          Bently Nevada’s current documentation lists the 330103 probe family and the BR country-specific approval option. Product availability is subject to OEM or Apter Power sourcing confirmation.

        330103-00-25-05-02-BR

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The Bently Nevada 330103-00-25-05-02-BR is a 3300 XL 8 mm metric proximity probe with M10 × 1 threads, a 250 mm case, a 0.5 metre total length, a miniature coaxial ClickLoc connector with standard cable, and the BR country-specific approval option for hazardous-area use in Brazil.
        In Stock
        Ships by Thursday, October 29
        Fast Shipping Available
        Get a quick price for 330103-00-25-05-02-BR
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330103-00-25-05-02-BR

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330103-00-25-05-02-BR
        • Product Family:
          3300 XL 8 mm Probe
        • Product Type:
          8 mm Metric Proximity Probe
        • Stock:
          2
        • Armor:
          Without armor
        • Unthreaded Length:
          0 mm
        • Overall Case Length:
          250 mm
        • Total Length:
          0.5 metre
        • Connector:
          Miniature coaxial ClickLoc connector
        • Cable:
          Standard cable
        • Mounting Thread:
          M10 × 1
        • Connector Protector:
          Not included with connector option 02
        • Probe Tip Material:
          Polyphenylene sulfide (PPS)
        • Probe Case Material:
          AISI 303 or AISI 304 stainless steel
        • Probe Operating and Storage Temperature:
          −52°C to +177°C (−62°F to +350°F)
        • Agency Approval Option:
          BR
        • Weight:
          0.323 kg
        • Estimated shipping dimensions:
          26x18x2cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Application Efficiency Application Scenarios

        Features:

        • M10 × 1 metric mounting threads with a 250 mm overall case length
        • Patented TipLoc molding and CableLoc cable attachment design
        • BR country-specific approval option for hazardous-area use in Brazil, covering applicable INMETRO requirements
        The Bently Nevada 330103-00-25-05-02-BR is a standard-mount 3300 XL 8 mm proximity probe with M10 × 1 threads and no armor. It has a 0 mm unthreaded length, a 250 mm overall case length and a 0.5 metre total length. Connector option 02 provides a miniature coaxial ClickLoc connector with standard FEP-insulated cable and does not include a factory-installed connector protector.

        The BR suffix is the country-specific approval option for hazardous-area use in Brazil. It covers applicable INMETRO requirements and includes ATEX/IECEx hazardous-area markings and ratings as applicable.

        When this probe is used as part of a correctly configured standard 3300 XL 8 mm 5 metre transducer system, the complete system complies with the applicable API 670 requirements for mechanical configuration, linear range, accuracy and temperature stability.

        Availability is subject to Apter Power’s current inventory and sourcing confirmation.
        Bently Nevada 330103-00-25-05-02-BR 8 mm Metric Proximity Probe Manuals and Datasheets Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 330103-00-25-05-02-BR 8 mm Metric Proximity Probe Specs

        General

        • Manufacturer Bently Nevada
        • Model 330103-00-25-05-02-BR
        • Condition New and unused
        • Product Family 3300 XL 8 mm Proximity Transducer System
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Fluid-Film Bearing Machines: Used as part of a complete 3300 XL 8 mm system for vibration and position measurements.
        • Radial Vibration: The complete transducer system measures dynamic shaft motion relative to the probe mounting location.
        • Position Measurement: The complete transducer system measures static displacement between the probe tip and the observed conductive target.
        • Keyphasor Reference and Speed: The complete system may be used for Keyphasor reference and speed measurements. For overspeed applications, follow the applicable Bently Nevada application guidance.
        • Complete-System Linear Range: 2.0 mm (80 mils), approximately 0.25–2.3 mm (10–90 mils) from the target, corresponding approximately to −1 to −17 VDC.
        • Recommended Gap for Radial Vibration: −9 VDC, approximately 1.27 mm (50 mils).
        • Incremental Scale Factor depends on the complete system configuration: ±5% for a standard 5 metre system and ±6.5% for a standard 9 metre system under the official reference conditions.
        • Vibration and Position Monitoring: Measures shaft vibration and position on fluid-film bearing machines as part of a complete 3300 XL 8 mm system.
        • Brazil Hazardous Areas: The BR option supports hazardous-area applications in Brazil under applicable INMETRO requirements.
        • Monitoring System Interface: Provides a displacement signal to compatible machinery monitoring systems for configured alarm and shutdown functions.
        Description
        The Bently Nevada 330103-00-25-05-02-BR is a standard-mount 3300 XL 8 mm proximity probe with an M10 × 1 threaded case and no armor. Its ordering configuration specifies a 0 mm unthreaded length, a 250 mm overall case length and a 0.5 metre total length. Connector option 02 provides a miniature coaxial ClickLoc connector with standard cable and without a factory-installed connector protector.

        The BR suffix is the country-specific approval option for hazardous-area use in Brazil. According to the official Bently Nevada Approvals Quick Reference Guide, it covers applicable INMETRO requirements and includes ATEX/IECEx hazardous-area markings and ratings as applicable.

        The 330103-00-25-05-02-BR probe uses a polyphenylene sulfide probe tip and an AISI 303 or AISI 304 stainless-steel case. Patented TipLoc molding improves the bond between the probe tip and probe body, while the CableLoc design provides a rated tensile strength of 330 N (75 lbf) between the probe case and probe lead.

        When used with an appropriate 3300 XL extension cable and 3300 XL Proximitor Sensor, the probe forms part of a complete 3300 XL 8 mm Proximity Transducer System. The complete system measures static position and dynamic vibration and is primarily applied to vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
        Alternative Names
        Bently Nevada 330103-00-25-05-02-BR 330103-00-25-05-02-BR 3300 XL 8 mm Proximity Probe 330103-00-25-05-02-BR Brazil Hazardous-Area Approval Probe
        Technical notes
        330103-00-25-05-02-BR is a standard 3300 XL 8 mm metric proximity probe with M10 × 1 threads, no armor, a 0 mm unthreaded length, a 250 mm overall case length, a 0.5 metre total length, a miniature coaxial ClickLoc connector with standard cable and the BR country-specific hazardous-area approval option. Linear range, scale factor, API 670 compliance and frequency response are complete-system characteristics and depend on the compatible extension cable and Proximitor Sensor configuration.
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        What are the primary applications of the 330103-00-25-05-02-BR?
        When used as part of a complete 3300 XL 8 mm transducer system, it supports vibration and position measurements on fluid-film bearing machines, as well as Keyphasor reference and speed measurements.
        What are the length and connector configuration?
        It has a 0.5 metre total length and a miniature coaxial ClickLoc connector with standard cable. Connector option 02 does not include a factory-installed connector protector.
        What is the system incremental scale factor?
        The nominal incremental scale factor is 7.87 V/mm (200 mV/mil). Under the official reference conditions, tolerance is ±5% for a standard 5 metre system and ±6.5% for a standard 9 metre system. These are complete-system values, not standalone probe specifications.
        What does the BR approval option indicate?
        BR is the country-specific option for hazardous-area use in Brazil. It covers applicable INMETRO requirements and includes ATEX/IECEx hazardous-area markings and ratings as applicable. Verify the exact approval from the product marking and applicable certification documentation.
