The 330730-040-03-00 is a 3300 XL 11 mm Extension Cable featuring a 4.0 meter (13.1 feet) length with armored cable construction and integrated connector protector.
Get a quick price for 330730-040-03-00
Quantity
*E-mail
Company
*Mobile
*Content
Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)

Technical specifications for 330730-040-03-00

  • Manufacturer:
    Bently Nevada
  • Part Number:
    330730-040-03-00
  • Product Family:
    3300 XL 11mm Proximity Transducer System
  • Product Type:
    3300 XL 11 mm Extension Cable
  • Cable Length:
    4.0 meters (13.1 feet)
  • Cable Type:
    Armored cable with connector protector
  • Agency Approval:
    Not required
  • Sealing Options:
    Integrated connector protector; Silicone tape (provided)
  • Silicone Tape Limitation:
    Not recommended for turbine oil exposure applications
  • Optional Feature:
    FluidLoc cable option (prevents fluid leakage)
  • Key Benefit:
    Model 330730-040-03-00 addresses moisture ingress concerns with integrated connector protectors and provided silicone tape sealing options.
  • Weight:
    0.2 kg
  • Estimated shipping dimensions:
    20.5x22.4x3.3cm
  • Tariff Code:
    8544492100
  • Country of origin:
    USA
  • Place of shipment:
    Xiamen, Fujian, China
By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

More Information

Overview Manuals Specifications Applications Certifications and Standards Compatibility

Features:

  • The 330730-040-03-00 features armored cable construction for mechanical protection against crushing and abrasion.
  • This model includes an integrated connector protector for enhanced environmental sealing in humid or moist environments.
  • The 330730-040-03-00 comes with silicone tape as an alternative sealing option for the probe-to-extension cable connection.
The 330730-040-03-00 includes an integrated connector protector for increased environmental protection in humid or moist installations, directly affecting the long-term reliability of the monitoring system. Silicone tape is provided with each 330730-040-03-00 and can be used as an alternative sealing method for the probe-to-extension cable connection. However, silicone tape is not recommended for applications where the connection will be exposed to turbine oil, as oil exposure can compromise the tape's sealing effectiveness.

For applications requiring enhanced fluid containment, the 330730-040-03-00 can be ordered with an optional FluidLoc cable option, which prevents oil and other liquids from leaking out of the machine through the cable's interior. This option addresses critical safety concerns in lubricated machinery applications. The 330730-040-03-00 is compatible with 3300 XL 11 mm probes that come standard with a locknut featuring pre-drilled safety wire holes for secure installation in high-vibration environments.

The 330730-040-03-00 requires no agency approvals, simplifying procurement for standard industrial monitoring applications. This armored extension cable solves the pain point of cable damage in harsh environments while the integrated connector protector addresses moisture ingress concerns. The 330730-040-03-00 ensures reliable signal transmission for critical machinery monitoring in applications ranging from power generation to industrial processing where mechanical protection and environmental sealing are essential.

The 330730-040-03-00 Bently Nevada 3300 XL 11 mm Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).

Bently Nevada 330730-040-03-00 3300 XL 11 mm Extension Cable Manuals, Datasheets, Drivers, Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
Bently Nevada 330730-040-03-00 3300 XL 11 mm Extension Cable Specs

General

  • Manufacturer GE / Bently Nevada
  • Model 330730-040-03-00
  • Condition New Original ready stock
  • Product Family 330730-080-03-00,330730-040-10-00,330730-040-12-00
Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
  • Small Rotating Machinery: Due to the small magnetic field area (sideview) of the 3300 NSv system, it is ideal for monitoring shafts with a diameter less than 9.5 mm or in narrow mounting locations.
  • Centrifugal Air Compressors and Pumps: Used for measuring axial displacement, radial vibration, and speed.
  • Fluid Dynamics Machinery: Performs excellently in aero-engine testing, small steam turbines, and high-speed industrial equipment.
  • Hazardous Area Certification: Compliant with ATEX, IECEx, and North American (CSA/NRTL) certifications, allowing use in potentially explosive environments such as Class I Division 1 (Zone 0/1).
  • Electromagnetic Compatibility (EMC): Compliant with EN 61000-6-2 and EN 61000-6-4 standards, providing strong resistance to industrial noise interference and ensuring signal transmission accuracy.
  • Environmental Protection: Compliant with RoHS directives, and the cable sheath typically possesses excellent resistance to chemical corrosion (such as resistance to synthetic lubricants and corrosive liquids).
  • System-Specific: Compatible only with 3300 NSv probes and 3300 NSv preamplifiers. It is not compatible with standard 3300 XL 8mm or 5mm systems.
  • Length Matching: Ensure that "probe length + extension cable length = preamplifier rated length" (typically 5 or 7 meters in total) or linearity errors will occur.
  • Interoperability: Connects to Bently Nevada 3500 Series or S1 Series monitoring frames for digital analysis of the preamplifier's output voltage signal.
Description
The 330730-040-03-00 features a 4.0 meter (13.1 feet) length with armored cable construction that provides enhanced mechanical protection against crushing, abrasion, and physical damage in demanding industrial environments. This extension cable includes an integrated connector protector for increased environmental protection in humid or moist installations.

The 330730-040-03-00 is designed for use with 3300 XL 11 mm proximity probes, providing reliable signal transmission between the probe and Proximitor sensor. Silicone tape is provided with each 330730-040-03-00 and can be used as an alternative sealing method for the probe-to-extension cable connection.

This model can be ordered with an optional FluidLoc cable option, which prevents oil and other liquids from leaking out of the machine through the cable's interior. The 330730-040-03-00 is compatible with 3300 XL 11 mm probes that come standard with a locknut featuring pre-drilled safety wire holes for secure installation.

The 330730-040-03-00 represents a complete solution for extending 3300 XL 11 mm proximity probe signals over 4.0 meter distances. This armored extension cable solves the pain point of cable damage in harsh environments while the integrated connector protector addresses moisture ingress concerns.
Alternative Names
330730-080-03-00 330730-040-10-00 330730-040-12-00 330730-040-03-05
Exceptional Service

Our Mission

  • 100% Satisfaction

    We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.
  • Trust Guaranteed

    Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.
  • Expertise

    Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

FAQS

The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
What sealing options are available for the 330730-040-03-00?
The 330730-040-03-00 includes an integrated connector protector for environmental protection and comes with silicone tape for field sealing. Silicone tape is not recommended for turbine oil exposure applications.
What mechanical protection does the armored construction of the 330730-040-03-00 provide?
The armored cable construction protects against crushing, abrasion, and physical damage in demanding industrial environments where standard cables would be vulnerable to mechanical failure.
Can the 330730-040-03-00 be used in applications requiring fluid containment?
Yes, the 330730-040-03-00 can be ordered with an optional FluidLoc cable option that prevents oil and other liquids from leaking out of the machine through the cable's interior.
What is the limitation of using silicone tape with the 330730-040-03-00?
Silicone tape is not recommended for applications where the probe-to-extension cable connection will be exposed to turbine oil, as oil exposure can compromise the tape's sealing effectiveness.
