brake timing, safety configuration, and fault history.
Which terminal block set is mandatory for B&R 8BVI0055HWD0.000-1?
B&R specifies the 8BZVI0055D0.000-1A screw-clamp terminal block set as a mandatory accessory.
What should be monitored during the first loaded run of B&R 8BVI0055HWD0.000-1?
Monitor both axis currents and faults, DC-bus behavior, motor and cabinet temperature, brake operation, feedback stability, regeneration, vibration, and airflow while gradually increasing speed and load.
What should be checked after installing B&R 8BVI0055HWD0.000-1?
Confirm connectors and shielding, cooling, bus and 24 VDC voltages, project hardware identity, feedback direction, motor brake, enable chain, fault-free startup and controlled low-speed motion before production.
