31000-28-10-00-165-01-02

/ 4.9
1001 reviews | Need a Specific Revision?
Bently Nevada 31000-28-10-00-165-01-02 is an English proximity probe housing assembly with a multiple-approval 3300 XL 8 mm probe, 1.0 m cable, no standoff adapter, 16.5 in penetration and one NPT fitting.
In Stock
Ships by Saturday, October 31
Fast Shipping Available
Get a quick price for 31000-28-10-00-165-01-02
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 31000-28-10-00-165-01-02

  • Manufacturer:
    Bently Nevada
  • Part Number:
    31000-28-10-00-165-01-02
  • Product Family:
    31000 and 32000 Proximity Probe Housing Assemblies
  • Product Type:
    Proximity Probe Housing Assembly
  • Stock:
    1
  • Probe option:
    3300 XL 8 mm probe, multiple approvals
  • Probe cable length:
    1.0 m (39 in)
  • Standoff adapter:
    00 = no standoff adapter
  • Probe penetration:
    165 = 16.5 in nominal
  • Fitting option:
    01 = one 3/4-14 NPT fitting and two plugs
  • Mounting thread:
    3/4-14 NPT
  • Housing material:
    Glass-reinforced PPS thermoplastic with conductive fibers
  • Sleeve material:
    AISI 304 stainless steel
  • Outer sleeve and screws:
    AISI 303 stainless steel
  • Mechanical protection:
    NEMA 4X and IP66
  • Operating and storage temperature:
    -51°C to +177°C
  • API compliance:
    API 670 externally mounted proximity probe housing
  • Typical housing weight:
    1.2 kg (2.6 lb)
  • Retaining nut torque:
    29.4 N·m (260 in·lb)
  • Probe penetration adjustment:
    ±0.5 in (13 mm)
  • Long penetration support:
    Additional sleeve support recommended above 12 in
  • Impact strength:
    4 J low/high temperature impact; CSA 7 J ambient impact
  • Pressure capability:
    Mechanical/environmental protection only; not pressure-rated
  • Hazardous-area use:
    Usable with approved transducer system and appropriate I.S. barriers
  • Conduit note:
    Hardline conduit requires the specified NPT fitting
  • Weight:
    2.6 lbs (1.2 kg)
  • Estimated shipping dimensions:
    91.4 × 144.8 × 76.2 mm.
  • Tariff Code:
    Please confirm the destination before shipping.
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen,Fujian,China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Applications Configuration Operating Environment Diagnostics

Features:

  • Multiple-approval 3300 XL 8 mm probe is paired with a 1.0 m cable.
  • The housing provides a 16.5 in penetration with no standoff adapter.
  • One 3/4-14 NPT fitting and two plugs complete the English conduit arrangement.
This configuration is selected for long-reach through-case monitoring where the probe must pass deep into the machine.

The external housing preserves access to the sensor cable while the PPS body and stainless components shield the assembly from the surrounding environment.

Because the penetration is longer than 12 in, plan sleeve support and verify the machine casing geometry before tightening the retaining hardware.

The 31000-28-10-00-165-01-02 is supplied with the published multiple-approval English options.
Verified resources for Bently Nevada 31000-28-10-00-165-01-02: Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Long-reach radial vibration measurements inside a machine casing.
  • Keyphasor sensing where an approved 3300 XL probe is installed through the case.
  • Condition-monitoring retrofits that retain external cable and probe access.
  • Option 28 selects the multiple-approval 3300 XL 8 mm probe.
  • Option 165 sets the nominal probe penetration at 16.5 inches.
  • Option 01 defines one NPT fitting with two blanking plugs.
  • The 3300 XL 8 mm probe operating and storage range is -51°C to +177°C.
  • The PPS enclosure resists corrosion while stainless sleeves protect the probe path.
  • Hot water and condensing steam exposure require the limits stated in the datasheet.
  • The housing keeps the probe accessible for gap adjustment during maintenance.
  • External cable access supports inspection without removing the machine casing.
  • Leakage and pressure conditions must be assessed because the housing is not pressure-rated.
Description
Bently Nevada 31000-28-10-00-165-01-02 is an English proximity probe housing assembly that combines a multiple-approval 3300 XL 8 mm probe with a 1.0 m cable and a nominal 16.5 in penetration. The absence of a standoff adapter allows the probe sleeve to be arranged directly for the selected machine-case geometry.

One 3/4-14 NPT fitting and two plugs provide the specified conduit entry while the PPS enclosure and stainless sleeve protect the sensing path. External access keeps the probe and extension cable serviceable for gap adjustment or replacement without opening the machine casing.

The long reach should be reviewed against sleeve resonance, casing thickness and support requirements before installation. Match the multiple-approval probe to the monitoring system and any intrinsic-safety barriers, remembering that the housing is protective rather than explosion-proof.
Alternative Names
31000-28-10-00-165-01-02 310002810001650102 31000 multiple approval housing Bently Nevada 31000-28 housing 3300 XL 8 mm multiple approvals housing 31000 16.5 inch penetration 31000 one NPT fitting 31000 English proximity housing
Technical notes
For Bently Nevada 31000-28-10-00-165-01-02, confirm the multiple-approval probe option, 16.5 in penetration, one 3/4-14 NPT fitting and 3/4-14 NPT mounting thread; combined dimensions above 12 in require sleeve support.
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What probe approval option is built into Bently Nevada 31000-28-10-00-165-01-02?
The first code 28 identifies a 3300 XL 8 mm probe with multiple approvals.
What does the 165 code mean on Bently Nevada 31000-28-10-00-165-01-02?
It selects a nominal 16.5 in probe penetration.
How many fittings are included with Bently Nevada 31000-28-10-00-165-01-02?
The E option 01 supplies one 3/4-14 NPT fitting and two plugs.
Does Bently Nevada 31000-28-10-00-165-01-02 have a standoff adapter?
No. The C option is 00, so no standoff adapter is included.
When is sleeve support important for Bently Nevada 31000-28-10-00-165-01-02?
The datasheet recommends added support when standoff plus penetration exceeds 12 inches.
What installation review is needed for Bently Nevada 31000-28-10-00-165-01-02?
Review probe approvals, casing penetration, support, conduit routing and barrier requirements.
