        330130-045-01-CN

        / 4.9
        1001 reviews ｜ Need a Specific Revision?
        The model 330130-045-01-CN is a 4.5-meter (14.8-foot) armored extension cable for the Bently Nevada 3300 XL 8 mm Proximity Transducer System.
        Get a quick price for 330130-045-01-CN
        Quantity
        *E-mail
        Company
        *Mobile
        *Content
        Upload (gif, jpg, jpeg, png, bmp, doc, docx, xls, xlsx, ppt, pdf, csv)
        Get a Quote
        Warranty Policy
        We provide 1 year warranty for all remaining parts.
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        Return Notice
        The warranty period is one year from the date of shipment, unless otherwise stated in the parts description. We guarantee that the project will not exhibit functional defects that may occur under normal operating conditions during the warranty period.
        In the event of a defect, we will send new equipment, repair equipment or refund the purchase price based on our availability. You must contact us to obtain a return authorization and return the defective device to us within 14 days of reporting the defect.
        Shipping Mode
        Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.Various transportation options are available in each country. Shipping methods and fees are clearly indicated on all quotations.
        Parts Availability
        Apter Power offers a wide range of components, products and services related to industrial automation. We also supply new products from a variety of quality manufacturers.
        How to order
        We have been working hard to update our inventory. If we have stock or parts available for new factory purchases, you can contact the order online. If we do not currently have an inventory, the displayed quantity will show "Ask". Please create an online quote or contact us by phone, fax or email to check availability.

        Technical specifications for 330130-045-01-CN

        • Manufacturer:
          Bently Nevada
        • Part Number:
          330130-045-01-CN
        • Product Family:
          3300 XL Extension Cable
        • System Compatibility:
          3300 XL 8 mm Proximity Transducer System
        • Cable Length:
          4.5 meters (14.8 feet)
        • Connector Type:
          Gold-plated ClickLoc
        • Compliance Standards:
          API 670 Standard
        • Connector Protection:
          Included
        • Weight:
          0.46 kg
        • Estimated shipping dimensions:
          27x27x3cm
        • Tariff Code:
          8537101190
        • Country of origin:
          USA
        • Place of shipment:
          Xiamen, Fujian, China
        By purchasing this item, you agree to the Terms & Conditions, ApterPower is not an authorized distributor for listed manufacturers or tradenames and therefore the manufacturer's warranty does not apply. All our products come with ApterPower's 1-year warranty.

        More Information

        Overview Manuals Specifications Applications Installation & Integration Compatibility & Interoperability

        Features:

        • Connection Interface Between 3300 XL 8mm Probe and 3300 XL Preamplifier
        • Integrates High-Quality Coaxial Cable Construction with EMI/RFI Noise Immunity
        • Functions in Conjunction with the 3300 XL Series Proximity Transducer System
        The Bently Nevada 330130-045-01-CN serves as the standard extension cable within the 3300 XL proximity transducer system, establishing reliable electrical continuity between the probe and preamplifier. It continuously transmits the modulated RF signal from the probe tip to the 3300 XLSensor (330180 series), maintaining signal integrity across the 4.5 meter cable length (designated by "045" in the model number). The 330130-045-01-CN utilizes triaxial cable construction with a copper braid shield to minimize electromagnetic interference and ensure accurate vibration and displacement measurements in high-noise industrial environments. Seamless integration is standard with the 330130-045-01-CN, and when combined with compatible probes and preamplifiers, it enables precise detection of shaft vibration, thrust position, and speed measurements for rotating machinery protection.

        The 330130-045-01-CN provides essential signal transmission functions critical to the entire measurement path, and is a vital component of the monitoring chain, directly influencing the accuracy and reliability of the overall condition monitoring system. One 330130-045-01-CN extension cable is required per transducer channel to complete the proximity probe system configuration. The 330130-045-01-CN occupies no rack slot as a passive component, connecting directly between the probe cable and preamplifier input via standard coaxial connectors.

        For complete system operation, the 330130-045-01-CN must be paired with a compatible 3300 XL 8mm probe (such as 330103, 330104, or 330105 series) and a 330180 series preamplifier. In addition to standard single-channel operation, multiple 330130-045-01-CN cables can be deployed throughout the monitoring system to support multi-channel machinery protection applications. The 3300 XL system executes signal conditioning using the internal electronics specified in the preamplifier options. Using this method, the 330130-045-01-CN cable maintains constant signal amplitude and phase characteristics, ensuring that the proximity transducer system output remains linear and stable across the full measurement range. If the system detects signal degradation due to cable damage or connection issues, it will indicate a fault condition through the preamplifier's OK output and trigger appropriate system alerts.

        The 330130-045-01-CN Bently Nevada Extension Cable may still be available for purchase and support from Apter Power beyond End-Of-Life (EOL) by the manufacturer (OEM).
        Bently Nevada 330130-045-01-CN Extension Cable Manuals,Datasheets,Link Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        Bently Nevada 330130-045-01-CN Extension Cable Specs

        General

        • Manufacturer Bently Nevada
        • Model 330130-045-01-CN
        • Condition New Original ready stock
        • Product Family 330130-045-01-00,330130-045-01-05,330130-040-01-CN
        Important Notice: Other accessories, manuals, cables, calibration data, software, etc. are not included with this equipment unless listed in the above stock item description. All prices are shown in USD.
        • Fluid-Film Bearing Machines: Measuring vibration and radial/axial position.
        • Speed & Reference Measurements: Used as a Keyphasor reference and for measuring rotational speed.
        • Harshest Environments: Ideal for compression systems and heavy industrial setups like refineries or offshore platforms where armored protection is necessary.
        • Electrical Length: The combined electrical length of the probe and the extension cable must match the required electrical length of the Proximitor sensor (typically 5 or 9 metres total).
        • Routing: It should be routed carefully to avoid mechanical stress and sharp bends.
        • Environmental Protection: The armored casing provides durability against physical damage, and optional connector protectors are recommended for high-moisture or oil-rich environments.
        • Grounding: Proper shielding and grounding are required to maintain EMC compliance and signal integrity.
        • System Components: It is fully compatible with standard 3300 XL 8 mm probes and 3300 XL Proximitor sensors.
        • Backward Compatibility: It is interchangeable with non-XL 3300 series 5 mm and 8 mm transducer components.
        • Extended Temperature Range (ETR): Standard cables like the 330130 can be used with ETR probes, though the system will be limited by the lowest-rated component's temperature specification.
        • Standards Compliance: When used as part of a 5-metre system, it complies with API 670 Standard for accuracy and stability.
        View as PDF
        Description
        The 330130-045-01-CN serves as a critical component within the Bently Nevada 3300 XL 8 mm Proximity Transducer System, providing a reliable armored link between the probe and monitoring electronics. This extension cable is engineered to meet the stringent requirements of the American Petroleum Institute's API 670 Standard, ensuring compliance in mechanical configuration, linear range, accuracy, and temperature stability.

        Featuring a length of 4.5 meters (14.8 feet), the 330130-045-01-CN is designed with robust armored construction to withstand harsh industrial environments. The cable incorporates gold-plated ClickLoc connectors that are corrosion-resistant and engineered for secure, finger-tight installation—requiring no special tools for connection or removal. The locking mechanism on these connectors prevents loosening under vibration, ensuring reliable signal integrity.

        While the 330130-045-01-CN is rated for standard temperature applications, the 3300 XL system also offers Extended Temperature Range (ETR) options for more extreme conditions. It is important to note that the 330130-045-01-CN is compatible with ETR probes, allowing users to mix components based on application needs.

        In summary, the 330130-045-01-CN exemplifies Bently Nevada's commitment to performance, durability, and ease of use in condition monitoring systems. Its armored construction, combined with industry-compliant design and plug-and-play interchangeability, makes it a dependable choice for vibration and position monitoring in turbines, compressors, pumps, and other critical rotating machinery.
        Alternative Names
        330130-045-01-00 330130-045-01-05 330130-045-01-RU 330130-045-11-CN
        Exceptional Service

        Our Mission

        • 100% Satisfaction

          We believe expertise is priceless. With over 20 years of experience, and top engineers on staff, we can help you solve or avoid problems that threaten your business.

        • Trust Guaranteed

          Not only do we have a vast inventory, our team makes sure every piece of equipment is in working condition. Your purchases are also backed by our Warranty.

        • Expertise

          Time is money, especially when your equipment is down. We work quickly to get your equipment on its way so you can get it back up and running.

        FAQS

        The following is a list of questions commonly asked by our customers. Please contact us if you have a question about our process that is not answered below.
        VIEW ALL FAQS
        Does the 330130-045-01-CN comply with industry standards, and what does this mean for system performance?
        Yes, the 330130-045-01-CN is part of the 3300 XL 8 mm system, which fully complies with the American Petroleum Institute’s API 670 Standard for mechanical configuration, linear range, accuracy, and temperature stability. This ensures that when the 330130-045-01-CN is used within the system, it meets rigorous industry requirements for machinery protection and condition monitoring in critical applications such as refineries, petrochemical plants, and power generation facilities.
        Can the 330130-045-01-CN be used with Extended Temperature Range (ETR) probes, and what are the implications for system accuracy?
        Yes, the 330130-045-01-CN is compatible with ETR probes. However, when any ETR component—such as an ETR probe or cable—is integrated into the system alongside the 330130-045-01-CN, the overall system accuracy is limited to the ETR specification. This means that while the 330130-045-01-CN maintains its standard performance, the combined system’s accuracy will align with the lower tolerance of the ETR components, which is an important consideration for high-precision monitoring applications.
        What are the key mechanical and connector features of the 330130-045-01-CN that enhance reliability?
        The 330130-045-01-CN features armored cable construction for physical protection and durability. Its connectors are gold-plated ClickLoc types, which are corrosion-resistant and designed for finger-tight installation with no special tools required. The connectors incorporate a locking mechanism to prevent loosening under vibration, and the system also includes a connector protector to shield against environmental contaminants, ensuring long-term signal integrity and reliability in industrial settings.
        Is the 330130-045-01-CN interchangeable with other components in the 3300 XL system, and does it require calibration when replaced?
        Yes, the 330130-045-01-CN supports complete interchangeability within the 3300 XL 8 mm proximity transducer system. This means that probes, extension cables like the 330130-045-01-CN, and Proximitor sensors can be replaced individually without the need for matching or bench calibrating components. This plug-and-play design simplifies maintenance, reduces downtime, and ensures consistent system performance without requiring recalibration or component-specific pairing.
