          This 330101-04-30-05-01-05 identifies a 3300 XL 8 mm proximity probe configuration. Availability and the required revision should be confirmed before ordering.

        330101-04-30-05-01-05

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        Bently Nevada 330101-04-30-05-01-05 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF threads, no armor, a 0.4-inch unthreaded length, a 3.0-inch case and a 0.5-metre standard cable.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330101-04-30-05-01-05
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330101-04-30-05-01-05

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330101-04-30-05-01-05
        • Product Family:
          3300 XL 8 mm Probe
        • Product Type:
          3300 XL 8 mm Proximity Probe
        • Stock:
          1
        • Unthreaded Length Option:
          0.4 in
        • Overall Case Length Option:
          3.0 in
        • Total Length Option:
          0.5 meter (1.6 feet)
        • Connector and Cable-Type Option:
          Miniature coaxial ClickLoc connector with connector protector, standard cable
        • Agency Approval Option:
          CSA, ATEX and IECEx approval option (code 05); installation requirements must follow the applicable approval documents.
        • Nominal Probe DC Resistance:
          7.45 ± 0.50 Ω
        • Standard probe operating and storage temperature:
          −52°C to +177°C (−62°F to +350°F)
        • Weight:
          0.05 kg
        • Estimated shipping dimensions:
          1.6x1.3x116cm
        • Tariff Code:
          8414909090
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Operation Application Scenarios Installation

        Features:

        • TipLoc molding provides a robust bond between the probe tip and probe body
        • CableLoc construction provides a maximum rated pull strength of 330 N (75 lbf) between the probe case and probe lead
        • Standard probe temperature range: −52°C to +177°C (−62°F to +350°F); approval option 05 specifies CSA, ATEX and IECEx approvals
        Bently Nevada 330101-04-30-05-01-05 is a standard forward-mount 3300 XL 8 mm proximity probe with 3/8-24 UNF threads and no armor. Its ordering configuration specifies a 0.4-inch unthreaded length, a 3.0-inch overall case length and a 0.5-metre total probe length.

        The probe uses a miniature coaxial ClickLoc connector with a connector protector and standard FEP-insulated cable. Its nominal DC resistance is 7.45 ± 0.50 Ω. TipLoc and CableLoc construction improve the mechanical connection between the probe body, tip and lead.

        The standard probe operating and storage temperature range is −52°C to +177°C (−62°F to +350°F). Agency option 05 identifies CSA, ATEX and IECEx approvals; applicable installation and hazardous-area requirements must be verified for the complete transducer system.

        Bently Nevada official documentation confirms the ordering configuration, but the official lifecycle status of this exact part number has not been confirmed. Contact Apter Power to verify current availability and revision.
        Bently Nevada 330101-04-30-05-01-05 3300 XL 8 mm Proximity Probe Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 330101-04-30-05-01-05 3300 XL 8 mm Proximity Probe Specs

        General

        • Manufacturer Bently Nevada
        • Model 330101-04-30-05-01-05
        • Apter condition New and unused, subject to inspection and stock confirmation.
        • Product Family 3300 XL 8 mm Proximity Transducer System
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • When used with a matching 3300 XL Proximitor Sensor, the standard 1 m or 5 m system has a nominal incremental scale factor of 7.87 V/mm (200 mV/mil).
        • The matched 3300 XL 8 mm transducer system has a frequency response of 0 to 10 kHz (+0/−3 dB), subject to the specified system configuration and field wiring.
        • The probe must be connected to a compatible 3300 XL Proximitor Sensor. The Proximitor Sensor uses a negative DC supply; −24 Vdc is the nominal system test condition.
        • Steam Turbine Monitoring: Relative shaft vibration and axial position measurements on compatible fluid-film bearing machines.
        • Compressor Protection: Relative shaft vibration or position measurement when used with a compatible monitoring system.
        • Thread: 3/8-24 UNF. Select a mounting arrangement that maintains the required probe position, thread engagement and cable bend radius.
        • For radial vibration applications, the official recommended gap setting is −9 Vdc, approximately 1.27 mm (50 mils), when used as part of the specified 3300 XL 8 mm system.
        • Follow the official probe case torque and thread-engagement limits for the selected mounting arrangement. The recommended torque for a standard forward-mount probe is 11.2 N·m (100 in·lbf); where only the first three threads engage, the recommended torque is 7.5 N·m (66 in·lbf).
        Description
        Bently Nevada 330101-04-30-05-01-05 is a 3300 XL 8 mm proximity probe with 3/8-24 UNF threads and no armor. The configuration has a 0.4-inch unthreaded length, a 3.0-inch overall case length and a 0.5-metre total probe length.

        It uses a miniature coaxial ClickLoc connector with a connector protector and standard FEP-insulated cable. The nominal probe DC resistance is 7.45 ± 0.50 Ω. TipLoc and CableLoc construction provide a robust probe-tip and cable connection, with a maximum rated pull strength of 330 N (75 lbf) between the probe case and probe lead.

        The standard probe operating and storage temperature range is −52°C to +177°C (−62°F to +350°F). Approval code 05 specifies CSA, ATEX and IECEx approvals. Performance specifications such as 200 mV/mil scale factor, −24 Vdc nominal supply and 0–10 kHz frequency response apply to a correctly matched complete 3300 XL 8 mm transducer system, not to the probe alone.

        Alternative Names
        Bently Nevada 330101-04-30-05-01-05 330101 04 30 05 01 05 3301010430050105 3300 XL 8 mm Probe 330101-04-30-05-01-05
        Technical notes
        This 0.5-metre probe must be used with compatible 3300 XL 8 mm system components. The complete system can be used for vibration, position, Keyphasor reference and speed measurements.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What cable length comes with Bently Nevada 330101-04-30-05-01-05?
        The ordering code 05 specifies a total probe length of 0.5 metre (1.6 ft).
        Why does Bently Nevada 330101-04-30-05-01-05 use TipLoc molding?
        TipLoc molding provides a robust bond between the probe tip and probe body.
        How strong is the cable attachment on Bently Nevada 330101-04-30-05-01-05?
        The maximum rated tensile strength between the probe case and probe lead is 330 N (75 lbf).
        Can Bently Nevada 330101-04-30-05-01-05 operate at high temperatures?
        The standard probe operating and storage temperature range is −52°C to +177°C (−62°F to +350°F). Exposure below −34°C (−30°F) may cause premature failure of the pressure seal.
